M7i Internet Router
Quick Start
30 April 2007
Part Number: 530-017640-01
Revision 2
This document describes how to install the M7i Internet router.
Quick Start Description ...................................................................................3
Step 1: Prepare the Site ...................................................................................3
Rack-Mounting Requirements ...................................................................3
Tools Required ..........................................................................................5
Step 2: Prepare for Front or Center Mounting .................................................6
Step 3: Install the Router .................................................................................7
Step 4: Connect External Devices and PIC Cables ...........................................8
Connect a Management Console or Auxiliary Device ................................9
Connect to a Network for Out-of-Band Management .................................9
Connect FIC and PIC Cables ......................................................................9
Step 5: Connect Ground and Power Cables ...................................................10
Connect AC Power ..................................................................................10
Connect DC Power ..................................................................................11
Step 6: Power On the Router .........................................................................12
Step 7: Perform Initial Software Configuration ..............................................13
Safety Warnings ............................................................................................15
1

Advertisement

Table of Contents
loading

Related Manuals for Juniper Juniper M-series M7i

Summary of Contents for Juniper Juniper M-series M7i

  • Page 1: Table Of Contents

    M7i Internet Router Quick Start 30 April 2007 Part Number: 530-017640-01 Revision 2 This document describes how to install the M7i Internet router. Contents Quick Start Description ...3 Step 1: Prepare the Site ...3 Rack-Mounting Requirements ...3 Tools Required ...5 Step 2: Prepare for Front or Center Mounting ...6 Step 3: Install the Router ...7 Step 4: Connect External Devices and PIC Cables ...8...
  • Page 2 M7i Internet Router Quick Start Compliance Statements for NEBS ...17 Compliance Statements for EMC Requirements ...17 Canada ...17 European Union ...17 Declaration of Conformity ...18 List of Technical Publications ...19 Requesting Support ...23 Revision History ...23...

  • Page 3: Contents Quick Start Description

    The router is shipped in a cardboard carton, secured with foam packing material. The carton contains: One accessory box (the box to which this Quick Start is taped) One Juniper Networks router One Quick Start (this document) Step 1: Prepare the Site...
  • Page 4 M7i Internet Router Quick Start floor-to-ceiling rack. If you do so, the rack must be capable of supporting a combined weight of over 766 lb (347 kg). The rack rails must be spaced widely enough to accommodate the router chassis's external dimensions: 3.5 in.

  • Page 5: Tools Required

    Step 1: Prepare the Site Figure 1: Rack Clearances and Router Dimensions Tools Required Phillips (+) screwdriver, numbers 1 and 2 Electrostatic discharge wrist strap Antistatic mat Blank panels to cover any slots not occupied by a component Step 1: Prepare the Site...

  • Page 6: Step 2: Prepare For Front Or Center Mounting

    M7i Internet Router Quick Start Step 2: Prepare for Front or Center Mounting The cable management system organizes and supports the PIC cables to prevent damage. The mounting brackets are shipped installed in the front-mounting position, but must be removed to install the cable management system. Attach an electrostatic discharge (ESD) grounding strap to your bare wrist and connect the strap to one of the ESD points on the chassis.

  • Page 7: Step 3: Install The Router

    Step 3: Install the Router Have one person grasp each side of the router, lift the router, and position it in the rack. See Figure 4 on page 8. Align the bottom hole in each mounting bracket with a hole in each rack rail, making sure the chassis is level.

  • Page 8: Step 4: Connect External Devices And Pic Cables

    M7i Internet Router Quick Start Figure 4: Lift the Router into the Rack Step 4: Connect External Devices and PIC Cables To connect external devices and PIC or FIC cables, perform the following procedures: Connect a Management Console or Auxiliary Device on page 9 Connect to a Network for Out-of-Band Management on page 9 Connect FIC and PIC Cables on page 9 Step 4: Connect External Devices and PIC Cables...

  • Page 9: Connect A Management Console Or Auxiliary Device

    Figure 5: Connect External Devices and PIC Cables to Router Connect a Management Console or Auxiliary Device Turn off the power to the console or auxiliary device. Plug the female end of the RS-232 serial connector into the AUX/MODEM Use a 2.5 mm flat-blade screwdriver to tighten the screws on the connector. Connect the other end of the cable to the console or auxiliary device.

