Stryker Medical Renaissance 1210 Maintenance Manual

Emergency care and pacu stretcher
Hide thumbs
Table of Contents

Advertisement

Quick Links

Renaissance Series
1210/1211 Emergency Care Stretcher
1710/1711 PACU Stretcher
Maintenance Manual
For stretchers with serial numbers of 9711030047 and above
For Parts or Technical Assistance
800–327–0770

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Renaissance 1210 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Stryker Medical Renaissance 1210

Summary of Contents for Stryker Medical Renaissance 1210

  • Page 1 Renaissance Series 1210/1211 Emergency Care Stretcher 1710/1711 PACU Stretcher Maintenance Manual For stretchers with serial numbers of 9711030047 and above For Parts or Technical Assistance 800–327–0770...

  • Page 2: Table Of Contents

    Table of Contents Introduction Specifications ................Warning / Caution / Note Definition .
  • Page 3 Table of Contents Assembly Drawings and Parts Lists (Continued) Three Position Siderail to Litter Assembly, Fold to Head ........Three Position Siderail Assembly, Fold to Head .
  • Page 4 Table of Contents Assembly Drawings and Parts Lists (Continued) I.V. Holder Assembly ..............Defibrillator Tray Assembly .

  • Page 5: Introduction

    Introduction INTRODUCTION This manual is designed to assist you with the maintenance of the 1210/1211 Emergency Care Stretchers and the 1710/1711 PACU Beds. Read it thoroughly before using the equipment or beginning any mainte- nance on it. SPECIFICATIONS 1210/1211 1710/1711 Maximum Weight Capacity 500 pounds 500 pounds...

  • Page 6: Preventative Maintenance

    Preventive Maintenance CLEANING 1. Hand wash all surfaces of the stretcher with warm water and mild detergent. Dry thoroughly. 2. Clean Velcro AFTER EACH USE. Saturate Velcro with disinfectant and allow disinfectant to evaporate. (Appropriate disinfectant for nylon Velcro should be determined by the hospital.) NOTE Quaternary Germicidal Disinfectants, used as directed, and/or Chlorine Bleach products, typically 5.25% So- dium Hypochlorite in dilutions ranging between 1 part bleach to 100 parts water, and 2 parts bleach to 100...

  • Page 7: Service Information

    Service Information PNEUMATIC FOWLER ADJUSTMENT (OUTSIDE MOUNTED CYLINDERS) Required Tools: 5/32” Hex Allen Wrench 1/2” Open End Wrench Adjustment Procedure: 1. Refer to drawings 1210–31–120 or 1710–31–120 (Pneumatic Fowler Assembly, page 56 or page 58) for parts reference. 2. For easier access, move Fowler to 75 degrees or higher. 3.

  • Page 8: Caster Assembly Replacement

    Service Information CASTER ASSEMBLY REPLACEMENT* Required Tools: 1/8 Roll Pin Punch Drill with 1/8 inch Drill Bit Flat Punch (any size larger than 1/8) Hammer Needle Nose Pliers Floor Jack 3/4 Inch Wrench (2) Wooden Blocks (10 – 12 inches in length) 1 Inch Wrench Torque Wrench (w/ Ft.

  • Page 9: Caster Cover Installation And Removal

    Service Information CASTER COVER INSTALLATION AND REMOVAL Looking through the larger of the two side cut–outs, align cover with axle nut or bolt head, as shown. Double Prongs Push down on the opposite side of the cover until single prong engages with caster horn. Single Prong Top View (Cut–Away) Properly Attached...

  • Page 10: Brake Cam Replacement

    Service Information FOLDDOWN SIDERAIL LATCH ADJUSTMENT (1210 or 1710) Required Tools: 1/8 Hex Allen Wrench WARNING The siderail latch adjustment is pre–set at the factory, and there should not normally be a need for readjust- ment. If adjustment must be done it is important to follow the procedure below. If it is not done properly, injury to the patient or user could occur.

  • Page 11: Brake Ring Replacement

    Service Information BRAKE RING REPLACEMENT Brake Ring Part Number 715–1–61 Required Tools: Phillips Screwdriver String or Bungee Cord Floor Jack, Small Crate (or equiv.) Large Standard Screwdriver 3/32” Allen Wrench 11/16” Socket & Ratchet 5/8” Wrench Needle–Nose Pliers (2) 7/16” Wrenches Procedure: 1.

  • Page 12: Jack Replacement

    Service Information JACK REPLACEMENT (WITHOUT COMPRESSION SPRING) Required Tools: 3/8” Wrench 1/2” Socket 1/2” Wrench Needle–Nosed Pliers Replacement Procedure: 1. Apply stretcher brakes. Raise litter to full up. Raise Fowler to full up and raise siderails. 2. Use a 3/8” wrench to remove the bolt in the litter support tube above black bellows on both ends. 3.

  • Page 13: Hydraulic System Troubleshooting

    Service Information HYDRAULIC SYSTEM TROUBLESHOOTING NOTE Be sure the pedal linkage has been adjusted properly before beginning service on the jacks (see page 10). PROBLEM/SYMPTOM SOLUTION Jack will not raise to full height. Add hydraulic fluid (see p.13). Check for leaks. Jack will not hold in raised position.

  • Page 14: Checking Hydraulic Fluid Level

    Service Information CHECKING HYDRAULIC FLUID LEVEL Required Tools: 3/8 Open End Wrench 3/4 Open End Wrench Procedure: WARNING To avoid personal injury or damage to the stretcher, remove the litter and the base hood before beginning service on the jacks. 1.

  • Page 15: Hydraulic Check Valve Replacement

    Service Information HYDRAULIC CHECK VALVE REPLACEMENT Required Tools: 3/8 Open End Wrench Stiff Wire (with bent, pointed end) Small Needle Nose Pliers 3/4 Open End Wrench Torque Wrench (with Ft. Lbs. adjust.) 7/32 Hex Allen Wrench 1/2 Inch Diameter Rod Replacement of Valve #1 WARNING To avoid personal injury or damage to the stretcher, remove the litter and the base hood before beginning...

  • Page 16: Replacement Of Valve (Poppet) #2

    Service Information HYDRAULIC CHECK VALVE REPLACEMENT (CONT’D) Replacement of Valve (Poppet) #2 WARNING To avoid personal injury or damage to the stretcher, remove the litter and the base hood before beginning service on the jacks. Lower the jack rod completely to relieve the pressure on the pump piston side of the jack.

