CHAPTER 9
Connecting the M120 Router to External
Devices
Tools and Parts Required to Connect the M120 Router
Related
Documentation
Connecting the M120 Router to Management and Alarm Devices
Copyright © 2010, Juniper Networks, Inc.
All manuals and user guides at all-guides.com
Tools and Parts Required to Connect the M120 Router on page 81
Connecting the M120 Router to Management and Alarm Devices on page 81
Connecting PIC Cables to the M120 Router on page 87
To connect the router to management devices and PICs and to power on the router, you
need:
Phillips (+) screwdrivers, numbers 1 and 2
2.5-mm flat-blade (-) screwdriver
7/16-in. hexagonal-head external drive socket wrench, or nut driver, with a torque range
between 23 lb-in. (2.6 Nm) and 25 lb-in. (2.8 Nm), for tightening nuts to terminal studs
on the circuit breaker box (on a DC-powered router)
Wire cutters
Electrostatic discharge (ESD) grounding wrist strap
M120 Power Supplies Description on page 29
Connecting the Grounding Cable to the M120 Router on page 79
General Electrical Safety Warnings for M Series, MX Series, and T Series Routers on
page 208
Connecting the M120 Router to Management and Alarm Devices on page 81
Connecting PIC Cables to the M120 Router on page 87
For management and service operations, you connect the Routing Engine to an external
console or management network through ports on the Craft Interface. You can also
