APPENDIX B

M120 Router Physical Specifications

M120 Router Physical Specifications

Table 24: M120 Physical Specifications

Description
Chassis dimensions
Router weight
Related
Documentation
Copyright © 2010, Juniper Networks, Inc.
All manuals and user guides at all-guides.com
M120 Router Physical Specifications on page 225
Table 24 on page 225 summarizes the physical specifications for the router chassis.
Value
20.75 in. (52.71 cm) high
17.43 in. (44.3 cm) wide
24.3 in. (61.7 cm) deep (from front-mounting flange to chassis
rear)
Total depth (including cable management system)
29.85 in. (75.8 cm)
Chassis with midplane and fans: 110 lb (49 kg)
Maximum configuration: 225 lb (102.1 kg)
M120 Router Description on page 3
M120 Router Chassis Description on page 6
M120 Router Environmental Specifications on page 227
225