  • Page 17: Base Lubrication Points

    Service Information BASE LUBRICATION POINTS 1. Lubricate brake adjuster rod around area shown with MPG–2 grease or equivalent. Do not grease area shown...
  • Page 18 3–Sided Control Base Ass’y, Both Sides & Foot End 16.1...
  • Page 19 3–Sided Control Base Ass’y, Both Sides & Foot End...
  • Page 20 3–Sided Control Base Ass’y, Both Sides & Foot End...
  • Page 21 3–Sided Control Base Ass’y, Both Sides & Foot End Item Part No. Part Name Qty. Item Part No. Part Name Qty. 3–4 Hex Hd. Cap Screw 715–1–165 Actuator Plate Ass’y 3–47 Hex Hd. Cap Screw 715–1–192 Jack Support 3–62 Hex Hd. Cap Screw 715–1–193 Jack Support Clamp 3–85...
  • Page 22 3–Sided Control Base Ass’y, Both Sides & Head End 19.1...
  • Page 23 3–Sided Control Base Ass’y, Both Sides and Head End...
  • Page 24 3–Sided Control Base Ass’y, Both Sides and Head End...
  • Page 25 3–Sided Control Base Ass’y, Both Sides and Head End Item Part No. Part Name Qty. Item Part No. Part Name Qty. 3–4 Hex Hd. Cap Screw 715–1–165 Actuator Plate Ass’y 3–47 Hex Hd. Cap Screw 715–1–192 Jack Support 3–62 Hex Hd. Cap Screw 715–1–193 Jack Support Clamp 3–85...
  • Page 26 Notes 22.1...

  • Page 27: 4-Sided Control Base Assembly

    4–Sided Control Base Assembly 22.2...
  • Page 28 Assembly part number 1210–4–10 FOOT END...
  • Page 29 4–Sided Control Base Assembly...
  • Page 30 4–Sided Control Base Assembly Item Part No. Part Name Qty. Item Part No. Part Name Qty. 3–4 Hex Hd. Cap Screw 715–1–165 Actuator Plate Ass’y 3–47 Hex Hd. Cap Screw 715–1–192 Jack Support 3–62 Hex Hd. Cap Screw 715–1–193 Jack Support Clamp 3–85 Hex Hd.

  • Page 31: 715-270-400 Jack Assembly

    715–270–400 Jack Assembly Item Part No. Part Name Qty. Item Part No. Part Name Qty. 45–904 O–Ring 388–1–38 Plug 715–1–340 Cap Assembly 715–1–322 Reservoir 390–1–243 Gasket 390–1–244 Gasket 715–1–323 Actuator Cylinder 390–1–238 Gasket, Actuator 715–1–325 Actuator (Page 27) Jack Base Assembly 45–14 O–Ring 390–2–139...

  • Page 32: 715-1-300 Jack Base Assembly

    715–1–300 Jack Base Assembly Item Part No. Part Name Qty. Item Part No. Part Name Qty. 14–50 Bearing Retainer 715–1–327 Cylinder Wear Ring 38–311 Compression Spring 715–1–328 Piston Wear Ring 45–6 O–Ring 715–1–329 Pump Seal 45–110 O–Ring 715–1–341 Poppet 45–966 O–Ring 715–270–1 45–967...
  • Page 33 1210–70–10 Variable Descent Jack Assembly Item Part No. Part Name Qty. Item Part No. Part Name Qty. 45–904 O–Ring 715–1–422 Reservoir 715–1–340 Cap Assembly 390–1–244 Gasket 390–1–243 Gasket 390–1–238 Gasket, Actuator 1210–70–15 Actuator Cylinder (Page 27.2) Jack Base Assembly 715–1–325 Actuator 390–2–139 Retaining Collar...
  • Page 34 Variable Descent Jack Base Assembly Assembly part number 1210–270–11 (reference only) Item Part No. Part Name Qty. Item Part No. Part Name Qty. 14–50 Bearing Retainer 715–1–328 Piston Wear Ring 38–311 Compression Spring 715–1–329 Pump Seal 45–6 O–Ring 715–1–341 Poppet 45–110 O–Ring 1210–70–14...

  • Page 35: 715-1-150 Brake Adjuster Assembly

    715–1–150 Brake Adjuster Assembly Item Part No. Part Name Qty. 715–1–62 Threaded Stud Assembly 14–4 Nylon Washer 715–1–180 Bearing 28–8 Retaining Ring...

  • Page 36: 715-1-213 Brake Cam Assembly

    715–1–213 Brake Cam Assembly Item Part No. Part Name Qty. 715–1–221 Brake Cam 16–59 Fiberlock Nut 8–21 Soc. Hd. Cap Screw 715–1–173 Brake Connecting Link...
  • Page 37 End Control Pump Pedal Assembly, Head Assembly part number 716–1–292 Item Part No. Part Name Qty. 716–1–285 Pump Pivot, Head End 26–12 Roll Pin 716–1–290 Pump Ped. Wldmt., Head 721–40–25 Pedal End Control Pump Pedal Assembly, Foot Assembly part number 716–1–288 Item Part No.

  • Page 38: Side Release Pedal Assembly, Right

    Side Release Pedal Assembly Assembly part number 1210–1–150 Item Part No. Part Name Qty. 715–1–126 Side Control Pedal Pad 1210–1–152 Side Release Pedal Weldment...
  • Page 39 Pedal Base Assembly, Pump Assembly part number 715–1–108 Item Part No. Part Name Qty. 715–1–83 Pedal Ass’y Weldm’t, Pump 715–1–126 Side Control Pedal Pad 81–44 Bearing, Bronze NOTE Apply plastic adhesive to the mating surfaces of item B prior to assembly.

  • Page 40: 715-2-21 Caster Assembly With Steerlock

    715–2–21 Caster Assembly with Steerlock Item Part No. Part Name Qty. 700–10–50 Steer Lock Caster Weldment 715–2–25 Caster Wheel 16–60 Hex Nut 3–99 Hex Bolt 715–3–96 Hex Bolt 1000–59–10 Latch Assembly 11–310 Flat Washer...

  • Page 41: Caster And Caster Cover Replacement Kits

    Caster and Caster Cover Replacement Kits Item Part No. Part Name Qty. 715–2–20 Caster Assembly 715–1–266 Caster Cover, Left 715–1–265 Caster Cover, Right P/N 715–259–400 – Kit to replace 4 standard caster assemblies with necessary hardware – no caster covers. P/N 715–269–400 –...
  • Page 42 Optional Fifth Wheel Base Assembly Item Part No. Part Name Qty. 3–20 Hex Hd. Cap Screw 16–16 Fiberlock Nut 16–49 Nylock Hex Nut 23–25 Hex Washer Hd. Screw 26–8 Roll Pin 81–219 Bearing (page 35) Fifth Wheel Assembly 715–1–136 Fifth Wheel Spring 715–1–149 715–1–157 Fifth Wheel Bearing...
  • Page 43 Notes 34.2...

