Juniper M-series M10i Manual

Juniper M-series M10i Manual

Internet router
Hide thumbs Also See for Juniper M-series M10i:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction and Installation Manual
M10i Internet Router
PIC Guide
Juniper Networks, Inc.
1194 North Mathilda Avenue
Sunnyvale, California 94089
USA
408-745-2000
www.juniper.net
Part Number: 530-022504-01, Revision 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Juniper M-series M10i and is the answer not in the manual?

Questions and answers

Related Manuals for Juniper Juniper M-series M10i

Summary of Contents for Juniper Juniper M-series M10i

  • Page 1 M10i Internet Router PIC Guide Juniper Networks, Inc. 1194 North Mathilda Avenue Sunnyvale, California 94089 408-745-2000 www.juniper.net Part Number: 530-022504-01, Revision 2...
  • Page 2 M10i Internet Router PIC Guide This guide provides an overview and description of the Physical Interface Cards (PICs) supported by the Juniper Networks M10i Internet router. The PICs are described alphabetically. Table 1 on page 3 lists the PICs supported by the M10i router.
  • Page 3 Table 1: PICs Supported in the M10i Internet Router PIC Family and Type Ports ATM2 IQ ATM2 DS3 IQ ATM2 E3 IQ ATM2 OC3/STM1 IQ ATM2 OC12/STM4 IQ Channelized Channelized OC12 Channelized IQ Channelized DS3 IQ Channelized E1 IQ Channelized OC12 IQ Channelized OC3 IQ Channelized STM1 IQ Channelized T1 IQ...
  • Page 4 M10i Internet Router PIC Guide Table 1: PICs Supported in the M10i Internet Router (continued) PIC Family and Type Ethernet IQ2 Gigabit Ethernet IQ2 Services Adaptive Services II Adaptive Services II FIPS Link Services MultiServices 100 Tunnel Services Serial EIA-530 SONET/SDH SONET/SDH OC3c/STM1 SONET/SDH OC3c/STM1...

  • Page 5: Adaptive Services Ii Pic

    Adaptive Services II PIC Software release JUNOS 6.4 and later Description Supports tunnel services. This feature is included with the PIC and does not require an individual license. Individual licenses must be purchased for additional services. Power requirement: 0.4 A @ 48 V (19 W) Hardware features Support for up to 2000 service sets Active monitoring on up to 1 million flows...
  • Page 6 M10i Internet Router PIC Guide Table 2: Adaptive Services PICs Software Features (continued) Network Address Translation (NAT) for IP addresses Port Address Translation (PAT) for port numbers IP Security (IPSec) encryption Active flow monitoring exports cflowd version 5 and version 8 records Active flow monitoring exports version 9 records, based on RFC 3954 (IP v4 templates only)

  • Page 7: Adaptive Services Ii Fips Pic

    Adaptive Services II FIPS PIC Software release JUNOS 7.2 and later Description JUNOS-FIPS requires an Adaptive Services II FIPS PIC for external IPSec connections. See the Secure Configuration Guide for Common Criteria and JUNOS-FIPS for more information. Supports tunnel services. This feature is included with the PIC and does not require an individual license.
  • Page 8 M10i Internet Router PIC Guide LEDs Status LED, one tricolor: Off PIC is offline and it is safe to remove it from the chassis. Green PIC is operating normally. Amber PIC is initializing. Red PIC has an error or failure and no further harm can be done by removing it from the chassis.
  • Page 9 ATM2 DS3 IQ PIC Software release JUNOS 6.1 and later Description Four DS3 ports Power requirement: 0.41 A @ 48 V (20.0 W) Intelligent queuing (IQ) PICs support fine-grained queuing per logical interface. ATM standards compliant Hardware features 16-MB SDRAM memory for ATM segmentation and reassembly (SAR) ATM switch ID Configurable framing options: Internal and loop timing...
  • Page 10 M10i Internet Router PIC Guide Cables and connectors 10 ft (3.05 m) posilock SMB to BNC (provided) Four pairs of Rx and Tx coaxial cables LEDs One tricolor per port: Off Not enabled Green Online with no alarms or failures Amber Online with alarms for remote failures Red Active with a local alarm;...
  • Page 11 ATM2 E3 IQ PIC Software release JUNOS 6.1 and later Description Two E3 ports Power requirement: 0.41 A @ 48 V (20 W) Intelligent queuing (IQ) PICs support fine-grained queuing per logical interface ATM standards compliant Hardware features 16-MB SDRAM memory for ATM segmentation and reassembly (SAR) ATM switch ID Configurable framing options: Internal and loop timing...
  • Page 12 M10i Internet Router PIC Guide LEDs One tricolor per port: Off Not enabled Green Online with no alarms or failures Amber Online with alarms for remote failures Red Active with a local alarm; router has detected a failure Alarms, errors, and Alarm indication signal (AIS) events Frame error...

