Step 2: Configure IP Address
i. Select the
"Name" field
from the default
IP address row
of
ET-8KPn-MTCP
ii. Click the
Configuration
(UDP) button to
open the setting
dialog
iii. Configure the IP
settings
iv. Click the OK
button to save
the
configuration
5

Inserting and Wiring the I/O Modules

There are various types of I/O expansion modules for interfacing many
different field devices to the ET-8KPn-MTCP.
For more information about I/O
expansion module, please refer to:
http://www.icpdas.com/products/PAC/xpac/remote_io_support_list.htm
Copyright © 2016 ICP DAS Co., Ltd. All Rights Reserved.
i. Click the Name column of ET-8KPN-MTCP
ii. Click the Configuration (UDP) button
ii. Click the OK button