  • Page 44: Fifth Wheel Assembly

    715–1–25 Fifth Wheel Assembly Item Part No. Part Name Qty. 715–1–339 Fifth Wheel Pivot Assembly 715–1–17 Fifth Wheel Bushing 16–11 Flexlock Nut 715–1–15 Spring 715–1–13 Fifth Wheel Bracket 16–12 Flexlock Nut 390–1–54 Wheel 3–31 Hex Head Cap Screw 3–82 Hex Head Cap Screw...

  • Page 45: 3-Sided Base Graphics, Foot End Control

    3–Sided Base Graphics, Foot End Control Assembly part numbers 1210–750–10 thru 1210–750–70 Item Part No. Part Name Qty. 1210–750–9 Head End Brake/Steer Label 1210–800–9 Renaissance Series Label 1210–45–25 Base Hood 946–1–60 Stryker Logo Label 715–1–134 Bellows 1210–1–17 Specification Label 1211–1–17 Specification Label 1710–1–17 Specification Label...

  • Page 46: 3-Sided Base Graphics, Head End Control

    3–Sided Base Graphics, Head End Control Assembly part numbers 1210–800–10 thru 1210–800–70 Item Part No. Part Name Qty. 1210–750–9 Head End Brake/Steer Label 1210–800–9 Renaissance Series Label 1210–750–8 Foot End Brake/Steer Label 1210–45–25 Base Hood 946–1–60 Stryker Logo Label 715–1–134 Bellows 1210–1–17 Specification Label...

  • Page 47: 4-Sided Base Graphics

    4–Sided Base Graphics Assembly part numbers 1210–850–10 thru 1210–750–10 Item Part No. Part Name Qty. 1210–800–9 Renaissance Series Label 1210–45–25 Base Hood 715–1–134 Bellows 1210–1–17 Specification Label 1211–1–17 Specification Label 1710–1–17 Specification Label 1711–1–17 Specification Label Color Item A Control Item C Control Item D Control Item E Control...

  • Page 48: Litter Assembly

    Litter Assembly Assembly part number 1210–30–10 Item Part No. Part Name Qty. Item Part No. Part Name Qty. 3–47 Hex Hd. Cap Screw 926–400–142 Bumper Wheel 3–50 Hex Hd. Cap Screw 938–1–401 Collar 3–54 Hex Hd. Cap Screw 1001–1–37 Jack Supt. Tube, Head 3–76 Hex Hd.
  • Page 49 Litter Assembly Assembly part number 1710–30–10 Item Part No. Part Name Qty. Item Part No. Part Name Qty. 3–47 Hex Hd. Cap Screw 926–400–142 Bumper Wheel 3–50 Hex Hd. Cap Screw 938–1–401 Collar 3–54 Hex Hd. Cap Screw 1001–1–37 Jack Supt. Tube, Hd. 3–76 Hex Hd.

  • Page 50: Three Position Siderail To Litter Assembly, Fold To Foot

    Three Position Siderail to Litter Assembly, Fold to Foot Assembly part number 1210–21–10 Item Part No. Part Name Qty. 4–135 But. Hd, Cap Screw 4–136 But. Hd. Cap Screw 11–2 Flat Washer 16–28 Nylock Nut 21–104 Set Screw 25–38 Pop Rivet 37–74 Hole Plug 38–220...
  • Page 51 Three Position Siderail Ass’y, Rt. & Lt., Fold to Foot Assembly part numbers 1210–26–16 (Right) & 1210–26–18 (Left) (Right Side is Shown) Item Part No. Part Name Qty. 25–106 Semi–Tubular Rivet 1010–26–10 Round Hole Plug 1010–26–12 Bent Spindle Rest 1010–26–15 Top Rail 1010–26–82 Sleeve Bearing...

  • Page 52: Three Position Siderail To Litter Assembly, Fold To Head

    Three Position Siderail to Litter Assembly, Fold to Head Assembly part number 1210–20–10 Item Part No. Part Name Qty. 4–135 But. Hd, Cap Screw 4–136 But. Hd. Cap Screw 11–2 Flat Washer 16–28 Nylock Nut 21–104 Set Screw 25–38 Pop Rivet 37–74 Hole Plug 38–220...
  • Page 53 Three Position Siderail Ass’y, Rt. & Lt., Fold to Head Assembly part number 1210–26–16 (Right) & 1210–26–18 (Left) (Right Side is Shown) Item Part No. Part Name Qty. 1010–26–15 Top Rail 1010–26–83 Upright 1010–26–84 Upright, Bent 1010–26–82 Sleeve Bearing 25–106 Semi–Tubular Rivet 1010–26–10 Round Hole Plug...

  • Page 54: Two Position Siderail To Litter Assembly, Fold To Foot

    Two–Position Siderail to Litter Assembly, Fold to Foot Assembly part number 1009–21–10 Item Part No. Part Name Qty. 4–135 But. Hd, Cap Screw 4–136 But. Hd. Cap Screw 11–2 Flat Washer 16–28 Nylock Nut 21–104 Set Screw 37–74 Hole Plug 38–220 Compression Spring 721–26–66...
  • Page 55 Two Position Siderail Ass’y, Right & Left, Fold to Foot Assembly part numbers 721–26–96 (Right) & 721–26–97 (Left) (Right Side Shown) Item Part No. Part Name Qty. 1010–26–15 Top Rail 1010–26–83 Upright 1010–26–84 Upright, Bent 1010–26–82 Spacer 25–106 Semi–Tubular Rivet 1010–26–10 Round Hole Plug 1010–26–85...

  • Page 56: Two Position Siderail To Litter Assembly, Fold To Head

    Two Position Siderail to Litter Assembly, Fold to Head Assembly part number 1009–20–10 Item Part No. Part Name Qty. 4–135 But. Hd, Cap Screw 4–136 But. Hd. Cap Screw 11–2 Flat Washer 16–28 Nylock Nut 21–104 Set Screw 37–74 Hole Plug 38–220 Compression Spring 721–26–66...
  • Page 57 Two Position Siderail Ass’y, Right & Left, Fold to Head Assembly part numbers 1010–26–17 (Right) & 1010–26–19 (Left) (LEFT SIDERAIL IS SHOWN) Item Part No. Part Name Qty. 1010–26–15 Top Rail 1010–26–83 Upright 1010–26–84 Upright, Bent 1010–26–82 Sleeve Bearing 25–106 Semi–Tubular Rivet 1010–26–10 Round Hole Plug...