  • Page 13: Atm2 Oc3/Stm1 Iq Pic

    ATM2 OC3/STM1 IQ PIC Software release JUNOS 6.1 and later Description Two OC3 ports Power requirement: 0.41 A @ 48 V (20 W) Intelligent queuing (IQ) PICs support fine-grained queuing per logical interface Conforms to ANSI T1.105-1991 and T1E1.2/93-020R1 ATM and SONET/SDH standards compliant Alarm and event counting and detection Compatible with well-known ATM switches ATM switch ID, which displays the switch IP address and local interface name of the...
  • Page 14 M10i Internet Router PIC Guide Software features Circuit cross-connect (CCC) for leveraging ATM access networks User-configurable virtual circuit (VC) and virtual path (VP) support Support for idle cell or unassigned cell transmission OAM fault management processes alarm indication signal (AIS), remote defect indicator (RDI) cells, and loop cells Point-to-point and point-to-multipoint mode Layer 2 counters per VC and per VP Local and remote loopback...
  • Page 15 Table 3: Optical Interface Support for ATM2 OC3 IQ PICs (continued) Parameter Intermediate Reach (IR) Standard Telcordia GR-253 Maximum distance 9.3 miles/15 km Transmitter 1260 through 1360 nm wavelength Average launch power –15 through –8 dBm Receiver saturation –8 dBm Receiver sensitivity –28 dBm ATM2 OC3/STM1 IQ PIC...
  • Page 16 M10i Internet Router PIC Guide ATM2 OC12/STM4 IQ PIC Software release JUNOS 6.1 and later Description One OC12 port Power requirement: 0.41 A @ 48 V (20 W) Intelligent queuing (IQ) PICs support fine-grained queuing per logical interface Conforms to ANSI T1.105-1991 and T1E1.2/93-020R1 Complies with ATM and SONET/SDH standards Alarm and event counting and detection Compatible with well-known ATM switches...
  • Page 17 Cables and connectors Duplex SC/PC connector (Rx and Tx) Optical interface support See Table 4 on page 17 LEDs One tricolor per port: Off Not enabled Green Online with no alarms or failures Amber Online with alarms for remote failures Red Active with a local alarm;...

  • Page 18: Channelized Ds3 Iq Pic

    M10i Internet Router PIC Guide Channelized DS3 IQ PIC Software release JUNOS 6.1 and later Description Four DS3 ports Power requirement: 0.32 A @ 48 V (15.6 W) Intelligent queuing (IQ) PICs support fine-grained queuing per logical interface Channelization: DS3, DS0 Hardware features Data service unit (DSU) functionality Subrate and scrambling:...
  • Page 19 LEDs One tricolor per port: Off Not enabled Green Online with no alarms or failures Amber Online with alarms for remote failures Red Active with a local alarm; router has detected a failure Alarms, errors, and Alarm indication signal (AIS) events Excessive zeros (EXZ) Far-end block error (FEBE)

