- Page 1 KVM switch and rackmount screen technology User Manual 20” LCD 1152 x 900 Native Resolution SP-120 1U SUN LCD Drawer Options : - DC power Designed and manufactured by Austin Hughes UM-CV-751-SP-120-Q117V1 www.austin-hughes.com...
- Page 2 Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.
- Page 3 Contents < Part. 1 > SP-120 Package Content Structure Diagram & Dimension P.1 - 2 Installation < Part. 2 > Specifi cations / OSD Product Specifi cations P.4 - 5 On-screen Display Operation ( OSD ) P.6 - 7 < Part. 3 > Options DC Power : 12V / 24V / 48V / 125V / 250V UM-CV-751-SP-120-Q117V1...
- Page 4 Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content.
- Page 5 < Part 1 > < 1.1 > Package Content SP-120 SP-120 unit X 1 - 6ft VGA cable X 1 - Power cord X 1 - M6 screw, cage nut & cup washer X 8 The above package content is only for the pure model ( VGA and DVI-D only ). It varies with options such as DC power.
- Page 6 < 1.2 > Dimension Front View Rear View DVI-D Power UNIT : mm Side View 1mm = 0.03937 inch Top View Product Dimension Packing Dimension Gross Model (W x D x H) (W x D x H) Weight Weight 439.6 x 650 x 44 mm 595 x 860 x 140 mm 13.5 kg 17.5 kg...
- Page 7 < 1.3 > Installation - How to install 1U 20" LCD Tray SP-120 Step ■ Attach the left and right mounting bracket to Rear side rack 19" mounting rails. Right bracket ■ Adjust the mounting bracket to fi t your rack. ■...
- Page 8 < Part 2 > < 2.1 > Product Specifi cations Manufacturer Panel Panel Size ( diagonal ) 20-inch TFT color LCD 1152 x 900 ( Direct ) Display pixel ( dots x lines ) 1600 x 1200 ( Native ) Brightness ( typ.
- Page 9 SP-120 Product ( W x D x H ) 439.6 x 650 x 44 mm Physical Specifi cation 17.3 x 25.6 x 1.73 inch Packing ( W x D x H ) 595 x 860 x 140 mm 23.4 x 33.9 x 5.5 inch Net Weight 13.5 kgs / 29.7 lbs Gross Weight...
- Page 10 < 2.2 > On-screen Display Operation ( OSD ) Membrane Switch Function Turn the monitor on or off Display the OSD menu Act as an Enter key to select screen setting options Scroll through menu options and adjust the displayed control Exit the OSD screen Go back to the previous on-screen sub-menu or main menu...
- Page 11 < 2.2 > On-screen Display Operation ( OSD ) SP-120 OSD Confi guration Page Image: for the brightness, contrast, color temp, red, green, and blue Geometry: for the auto adjust, H position, V position, phase and clock Video: for the colour, tint, sharpness, noise reduction, DCDi and TV Setup Audio: for volume, bass, treble, balance, AVL and mute Misc:...
- Page 12 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2017 Austin Hughes Electronics Ltd. All rights reserved. UM-CV-751-SP-120-Q117V1 www.austin-hughes.com...