  • Page 58: Litter Assembly

    Litter Assembly Assembly part number 1211–30–10 Item Part No. Part Name Qty. Item Part No. Part Name Qty. 3–40 Hex Hd. Cap Screw 721–32–107 Roller Sleeve 3–47 Hex Hd. Cap Screw 919–30–28 Rack Guide 3–50 Hex Hd. Cap Screw 926–400–142 Bumper Wheel 3–54 Hex Hd.
  • Page 59 Litter Assembly Assembly part number 1211–30–10 Item Part No. Part Name Qty. Item Part No. Part Name Qty. 3–40 Hex Hd. Cap Screw 721–32–107 Roller Sleeve 3–47 Hex Hd. Cap Screw 919–30–28 Rack Guide 3–50 Hex Hd. Cap Screw 926–400–142 Bumper Wheel 3–54 Hex Hd.

  • Page 60: Siderail To Litter Assembly, Fold To Head

    Siderail to Litter Assembly, Fold to Head Assembly part number 1211–20–10 Item Part No. Part Name Qty. Item Part No. Part Name Qty. 3–78 Hex Hd. Cap Screw 16–36 Nylock Nut 4–161 But. Hd. Cap Screw 37–200 Vinyl Sleeve 4–169 But.

  • Page 61: Siderail To Litter Assembly, Fold To Foot

    Siderail to Litter Assembly, Fold to Foot Assembly part number 1211–21–10 Item Part No. Part Name Qty. Item Part No. Part Name Qty. 3–78 Hex Hd. Cap Screw 25–79 Pop Rivet 4–161 But. Hd. Cap Screw 37–200 Vinyl Sleeve 4–169 But.
  • Page 62 Glideaway Siderail Assembly, Right Assembly part number 1001–26–10 Item Part No. Part Name Qty. 1001–26–40 Top Rail, Right 1001–226–41 Upright, Plated, Right (page 54.1) Ring Spacer Assembly 1010–26–82 Sleeve Bearing 721–26–69 Upright Sleeve 123–20–52 Spindle Plug 25–114 Semi–Tubular Rivet 1001–226–31 Lock Upright Ass’y, Rt.
  • Page 63 Glideaway Siderail Assembly, Left Assembly part number 1001–26–11 Item Part No. Part Name Qty. 1001–26–30 Top Rail, Left 1001–226–42 Upright, Plated, Left (page 54.1) Ring Spacer Assembly 1010–26–82 Sleeve Bearing 721–26–69 Upright Sleeve 123–20–52 Spindle Plug 25–114 Semi–Tubular Rivet 1001–226–33 Lock Upright Ass’y, Left 1001–226–38 Upright Assembly, Left...
  • Page 64 Siderail Ring Spacer Assembly Assembly part number 1001–26–39 (reference only) Item Part No. Part Name Qty. 4–169 Socket Button Hd. Cap Screw 16–3 Hex Nut 1001–26–32 Ring Spacer 54.1...
  • Page 65 Notes 54.2...
  • Page 66 Pneumatic Fowler to Frame Assembly Assembly part number 1210–31–10 Item Part No. Part Name Qty. 4–182 But. Hd. Cap Screw 4–183 But. Hd. Cap Screw 11–179 Nylon Washer 14–21 Nylon Washer 16–11 Nylock Hex Nut 16–35 Nylock Hex Nut 23–100 Self–Tapping Screw 25–50 Pop Rivet...

  • Page 67: Pneumatic Fowler Assembly

    Pneumatic Fowler Assembly (Fiberresin) Assembly part number 1210–31–120 Item Part No. Part Name Qty. 4–161 Hex Soc. But. Hd. Cap Screw 7–20 Truss Hd. Mach. Screw 25–124 Pop Rivet 15–37 Jam Nut 15–50 Hex Nut 16–28 Nylock Nut 21–125 Set Screw 21–126 Set Screw 1001–1–36...
  • Page 68 Pneumatic Fowler to Frame Assembly Assembly part number 1710–31–10 Item Part No. Part Name Qty. 4–182 But. Hd. Cap Screw 4–183 But. Hd. Cap Screw 11–179 Nylon Washer 14–21 Nylon Washer 16–11 Nylock Hex Nut 16–35 Nylock Hex Nut 23–100 Self–Tapping Screw 25–50 Pop Rivet...
  • Page 69 Pneumatic Fowler Assembly (Fiberresin) Assembly part number 1710–31–120 Item Part No. Part Name Qty. 4–161 Hex Soc. But. Hd. Cap Screw 7–20 Truss Hd. Mach. Screw 25–124 Pop Rivet 15–37 Jam Nut 15–50 Hex Nut 16–28 Nylock Nut 21–125 Set Screw 21–126 Set Screw 1001–1–36...
  • Page 70 Outer Housing Assembly, Right and Left Assembly part number 1210–31–106 (Right) Item Part No. Part Name Qty. 25–144 Semi–Tubular Rivet 1210–31–103 Pivot Tab 1210–31–104 Outer Housing, Right Assembly part number 1210–31–107 (Left) Item Part No. Part Name Qty. 25–144 Semi–Tubular Rivet 1210–31–103 Pivot Tab 1210–31–105...
  • Page 71 Pneumatic Fowler to Frame Assembly Assembly part number 1211–31–10 Item Part No. Part Name Qty. 3–199 Hex Hd. Cap Screw 4–183 But. Hd. Cap Screw 11–179 Washer 16–11 Nylock Hex Nut 16–86 Nylock Hex Nut 25–50 Pop Rivet 25–124 Pop Rivet 52–284 Nylon Spacer 1010–31–78...
  • Page 72 Pneumatic Fowler Assembly (Fiberresin) Assembly part number 1211–31–20 Item Part No. Part Name Qty. 3–200 Hex Hd. Cap Screw 4–135 But. Hd. Cap Screw 7–20 Truss Hd. Mach. Screw 11–132 Nylon Washer 15–37 Jam Nut 15–50 Hex Nut 16–28 Nylock Nut 21–119 Set Screw 21–126...
  • Page 73 Pneumatic Fowler to Frame Assembly Assembly part number 1711–31–10 Item Part No. Part Name Qty. 3–199 Hex Hd. Cap Screw 4–183 But. Hd. Cap Screw 11–179 Washer 16–11 Nylock Hex Nut 16–86 Nylock Hex Nut 25–50 Pop Rivet 25–124 Pop Rivet 52–284 Nylon Spacer 1010–31–78...
  • Page 74 Pneumatic Fowler Assembly (Fiberresin) Assembly part number 1711–31–20 Item Part No. Part Name Qty. 3–200 Hex Hd. Cap Screw 4–135 But. Hd. Cap Screw 7–20 Truss Hd. Mach. Screw 11–132 Nylon Washer 15–37 Jam Nut 15–50 Hex Nut 16–28 Nylock Nut 21–119 Set Screw 21–126...
  • Page 75 Crank Fowler Assembly (Fiberresin) Assembly part number 1210–33–10 Item Part No. Part Name Qty. Item Part No. Part Name Qty. 4–97 Hex But. Hd. Cap Screw 25–50 Pop Rivet 4–183 But. Hd. Cap Screw 946–1–64 Fowler Operation Label 1 7–20 Truss Hd.