  • Page 20: Channelized E1 Iq Pic

    M10i Internet Router PIC Guide Channelized E1 IQ PIC Software release JUNOS 6.1 and later Description Ten E1 ports Power requirement: 0.15 A @ 48 V (7.2 W) Intelligent queuing (IQ) PICs support fine-grained queuing per logical interface. Channelization: E1, DS0 Hardware features Data service unit (DSU) functionality Ports configurable as clear channel E1 interfaces with 2.048-Mbps connectivity...
  • Page 21 Alarms, errors, and Alarm indication signal (AIS) events Loss of frame (LOF) Out of frame (OOF) Failed signal rate (FSR) Instrumentation Layer 2 per-queue and per-channel packet and byte counters (counters) Channelized E1 IQ PIC Channelized E1 IQ PIC...
  • Page 22 M10i Internet Router PIC Guide Channelized OC12 PIC Software release JUNOS 6.1 and later Description One OC12 port Power requirement: 0.23 A @ 48 V (10.8 W) 12 DS3 channels Supports IP version 4 (IPv4) unicast and multicast as well as MPLS, Intermediate System-to-Intermediate System (IS-IS), Open Shortest Path First (OSPF), and Border Gateway Protocol (BGP) Hardware features...
  • Page 23 Alarms, errors, and Alarm indication signal (AIS-L, AIS-P) events BERT functionality (you can configure one DS3 channel in BERT mode and configure the remaining channels to transmit and receive normal traffic) Bit error rate signal degrade (BERR-SD), Bit error rate signal fail (BERR-SF) Bit interleaved parity errors B1, B2, B3 (CV-S, CV-L, CV-P) Equipment failure (Does not affect service) Errored seconds (ES-S, ES-L, ES-P), far-end bit errors REI-L, REI-P (CV-LFE, CV-PFE),...

  • Page 24: Channelized Oc12 Iq Pic

    M10i Internet Router PIC Guide Channelized OC12 IQ PIC Software release JUNOS 6.1 and later Description One OC12 port Power requirement: 0.23 A @ 48 V (10.8 W) Intelligent queuing (IQ) PICs support fine-grained queuing per logical interface Channelization: OC3, DS3, DS1, DS0 Hardware features Subrate and scrambling: Packet buffering, Layer 2 parsing...
  • Page 25 LEDs One tricolor per port: Off Not enabled Green Online with no alarms or failures Amber Online with alarms for remote failures Red Active with a local alarm; router has detected a failure Alarms, errors, and Alarm indication signal (AIS-L, AIS-P) events Bit error rate signal degrade (BERR-SD), bit error rate signal fail (BERR-SF) Bit interleaved parity errors B1, B2, B3 (CV-S, CV-L, CV-P)

  • Page 26: Channelized Oc3 Iq Pic

    M10i Internet Router PIC Guide Channelized OC3 IQ PIC Software release JUNOS 7.6 and later Description One OC3 port Power requirement: 0.39 A @ 48 V (18.6 W) Intelligent queuing (IQ) PICs support fine-grained queuing per logical interface Channelization: DS3, DS1, DS0 Hardware features Subrate and scrambling: Packet buffering, Layer 2 parsing...
  • Page 27 LEDs One tricolor per port: Off Not enabled Green Online with no alarms or failures Amber Online with alarms for remote failures Red Active with a local alarm; router has detected a failure Alarms, errors, and Alarm indication signal (AIS-L, AIS-P) events Bit error rate signal degrade (BERR-SD), bit error rate signal fail (BERR-SF) Bit interleaved parity errors B1, B2, B3...

  • Page 28: Channelized Stm1 Iq Pic

    M10i Internet Router PIC Guide Channelized STM1 IQ PIC Software release JUNOS 6.1 and later Description One STM1 port Power requirement: 0.39 A @ 48 V (18.6 W) Intelligent queuing (IQ) PICs support fine-grained queuing per logical interface Channelization: STM1c, fractional E1, framed and unframed DS0 Hardware features Packet buffering, Layer 2 parsing Local and remote loopback testing...
  • Page 29 Alarms, errors, and Alarm indication signal (AIS-L, AIS-P) events Bit error rate signal degrade (BERR-SD), bit error rate signal fail (BERR-SF) Bit interleaved parity errors B1, B2, B3 (CV-S, CV-L, CV-P) Errored seconds (ES-S, ES-L, ES-P), far-end bit errors REI-L, REI-P (CV-LFE, CV-PFE), far-end errored seconds (ES-LFE, ES-PFE), far-end severely errored seconds (SES-LFE, SES-PFE), far-end unavailable seconds (UAS-LFE, UAS-PFE) Loss of frame (LOF), loss of pointer (LOP-P), loss of signal (LOS)