  • Page 10: Step 5: Connect Ground And Power Cables

    M7i Internet Router Quick Start CAUTION: To prevent damage to fiber-optic transceivers and fiber-optic cables, observe the following precautions: Do not leave a fiber-optic transceiver uncovered except when inserting or removing cable. The safety plug keeps the port clean and prevents accidental exposure to laser light.

  • Page 11: Connect Dc Power

    Verify that the switch on each power supply faceplate is in the For each power supply: Insert the appliance coupler end of a power cord into the appliance inlet on a power supply faceplate. Insert the plug into an AC power source receptacle. Verify that the power cord does not block access to router components or drape where people could trip on it.

  • Page 12: Step 6: Power On The Router

    M7i Internet Router Quick Start Verify that the power cables are not touching or blocking access to router components, and that they do not drape where people could trip on them. Switch on the external circuit breakers to provide voltage to the DC power source cable leads.

  • Page 13: Step 7: Perform Initial Software Configuration

    Verify that the seconds, repeat Steps 3 through 6. If necessary, reinstall the AC power cord or DC power cables. For routers with two power supplies, repeat Steps 3 through 7 for the second power supply. Step 7: Perform Initial Software Configuration This procedure connects the router to the network but does not enable it to forward traffic.
  • Page 14 M7i Internet Router Quick Start root@# set system name-server address Set the root authentication password by entering either a clear-text password, an encrypted password, or an ssh public key string (DSA or RSA). [edit] root@# set system root-authentication plain-text-password New password: password Retype new password: password [edit] root@# set system root-authentication encrypted-password encrypted-password...

  • Page 15: Safety Warnings

    Optionally, configure additional properties by adding the necessary configuration statements. Then commit the changes to activate them on the router. [edit] root@host# commit When you have finished configuring the router, exit configuration mode. [edit] root@host# exit root@host> Safety Warnings WARNING: See installation instructions before connecting the router. This is a summary of safety warnings.
  • Page 16 M7i Internet Router Quick Start When installing the router, do not use a ramp inclined at more than 10 degrees. Manually installing the router requires two people to lift. To prevent injury, keep your back straight and lift with your legs, not your back. Do not attempt to lift the chassis by the power supply handles.

  • Page 17: Compliance Statements For Nebs

    Compliance Statements for NEBS This product complies with the following standards: GR-63-Core: NEBS, Physical Protection GR-1089-Core: EMC and Electrical Safety for Network Telecommunications Equipment SR-3580 NEBS Criteria Levels (Level 3 Compliance) Compliance Statements for EMC Requirements Canada This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à...

  • Page 18: Declaration Of Conformity

    M7i Internet Router Quick Start Declaration of Conformity Compliance Statements for EMC Requirements...

  • Page 19: List Of Technical Publications

    Table 1 on page 19 lists the software and hardware guides and release notes for Juniper Networks J-series, M-series, MX-series, and T-series routing platforms and describes the contents of each document. Table 2 on page 22 lists the books included in the Network Operations Guide series.
  • Page 20 JUNOS system software. This material was formerly covered in the JUNOS System Basics Configuration Guide. Describes Juniper Networks routing platforms, and provides information about how to configure basic system parameters, supported protocols and software processes, authentication, and a variety of utilities for managing your router on the network.
  • Page 21 Basic LAN and WAN Access Configuration Guide Advanced WAN Access Configuration Guide Description Describes how to use the JUNOScript application programming interface (API) to monitor and configure Juniper Networks routing platforms. Provides reference pages for the configuration tag elements in the JUNOS XML API.
  • Page 22 M7i Internet Router Quick Start Table 1: Technical Documentation for Supported Routing Platforms (continued) Book Administration Guide Release Notes JUNOS Release Notes Hardware Release Notes JUNOScope Release Notes J-series Services Router Release Notes Table 2: JUNOS Internet Software Network Operations Guides Book Baseline Interfaces...

  • Page 23: Requesting Support

    Products made or sold by Juniper Networks or components thereof might be covered by one or more of the following patents that are owned by or licensed to Juniper Networks: U.S. Patent Nos. 5,473,599, 5,905,725, 5,909,440, 6,192,051, 6,333,650, 6,359,479, 6,406,312, 6,429,706, 6,459,579, 6,493,347, 6,538,518, 6,538,899, 6,552,918, 6,567,902, 6,578,186, and 6,590,785.