  • Page 76: Crank Fowler Assembly

    Crank Fowler Assembly (Fiberresin Assembly part number 1710–33–10 Item Part No. Part Name Qty. Item Part No. Part Name Qty. 4–97 Hex But. Hd. Cap Screw 25–50 Pop Rivet 4–183 But. Hd. Cap Screw 946–1–64 Fowler Operation Label 1 7–20 Truss Hd.

  • Page 77: Fowler Crankscrew Assembly

    Fowler Crankscrew Assembly Assembly part numbers 1001–33–25 & 1501–33–25 Item Part No. Part Name Qty. 1001–33–26 Drive Bar Assembly 1501–33–26 Drive Bar Assembly 1550–1–16 Crank Assembly 946–33–18 Crank Disc 938–1–177 Knob 16–5 Kep Nut 378–24–29 Shoulder Bolt 946–33–35 Fowler Screw 26–14 Roll Pin 81–174...

  • Page 78: Stationary Foot Section Assembly

    Stationary Foot Section Assembly (Fiberresin) Assembly part numbers 1010–332–20 & 1510–332–20 HEAD END Item Part No. Part Name Qty. 1010–332–21 Footsection Skin, Fiberresin (24”) 1 1510–332–21 Footsection Skin, Fiberresin (29”) 1 7900–1–102 Velcro Pile 24 1/2” 25–50 Pop Rivet...
  • Page 79 Stationary Foot End Assembly (Steel) Assembly part number 1010–232–20 Item Part No. Part Name Qty. 1010–232–21 Ftsec. Skin, Fiberresin 7900–1–102 Velcro Pile 24 1/2” 25–122 Pop Rivet 66.1...
  • Page 80 Stationary Foot End Assembly (Steel) Assembly part number 1001–132–20 Item Part No. Part Name Qty. 25–122 Pop Rivet 1001–132–21 Footsection Skin (Steel) 7900–1–102 Velcro Pile 24 1/2” 66.2...
  • Page 81 Stationary Foot End Assembly (Steel) Assembly part number 1501–132–20 Item Part No. Part Name Qty. 25–122 Pop Rivet 1501–132–21 Footsection Skin (Steel) 7900–1–102 Velcro Pile 24 1/2” 66.3...
  • Page 82 Stationary Foot End Assembly (Steel) Assembly part number 1510–232–20 Item Part No. Part Name Qty. 1510–232–21 Ftsec. Skin, Fiberresin 7900–1–102 Velcro Pile 24 1/2” 25–122 Pop Rivet 66.4...

  • Page 83: Knee Gatch Assembly

    Knee Gatch Assembly Assembly part number 1010–434–20 Item Part No. Part Name Qty. Item Part No. Part Name Qty. 3–47 Hex Hd. Cap Screw 721–31–65 Litter Hole Plug (not shown) 2 3–76 Hex Hd. Cap Screw 946–1–65 Label, Gatch Symbol 4–105 Soc.
  • Page 84 Knee Gatch Assembly (Fiberresin) Assembly part number 1010–534–10 Frame Assembly (Ref.) Item Part No. Part Name Qty. (page 67) Knee Gatch Assembly 1010–334–27 Midsection Skin (Fiberresin) 1010–334–28 Thigh Skin (Fiberresin) 1010–334–126 Calf Skin (Fiberresin) 25–50 Pop Rivet...
  • Page 85 Crank Knee Gatch Assembly (Steel) Assembly part number 1010–434–10 Frame Assembly (Ref.) Item Part No. Part Name Qty. (page 67) Knee Gatch Assembly 1010–234–27 Midsection Skin 1010–234–28 Thigh Skin 1010–234–126 Calf Skin 25–122 Pop Rivet 68.1...
  • Page 86 Crank Knee Gatch Assembly (Steel) Assembly part number 1510–434–10 Frame Assembly (Ref.) Item Part No. Part Name Qty. (page 69) Knee Gatch Assembly 1510–234–27 Midsection Skin 1510–234–28 Thigh Skin 1510–234–126 Calf Skin 25–122 Pop Rivet 68.2...
  • Page 87 Knee Gatch Assembly Assembly part number 1510–434–20 Item Part No. Part Name Qty. Item Part No. Part Name Qty. 3–47 Hex Hd. Cap Screw 721–31–65 Litter Hole Plug (not shown) 2 3–76 Hex Hd. Cap Screw 946–1–65 Label, Gatch Symbol 4–105 Soc.
  • Page 88 Knee Gatch Assembly (Fiberresin) Assembly part number 1510–534–10 Frame Assembly (Ref.) Item Part No. Part Name Qty. (page 69) Knee Gatch Assembly 1510–334–27 Midsection Skin (Fiberresin) 1510–334–28 Thigh Skin (Fiberresin) 1510–334–126 Calf Skin (Fiberresin) 25–50 Pop Rivet...
  • Page 89 Knee Gatch Assembly Assembly part number 1211–34–20 Item Part No. Part Name Qty. Item Part No. Part Name Qty. 3–47 Hex Hd. Cap Screw 1001–34–29 Slider Supt. Wldmt., Lt. 4–105 Soc. Hd. Cap Screw 1001–34–30 Slider Supt. Wldmt., Rt. 7–20 Truss Hd.
  • Page 90 Knee Gatch Assembly (Fiberresin) Assembly part number 1211–34–10 Item Part No. Part Name Qty. (page 71) Knee Gatch Assembly 1010–334–27 Midsection Skin (Fiberresin) 1010–334–28 Thigh Skin (Fiberresin) 1010–334–126 Calf Skin (Fiberresin) 25–50 Pop Rivet...
  • Page 91 Crank Knee Gatch Assembly (Steel) Assembly part number 1001–134–10 Item Part No. Part Name Qty. (page 71) Knee Gatch Assembly 1001–134–27 Midsection Skin 1010–234–28 Thigh Skin 1010–234–126 Calf Skin 25–122 Pop Rivet 72.1...
  • Page 92 Crank Knee Gatch Assembly (Steel) Assembly part number 1501–134–10 Item Part No. Part Name Qty. (page 73) Knee Gatch Assembly 1501–134–27 Midsection Skin 1510–234–28 Thigh Skin 1510–234–126 Calf Skin 25–122 Pop Rivet 72.2...
  • Page 93 Knee Gatch Assembly Assembly part number 1711–34–20 Item Part No. Part Name Qty. Item Part No. Part Name Qty. 3–47 Hex Hd. Cap Screw 1001–34–29 Slider Supt. Wldmt., Lt. 4–105 Soc. Hd. Cap Screw 1001–34–30 Slider Supt. Wldmt., Rt. 7–20 Truss Hd.
  • Page 94 Knee Gatch Assembly, Fiberresin Assembly part number 1711–34–10 Item Part No. Part Name Qty. (page 73) Knee Gatch Assembly 1510–334–27 Midsection Skin (Fiberresin) 1510–334–28 Thigh Skin (Fiberresin) 1510–334–126 Calf Skin (Fiberresin) 25–50 Pop Rivet...