  • Page 30: Channelized T1 Iq Pic

    M10i Internet Router PIC Guide Channelized T1 IQ PIC Software release JUNOS 7.4 and later Description Ten T1 ports Power requirement: 0.15 A @ 48 V (7.2 W) Intelligent queuing (IQ) PICs support fine-grained queuing per logical interface. Channelization: T1, FT1, NxDS0 Hardware features Data service unit (DSU) and channel service unit (CSU) functionality Ports configurable as clear channel T1 interfaces with 1.544-Mbps connectivity...
  • Page 31 Software features Quality of service (QoS) per channel: weighted round-robin (WRR), random early detection (RED), weighted random early detection (WRED) SNMP: T1 MIB and DS0 MIB Dynamic, arbitrary channel configuration Full bit error rate test (BERT) patterns at T1 and DS0 levels Encapsulations: High-Level Data Link Control (HDLC) Frame Relay...
  • Page 32 M10i Internet Router PIC Guide DS3 PIC Software release JUNOS 6.1 and later Description Two or four DS3 ports Power requirement: 0.47 A @ 48 V (22.5 W) Integrated DSU interoperability with leading DSU vendors Hardware features High-performance throughput on each port at speeds up to 44.736 Mbps, full duplex C-bit framing B3ZS line encoding Subrate and scrambling:...
  • Page 33 LEDs One tricolor per port: Off Not enabled Green Online with no alarms or failures Amber Online with alarms for remote failures Red Active with a local alarm; router has detected a failure Alarms, errors, and Alarm indication signal (AIS) events Bit error rate test (BERT) functionality on PIC (you can configure one DS3 channel in BERT mode and configure the remaining channels to transmit and receive normal traffic)
  • Page 34 M10i Internet Router PIC Guide E1 PIC Software release JUNOS 6.1 and later Description Four E1 or coaxial ports Power requirement: 0.08 A @ 48 V (3.74 W) Two versions: Onboard DSU functionality for E1 connectivity Hardware features High-performance throughput on each port at speeds up to 2.048 Mbps, full duplex Maximum transmission units (MTUs) of up to 4500 bytes Per-interface diagnostics and loopback control Per-interface shaping on output...
  • Page 35 LEDs One tricolor per port: Off Not enabled Green Online with no alarms or failures Amber Online with alarms for remote failures Red Active with a local alarm; router has detected a failure Alarms, errors, and Alarm indication signal (AIS) events Bipolar violations Excessive zeros...
  • Page 36 M10i Internet Router PIC Guide E3 PIC Software release JUNOS 6.0 and later Description Two E3 ports Power requirement: 0.47 A @ 48 V (22.5 W) Integrated DSU interoperability Hardware features High-density E3 (34.368-Mbps) connectivity High-performance throughput on each port at speeds up to 34.368 Mbps, full duplex Scrambling support Subrate clocking support Rate policing on input...
  • Page 37 Alarms, errors, and Alarm indication signal (AIS) events Equipment failure (does not affect service) Frame error Line code violation Loss of signal (LOS) Out of frame (OOF) Yellow alarm bit (A-bit) disagreements E3 PIC E3 PIC...
  • Page 38 M10i Internet Router PIC Guide E3 IQ PIC Software release JUNOS 6.1 and later Description Four E3 ports Power requirement: 0.38 A @ 48 V (18 W) Intelligent queuing (IQ) PICs support fine-grained queuing per logical interface Hardware features Clear-channel (34.368-Mbps) and subrate E3 Unframed or ITU G.751 framing Data service unit (DSU) functionality Subrate and scrambling:...
  • Page 39 LEDs One tricolor per port: Off Not enabled Green Online with no alarms or failures Amber Online with alarms for remote failures Red Active with a local alarm; router has detected a failure Alarms, errors, and Alarm indication signal (AIS) events Equipment failure (does not affect service) Frame error...
  • Page 40 M10i Internet Router PIC Guide EIA-530 PIC Software release JUNOS 6.1 and later Description Two EIA-530, X.21 or V.35 serial ports Power requirement: 0.07 A @ 48 V (3.4 W) Hardware features Configured as data terminal equipment (DTE) ports Resynchronization signal Receives clock rates up to 16 Mbps Local, data communications equipment (DCE) local, and DTE remote loopbacks Software features...
  • Page 41 LEDs Three bicolor per port: Data set ready (DSR): Green DSR is detected or ignored Red DSR expected but not present Data carrier detect (DCD): Green DCD is detected or ignored Red DCD expected but not present Resynchronization: Green Keepalives are being received Red Data terminal ready (DTR) toggled from low to high (resynchronization pulses are being sent) Instrumentation...
  • Page 42 M10i Internet Router PIC Guide ES PIC Software release JUNOS 6.1 and later Description High-bandwidth encryption (in accordance with IPSec standards) Power requirement: 0.21 A @ 48 V (10 W) Support for IPSec encryption, decryption, and key calculation acceleration NOTE: The ES PIC does not support reassembly and decryption of encrypted packets that were fragmented in an IPSec tunnel.
  • Page 43 Instrumentation Input and output bytes per tunnel (counters) Total authentication failures Total antireply failures Total encryption ASIC errors per PIC ES PIC ES PIC...

  • Page 44: Fast Ethernet Pics

    M10i Internet Router PIC Guide Fast Ethernet PICs Left: 4-Port Fast Ethernet PIC; Right: 8-Port Fast Ethernet PIC Left: 12-Port Fast Ethernet PIC; Right: VHDCI to RJ-21 cable Software release JUNOS 6.1 and later Description 4 or 12 100Base-TX ports; 8 100Base-FX ports Power requirement: Hardware features High-performance throughput on each port at speeds up to 100 Mbps...
  • Page 45 Cables and connectors 4-port PIC: Connector: Two-pair, Category 5 unshielded twisted-pair connectivity through an RJ-45 connector Pinout: MDI noncrossover 8-port PIC: Connector: MT-RJ female FX optical interface see Table 8 on page 45 12-port PIC: Connector: One very High Density Connector Interface (VHDCI) to RJ-21 cable that connects to an RJ-45 patch panel LEDs Status LED, one bicolor:...
  • Page 46 M10i Internet Router PIC Guide Table 8: Optical Interface Support for Fast Ethernet PICs (continued) Optical Parameters FX interface for 8-Port Maximum distance 62.5/125 micrometer MMF: 1.24 miles /2 km Wavelength 1,270 to 1,380 nm Average launch power –20 to –14 dBm Receiver saturation –14 dBm Receiver sensitivity...
  • Page 47 Gigabit Ethernet PIC with SFP Software release JUNOS 6.3 and later Description One Gigabit Ethernet port Power requirement: 0.15 A @ 48 V (7.3 W) Supports large Ethernet frame sizes for more efficient throughput across the intra-POP network Hardware features High-performance throughput on each port at speeds up to 1 Gbps Autonegotiation between Gigabit Ethernet circuit partners Full-duplex mode...
  • Page 48 M10i Internet Router PIC Guide LEDs Status LED, one bicolor: Off PIC is not enabled Green PIC is operating normally Red PIC has an error or failure Port LEDs, one pair per port: Link If green, the port is online; if there is no light, the port is down Activity If flashing green, the port is receiving data;...
  • Page 49 Gigabit Ethernet IQ PIC with SFP Software release JUNOS 6.1 and later Description One Gigabit Ethernet port Power requirement: 0.46 A @ 48 V (22 W) Intelligent queuing (IQ) PICs support fine-grained queuing per-logical interface. Hardware features High-performance throughput at speeds up to 1 Gbps Full-duplex mode Large MTUs of up to 9192 bytes Software features...
  • Page 50 M10i Internet Router PIC Guide LEDs Status LEDs, one tricolor: Port LEDs, one per port: Table 10: Optical Interface Support for Gigabit Ethernet IQ PICs with SFP Parameter 1000Base-SX Optical interface Multimode Transceiver type Standard IEEE 802.3 1998 Maximum distance 62.5/125 MMF cable: 656 ft/200 m 50/125 MMF cable:...