  • Page 95: Knee Gatch Crankscrew Assembly

    Knee Gatch Crankscrew Assembly Assembly part number 1001–34–19 Item Part No. Part Name Qty. 946–33–18 Crank Disk 1550–1–16 Crank Assembly 26–45 Roll Pin 26–14 Roll Pin 81–176 Thrust Washer 81–175 Thrust Bearing 81–174 Thrust Washer 938–1–175 Bearing Assembly 938–1–177 Knob 378–24–29 Shoulder Bolt 16–5...

  • Page 96: Transfer System To Litter Assembly

    Transfer System to Litter Assembly Assembly part number 1210–132–3 HEAD END Item Part No. Part Name Qty. 2–100 Pan Hd. Screw 3–50 Hex Hd. Cap Screw 3–78 Hex Hd. Cap Screw 10–11 Eye Bolt 11–180 Washer 15–28 Jam Nut 16–3 Fiberlock Nut 16–28 Fiberlock Nut...

  • Page 97: Short Transfer System Assembly, Right

    Short Transfer System Assembly, Right Assembly part number 1010–232–10 Shaft End (Ref.) Item Part No. Part Name Qty. 1020–32–100 Transfer Board Ass’y 721–24–46 Label 1010–32–98 Pivot 1010–224–33 Connecting Link Ass’y, Rt. 1010–232–16 Pivot Arm Ass’y, Right 28–93 Retaining Ring 3–50 Hex Hd.

  • Page 98: Short Transfer System Assembly, Left

    Short Transfer System Assembly, Left Assembly part number 1010–232–11 Item Part No. Part Name Qty. 1020–32–100 Transfer Board Ass’y 721–24–46 Label 1010–32–98 Pivot 1010–224–33 Connecting Link Ass’y 1010–232–17 Pivot Arm Ass’y, Lt. 28–93 Retaining Ring 3–50 Hex Hd. Cap Screw 11–224 Nylon Flat Washer 14–21...

  • Page 99: Transfer System To Litter Assembly

    Transfer System to Litter Assembly Assembly part number 1211–132–3 Item Part No. Part Name Qty. 3–199 Hex Hd. Cap Screw 11–4 Washer 16–86 Nylock Nut (page 80) Transfer System Ass’y, Lt. (page 81) Transfer System Ass’y, Rt.

  • Page 100: Transfer System Assembly, Left

    Transfer System Assembly, Left Assembly part number 1211–132–7 Item Part No. Part Name Qty. 4–169 But. Hd. Cap Screw 11–350 Washer 14–7 Washer 16–3 Fiberlock Nut 16–28 Fiberlock Nut 26–6 Roll Pin 26–233 Roll Pin (page 82) Transfer Board Assembly 1211–132–11 Transfer Bd.

  • Page 101: Transfer System Assembly, Right

    Transfer System Assembly, Right Assembly part number 1211–132–8 Item Part No. Part Name Qty. 4–169 But. Hd. Cap Screw 11–350 Washer 14–7 Washer 16–3 Fiberlock Nut 16–28 Fiberlock Nut 26–6 Roll Pin 26–233 Roll Pin (page 82) Transfer Board Assembly 1211–132–12 Transfer Bd.

  • Page 102: Transfer Board Assembly

    Transfer Board Assembly Assembly part number 1211–132–9 Item Part No. Part Name Qty. 25–125 Pop Rivet 25–126 Pop Rivet 1211–132–4 Transfer Board 1211–132–17 Transfer Bd. Sleeve Wldmt. 1211–132–19 Stiffener Weldment...

  • Page 103: Board Support Assembly

    Board Support Assembly Assembly part number 1010–24–30 Item Part No. Part Name Qty. 1010–24–15 Support Block 1010–24–16 Support Arm 1010–24–14 Warning Label 38–263 Spring 8–17 Shoulder Bolt 1010–26–46 Ball Knob...

  • Page 104: Foot End Steering Handles Assembly

    Foot End Steering Handles Assembly Assembly part number 1210–151 Litter Frame Item Part No. Part Name Qty. 3–47 Hex Hd. Cap Screw 3–50 Hex Hd. Cap Screw 3–54 Hex Hd. Cap Screw 7–20 Truss Hd. Mach. Screw 16–28 Nylock Nut 23–104 Self–Tapping Screw 26–11...
  • Page 105 Foot End Steering Handles Assembly Assembly part number 1211–151 Item Part No. Part Name Qty. 3–50 Hex Hd. Cap Screw 3–47 Hex Hd. Cap Screw 3–54 Hex Hd. Cap Screw 16–28 Nylock Nut 23–69 Self–Tapping Screw 23–104 Self–Tapping Screw 26–11 Roll Pin 1211–30–34 Cover, Hole/Slot...

  • Page 106: Push Handle Assembly

    Push Handle Assembly Assembly part number 1211–151–10 Item Part No. Part Name Qty. 26–10 Roll Pin 1010–254–24 Stop Link 1211–151–18 Sleeve Assembly...

  • Page 107: Head End Steering Handles Assembly

    Head End Steering Handles Assembly Assembly part number 1711–151 Item Part No. Part Name Qty. 26–11 Roll Pin (page 86) Push Handle Assembly...

  • Page 108: Foot End Corner Assembly W/O Steering Handles

    Foot End Corner Assembly w/o Steering Handles Assembly part number 1210–153 Item Part No. Part Name Qty. 23–104 Self–Tapping Screw 1010–201–238 Corner, Slot 1010–201–239 Corner, Hole...
  • Page 109 Foot End Corner Assembly, w/o Steering Handles Assembly part number 1211–153 Item Part No. Part Name Qty. 23–69 Self–Tapping Screw 23–104 Self–Tapping Screw 1211–30–38 Corner, Slot 1211–30–39 Corner, Hole...
  • Page 110 2– Stage I.V. Mounting Assembly Assembly part numbers 1010–280 & 1010–281 1510–280 & 1510–281 Item 1010 P/N Part Name Qty. (page 94) I.V. Pole Assembly 1001–259–5 I.V. Receptacle Ass’y 16–28 Lock Nut 3–54 Hex Hd. Cap Screw 4–91 But. Hd. Cap Screw 3–50 Hex Hd.
  • Page 111 Notes...
  • Page 112 Notes...
  • Page 113 2–Stage I.V. Mounting Assembly Assembly part numbers 1211–110 (Head End) – 1211 1211–112 (Foot End) – 1211 1711–110 (Head End) – 1711 1711–112 (Foot End) – 1711 Item Part No. Part Name Qty. 3–50 Hex Hd. Cap Screw 4–91 But. Hd. Cap Screw 16–20 Flexlock Nut 16–28...