  • Page 51 Gigabit Ethernet IQ2 PIC with SFP Software release JUNOS 7.6R3 and later Description Four Gigabit Ethernet ports Power requirement: 0.65 A @ 48 V (31 W) Hardware features High-performance throughput on each port: speeds up to 1 Gbps Full-duplex mode Large maximum transmission units (MTUs) of up to 9192 bytes Software features Intelligent handling of oversubscribed traffic...
  • Page 52 M10i Internet Router PIC Guide Cables and connectors You can install any transceiver supported by the PIC. For information about installing and removing transceivers, see the PIC and Transceiver Installation Instructions. NOTE: Do not install SONET/SDH SFPs in the Gigabit Ethernet port. The port will not recognize the SFP.
  • Page 53 Table 11: Optical Interface Support for Gigabit Ethernet IQ2 PICs with SFP (continued) Parameter 1000Base-SX Average launch power –9.5 through 0 dBm Average receive –17 through 0 dBm power Receiver saturation 0 dBm Receiver sensitivity –17dBm Gigabit Ethernet IQ2 PIC with SFP 1000Base-LX 1000Base-LH –11.5 through –3...
  • Page 54 M10i Internet Router PIC Guide Link Services PIC Software release JUNOS 6.1 and later Description Power requirement: 0.17 A @ 48 V (8 W) Three versions: Multilink bonding, link fragmentation and interleaving (LFI), and tunneling Hardware features Rate limiting/policing per multilink bundle Byte-wise load balancing across multilink bundles Bonding T1 links enable service ranging from 1.5 Mbps through 12 Mbps Bonding E1 links enable service ranging from 2 Mbps through 16 Mbps...
  • Page 55 MultiServices 100 PIC Software release JUNOS 8.1 and later Description Supports tunnel services. This feature is included with the PIC and does not require an individual license. Individual licenses must be purchased for additional services. Power requirement: 0.52 A @ 48 V (25 W) Hardware features Active monitoring on up to 1.6 million flows Software features...
  • Page 56 M10i Internet Router PIC Guide Table 12: MultiServices PICs Software Features Supported by the M10i Router (continued) Stateful firewall with packet inspection: detects SYN attacks, ICMP and UDP floods, and ping of death attacks Network Address Translation (NAT) for IP addresses Port Address Translation (PAT) for port numbers IP Security (IPSec) encryption Active flow monitoring exports cflowd version 5 and version 8 records...