  • Page 114: 2-Stage I.v. Pole Assembly

    2–Stage I.V. Pole Assembly Assembly part number 1211–110–10 Item Part No. Part Name Qty. 1001–59–32 Base Tube Assembly 1001–59–31 Extension Tube Assembly 1210–110–47 Lock Ring 1210–110–49 Lock Actuator 14–20 Nylon Flat Washer As Req’d 1010–59–16 I.V. Hook 52–17 Nylon Spacer 926–400–62 Stop Sleeve 1211–110–46...
  • Page 115 Notes...

  • Page 116: 3-Stage I.v. Mounting Assembly (1210 & 1710)

    3–Stage I.V. Mounting Assembly Assembly part numbers 1010–61 (Head) & 1010–62 (Foot) 1510–61 (Head) & 1510–62 (Foot) Item Part No. Part Name Qty. (page 97 , 98) I.V. Pole Assembly 1001–259–5 I.V. Receptacle Assembly 16–28 Lock Nut 3–54 Hex Hd. Cap Screw 4–91 But.

  • Page 117: 3-Stage I.v. Pole Assembly

    3–Stage I.V. Pole Assembly Assembly part number 1010–61–10 Item Part No. Part Name Qty. 1010–61–24 Base Tube Assembly (page 99) 2nd Stage Assembly (page 100) 3rd Stage Assembly 26–6 Roll Pin 7–4 Truss Hd. Mach. Screw 52–17 Nylon Spacer 1010–59–16 I.V.
  • Page 118 3–Stage I.V. Pole Assembly Assembly part number 1510–61–10 Item Part No. Part Name Qty. 1010–61–24 Base Tube Assembly (page 99) 2nd Stage Assembly (page 100) 3rd Stage Assembly 26–6 Roll Pin 7–4 Truss Hd. Mach. Screw 52–17 Nylon Spacer 1010–59–16 I.V.

  • Page 119: 2Nd Stage Assembly

    2nd Stage Assembly Assembly part number 1010–61–25 Item Part No. Part Name Qty. 1010–61–30 2nd Tube Assembly 1210–110–46 Back–Up Ring 1210–110–47 Lock Ring 1210–110–49 Lock Actuator...

  • Page 120: 3Rd Stage Assembly

    3rd Stage Assembly Assembly part number 1010–61–20 Item Part No. Part Name Qty. 38–303 Spring 1010–61–13 Ball Retainer 1010–61–15 Stop Nut 1010–61–16 Retaining Shaft 1010–61–17 Thumb Knob 1010–61–18 Hand Guard 1010–61–19 3rd Extension Rod 31–21 Ball...

  • Page 121: 3-Stage I.v. Mounting Assembly (1211 & 1711)

    3–Stage I.V. Mounting Assembly Assembly part numbers 1211–111 (Head End) 1211–113 (Foot End) 1711–111 (Head End) 1711–113 (Foot End) Litter Frame FOOT END Litter Frame HEAD END Item Part No. Part Name Qty. 3–50 Hex Hd. Cap Screw 4–91 But. Hd. Cap Screw 16–20 Flexlock Nut 16–28...

  • Page 122: 3-Stage I.v. Pole Assembly

    3–Stage I.V. Pole Assembly Assembly part number 1211–111–10 Item Part No. Part Name Qty. 1001–61–34 Base Tube Assembly (page 104) 2nd Stage Assembly (page 105) 3rd Stage Assembly 26–6 Roll Pin 7–4 Truss Hd. Mach. Screw 52–17 Nylon Spacer 1010–59–16 I.V.
  • Page 123 3–Stage I.V. Pole Assembly Assembly part number 1711–111–10 Item Part No. Part Name Qty. 1010–61–34 Base Tube Assembly (page 104) 2nd Stage Assembly (page 105) 3rd Stage Assembly 26–6 Roll Pin 7–4 Truss Hd. Mach. Screw 52–17 Nylon Spacer 1010–59–16 I.V.

  • Page 124: 2Nd Stage Assembly

    2nd Stage Assembly Assembly part number 721–61–25 Item Part No. Part Name Qty. 721–61–30 2nd Tube Assembly 1210–110–46 Back–Up Ring 1210–110–47 Lock Ring 1210–110–49 Lock Actuator...

  • Page 125: 3Rd Stage Assembly

    3rd Stage Assembly Assembly part number 1001–61–120 Item Part No. Part Name Qty. 38–303 Spring 1010–61–23 Ball Retainer 1010–61–15 Stop Nut 1010–61–16 Retaining Shaft 1010–61–17 Thumb Knob 1010–61–18 Hand Guard 1001–61–119 3rd Extension Rod 31–21 Ball...

  • Page 126: Tethered I.v. Pole Mounting Assembly

    Tethered I.V. Pole Mounting Assembly Assembly part number 1001–87–20 Item Part No. Part Name Qty. (page 108) Trough Assembly (page 107) I.V. Pole Assembly 34–22 Cord Clamp 25–79 Pop Rivet 4–85 Soc. Hd. Cap Screw 16–3 Nylock Nut...

  • Page 127: Tethered I.v. Pole Assembly

    Tethered I.V. Pole Assembly Assembly part number 1001–87–18 Item Part No. Part Name Qty. (page 109) I.V. Holder 1010–22–27 Cable Assembly 741–47–14 Retainer 21–16 Set Screw...

  • Page 128: Tethered I.v. Pole Trough Assembly

    Tethered I.V. Pole Trough Assembly Assembly part number 1001–87–22 Item Part No. Part Name Qty. 1001–87–23 Machined Sleeve 1001–87–16 Front Mounting Bracket 1001–87–15 Mounting Bracket Ass’y 1–22 Flat Hd. Mach Screw 37–2 Tube Plug 946–40–110 Lock Clip 16–14 Dynalock Hex Nut...

  • Page 129: I.v. Holder Assembly

    I.V. Holder Assembly Assembly part number 721–47–6 Item Part No. Part Name Qty. 938–1–305 Pole Socket Assembly 938–1–308 Pole Assembly 24–53 Knob...
  • Page 130 Tethered I.V. Pole Mounting Assembly Assembly part number 1210–117 HEAD END Item Part No. Part Name Qty. 4–66 Soc. Hd. Cap Screw 11–16 Washer 16–3 Fiberlock Nut 25–79 Rivet 34–22 Cable Clamp 1001–59–41 I.V. Plug (page 109.2) Tethered I.V. Pole Assembly 1211–117–21 Backing Plate 1211–117–22...
  • Page 131 Tethered I.V. Pole Assembly Assembly part number 1211–117–10 Item Part No. Part Name Qty. 4–232 Button Hd. Cap Screw 14–20 Nylon Washer 24–53 Knob 52–17 Spacer 926–400–62 Stop Sleeve 1010–22–27 Cable Assembly 1010–59–16 I.V. Hook 1211–117–11 Extension Rod 109.2...
  • Page 132 1211–117–12 Base Tube Weldment 109.3...