  • Page 57: Sonet/Sdh Oc3C/Stm1 Pic

    SONET/SDH OC3c/STM1 PIC Software release JUNOS 6.1 and later (Type 1) NOTE: Although the illustration shows a multimode PIC, both a multimode PIC and a single-mode intermediate reach PIC are supported. Description Four OC3 ports Power requirement: 0.49 A @ 48 V (23.7 W) Hardware features Multiplexing and demultiplexing Rate policing on input...
  • Page 58 M10i Internet Router PIC Guide Alarms, errors, and SONET alarms: events SDH alarms: Errored seconds (ES-S, ES-L, ES-P), far-end errored seconds (ES-LFE, ES-PFE), far-end severely errored seconds (SES-LFE, SES-PFE), far-end unavailable seconds (UAS-LFE, UAS-PFE) Severely errored framing (SEF), severely errored framing seconds (SEFS-S), severely errored seconds (SES-S, SES-L, SES-P), unavailable seconds (UAS-L, UAS-P) Table 13: Optical Interface Support for SONET/SDH OC3c/STM1 PICs Parameter...
  • Page 59 Table 13: Optical Interface Support for SONET/SDH OC3c/STM1 PICs (continued) Parameter Intermediate Reach Standard Telcordia GR-253 Maximum distance SMF cable: 9.3 miles/15 km Transmitter 1260 through 1360 nm wavelength Average launch power –15 through –8 dBm Receiver saturation –8 dBm Receiver sensitivity –28 dBm SONET/SDH OC3c/STM1 PIC...
  • Page 60 M10i Internet Router PIC Guide SONET/SDH OC3c/STM1 PIC with SFP Software release JUNOS 8.4 and later Description Two OC3c ports Power requirement: 0.25 A @ 48 V (12 W) Hardware features Multiplexing and demultiplexing Rate policing on input Rate shaping on output Packet buffering, Layer 2 parsing Software features Optical diagnostics and related alarms...
  • Page 61 Alarms, errors, and SONET alarms: events Alarm indication signal line (AIS-L) Alarm indication signal path (AIS-P) Bit error rate signal degrade (BERR-SD) Bit error rate signal fail (BERR-SF) Bit interleaved parity (BIP) error B1 Bit interleaved parity (BIP) error B2 Bit interleaved parity (BIP) error B3 Loss of frame (LOF) Loss of pointer (LOP-P)
  • Page 62 M10i Internet Router PIC Guide Table 14: Optical Interface Support for SONET/SDH OC3c/STM1 PICs with SFP (continued) Parameter Multimode Transceiver type Maximum distance MMF cable: 1.2 miles/2 km Standard Multivendor agreement Transmitter wavelength 1270 through 1380 nm Average launch power –20 through –14 dBm Receiver saturation –14 dBm...
  • Page 63 SONET/SDH OC3/STM1 (Multi-Rate) PIC with SFP Software release JUNOS 8.4 and later Description Rate-selectable using one of the following rates: Power requirement: 0.40 A @ 48 V (19 W) Hardware features Multiplexing and demultiplexing Rate policing on input Rate shaping on output Packet buffering, Layer 2 parsing Software features Optical diagnostics and related alarms...
  • Page 64 M10i Internet Router PIC Guide LEDs One tricolor per port: Off Not enabled Green Online with no alarms or failures Amber Online with alarms for remote failures Red Active with a local alarm; router has detected a failure Alarms, errors, and SONET alarms: events SDH alarms:...
  • Page 65 Table 15: Optical Interface Support for SONET/SDH OC3/STM1 (Multi-Rate) PICs with SFP Configured at an OC3/STM1 Rate Parameter Multimode Transceiver model SFP-OC3-SR number Optical interface Multimode Transceiver type Maximum distance MMF cable: 1.2 miles/2 km Standard Multivendor agreement Transmitter wavelength 1270 through 1380 nm Average launch power –20 through –14 dBm...

  • Page 66: Sonet/Sdh Oc12C/Stm4 Pic

    M10i Internet Router PIC Guide SONET/SDH OC12c/STM4 PIC Software release JUNOS 6.1 and later Description One port Power requirement: 0.23 A @ 48 V (10.8 W) Hardware features Multiplexing and demultiplexing Rate policing on input Rate shaping on output Packet buffering, Layer 2 parsing Software features SONET/SDH framing Link aggregation...
  • Page 67 Alarms, errors, and SONET alarms: events SDH alarms: Errored seconds (ES-S, ES-L, ES-P), far-end errored seconds (ES-LFE, ES-PFE), far-end severely errored seconds (SES-LFE, SES-PFE), far-end unavailable seconds (UAS-LFE, UAS-PFE) Severely errored framing (SEF), severely errored framing seconds (SEFS-S), severely errored seconds (SES-S, SES-L, SES-P), unavailable seconds (UAS-L, UAS-P) Table 17: Optical Interface Support for SONET/SDH OC12c/STM4 PICs Parameter Intermediate Reach...
  • Page 68 M10i Internet Router PIC Guide Table 17: Optical Interface Support for SONET/SDH OC12c/STM4 PICs (continued) Parameter Intermediate Reach Standard Telcordia GR-253 Maximum distance SMF cable: 9.3 miles/15 km Transmitter 1274 through 1356 nm wavelength Average launch power –15 through –8 dBm Receiver saturation –8 dBm Receiver sensitivity...
  • Page 69 SONET/SDH OC12/STM4 (Multi-Rate) PIC with SFP Software release JUNOS 8.4 and later Description Rate-selectable using one of the following rates: Power requirement: 0.20 A @ 48 V (9.5 W) Hardware features Multiplexing and demultiplexing Rate policing on input Rate shaping on output Packet buffering, Layer 2 parsing Software features Optical diagnostics and related alarms...
  • Page 70 M10i Internet Router PIC Guide LEDs One tricolor per port: Off Not enabled Green Online with no alarms or failures Amber Online with alarms for remote failures Red Active with a local alarm; router has detected a failure Alarms, errors, and SONET alarms: events SDH alarms:...
  • Page 71 Table 18: Optical Interface Support for SONET/SDH OC12/STM4 (Multi-Rate) PICs with SFP Configured at an OC3/STM1 Rate Parameter Multimode Transceiver model SFP-OC3-SR number Optical interface Multimode Transceiver type Maximum distance MMF cable: 1.2 miles/2 km Standard Multivendor agreement Transmitter wavelength 1270 through 1380 nm Average launch power –20 through –14 dBm...

  • Page 72: Sonet/Sdh Oc48C/Stm16 Pic With Sfp

    M10i Internet Router PIC Guide SONET/SDH OC48c/STM16 PIC with SFP Software release JUNOS 6.4 and later Description One OC48 port Power requirement: 0.86 A @ 48 V (41.4 W) Hardware features Multiplexing and demultiplexing on the 1-port PIC Rate policing on input Rate shaping on output Packet buffering, Layer 2 parsing Software features...
  • Page 73 LEDs One tricolor per port: Off Not enabled Green Online with no alarms or failures Amber Online with alarms for remote failures Red Active with a local alarm; router has detected a failure Alarms, errors, and SONET alarms: events Alarm indication signal line (AIS-L) Alarm indication signal path (AIS-P) Bit error rate signal degrade (BERR-SD) Bit error rate signal fail (BERR-SF)
  • Page 74 M10i Internet Router PIC Guide Table 20: Optical Interface Support for SONET/SDH OC48c/STM16 PICs with SFP Parameter Short Reach (SR) Optical interface Single-mode Transceiver type Maximum distance SMF cable: 1.24 miles/2 km Standard Telcordia GR-253 Transmitter 1266 through 1360 nm wavelength Average launch power –10 through –3 dBm...
  • Page 75 T1 PIC Software release JUNOS 6.1 and later Description Four T1 ports Power requirement: 0.08 A @ 48 V (3.7 W) Supports clear channel T1 per port (1.544 Mbps per channel) Supports attenuation up to –12 dBm Hardware features Per-port loop timing Onboard DSU functionality for T1 connectivity Software features ESF and SF framing...

  • Page 76: Tunnel Services Pic

    M10i Internet Router PIC Guide Tunnel Services PIC Software release JUNOS 6.1 and later Description Power requirement: 0.07 A @ 48 V (3.4 W) Hardware features Loopback function that encapsulates and de-encapsulates packets SONET/SDH OC12/STM4 tunneling bandwidth Software features For a list of the software features available for services PICs, see the JUNOS Services Interfaces Configuration Guide.

  • Page 77: High Availability Features

    Appendix A High Availability Features High availability features include Routing Engine redundancy, graceful Routing Engine switchover (GRES), nonstop bridging, nonstop active routing, graceful restart for routing protocols, Virtual Router Redundancy Protocol (VRRP), and unified in-service software upgrade (ISSU). Some high availability features are not supported by all platforms and all PICs.