  • Page 133: Defibrillator Tray Assembly

    Defibrillator Tray Assembly Assembly part number 926–39–10 Item Part No. Part Name Qty. Item Part No. Part Name Qty. 946–39–4 Tray 926–1–82 Label 926–39–16 Crosstube 390–57–12 Long Strap 25–55 Rivet 390–57–13 Short Strap 926–39–9 Cover 946–1–283 Label 18–6 Umbrella Nut 926–39–15 Holder 29–8...

  • Page 134: Foot Board/Chartholder Assembly

    Foot Board/Chartholder Assembly Assembly part number 926–40–10 Item Part No. Part Name Qty. 946–28–11 Chart Holder 946–29–6 Foot Board Upright Oxygen Bottle Holder Assembly Item Part No. Part Name Qty. 1020–30–11 Upright Bottle Holder 27–12 Cotter Pin 1020–30–17 Specification Label...

  • Page 135: C-Spine Cassette Holder Assembly

    C–Spine Cassette Holder Assembly Assembly part number 1001–70–1 Item Part No. Part Name Qty. 1010–70–25 I.V. Adaptor 1010–70–18 Specification Label 11–3 Flat Washer 4–91 Soc. Hd. Cap Screw (page 113) Support Pole Assembly (page 114) Storage Bracket Ass’y 16–5 Conelock Nut 3–50 Hex Hd.

  • Page 136: C-Spine Support Pole Assembly

    C–Spine Support Pole Assembly Assembly part number 1010–70–10 View A–A Item Part No. Part Name Qty. 1010–70–33 Support Tube Cap 26–6 Roll Pin 1010–70–34 Support Arm Weldment 1010–70–42 Cassette Holder Weldment 1010–70–50 Adjustment Tube Weldment 1010–70–30 Base Tube Weldment 1010–70–45 Knob 25–55 Pop Rivet...

  • Page 137: C-Spine Storage Bracket Assembly

    C–Spine Storage Bracket Assembly Assembly part number 1010–70–19 6.5” (Ref.) 2” (Ref.) Item Part No. Part Name Qty. 1010–70–20 Storage Bracket Weldment 1010–70–45 Knob 1010–70–23 Storage Label...

  • Page 138: Heel Stirrup And Support Assembly

    Heel Stirrup and Support Assembly Assembly part number 1001–55–10 Item Part No. Part Name Qty. (Page 116) Rt. Stirrup Support Ass’y (Page 117) Lt. Stirrup Support Ass’y (Page 118) Stirrup Assembly 22–8 Drive Screw 3–78 Hex Head Cap Screw 16–28 Nylock Hex Nut 11–158 Flat Washer...

  • Page 139: Right Stirrup Support Assembly

    Right Stirrup Support Assembly Assembly part number 1001–55–15 Item Part No. Part Name Qty. 1010–55–16 Right Support Tube Ass’y 1001–55–11 Mounting Bracket 650–2–32 Lock Screw Assembly 966–51–19 Wedge Lock, Modified 38–171 Compression Spring 26–7 Roll Pin 14–40 Nylon Flat Washer 24–11 Knob...

  • Page 140: Left Stirrup Support Assembly

    Left Stirrup Support Assembly Assembly part number 1001–55–16 Item Part No. Part Name Qty. 1010–55–26 Left Support Tube Ass’y 1001–55–11 Mounting Bracket 650–2–32 Lock Screw Assembly 966–51–19 Wedge Lock, Modified 38–171 Compression Spring 26–7 Roll Pin 14–40 Nylon Flat Washer 24–11 Knob...

  • Page 141: Heel Stirrup Assembly

    Heel Stirrup Assembly Assembly part number 1001–55–29 Item Part No. Part Name Qty. 390–20–13 Stirrup 390–20–9 Stirrup Holder Assembly 1010–55–30 Extension Tube Assembly 24–11 Knob 26–43 Roll Pin 22–8 Drive Screw...
  • Page 142 Foot Extension/Defibrillator Tray Ass’y Assembly part number 1010–50–210* Label Detail Label Detail Item Part No. Part Name Qty. Item Part No. Part Name Qty. 8–49 Socket Hd. Shoulder Bolt 1010–50–50 Knob 14–20 Nylon Washer 1010–50–57 “Max. Weight” Label 14–21 Nylon Washer 1010–50–205 Cushion Assembly 16–28...

  • Page 143: Fowler X-Ray Cassette Assembly (1210 & 1710)

    Fowler X–Ray Cassette Assembly (1210 & 1710) Assembly part number 1001–23–10 Item Part No. Part Name Qty. 1001–23–12 Tray 1020–23–16 Post Housing 1001–23–14 Actuating Rod 926–23–64 Post 1010–23–37 Rod Guide 1020–23–21 Knob 1010–23–28 Tray Angle 926–23–70 Block Assembly 926–23–69 Washer 14–3 Washer 38–122...

  • Page 144: X-Ray Cassette Mounting Assembly

    X–Ray Cassette Mounting Assembly Item Part No. Part Name Qty. (page 120) X–Ray Cassette Ass’y 16–3 Self–Locking Nut 4–149 Button Hd. Cap Screw 1001–23–13 Tray Latch 1020–23–13 Tray Hinge, Right 1020–23–12 Tray Hinge, Left 25–69 Pop Rivet...
  • Page 145 X–Ray Cassette Assembly Assembly part numbers 1211–143–20 & 1711–143–20 Item Part No. Part Name Qty. 1–20 Flat Hd. Mach. Screw 14–3 Thrust Washer 926–23–69 Washer 926–23–70 Block Assembly 926–23–71 Bushing 1010–23–18 Warning Label 1010–23–28 Tray Angle 1020–23–21 Knob Assembly 1211–143–12 X–Ray Cassette Tray 1711–143–12 X–Ray Cassette Tray...
  • Page 146 X–Ray Cassette to Fowler Assembly Assembly part number 1211–143–10 & 1711–143–10 Item Part No. Part Name Qty. 25–124 Pop Rivet (page 122) X–Ray Cassette Assembly...

  • Page 147: Accessory Rail Assembly

    Accessory Rail Assembly Assembly part number 1210–136 Item Part No. Part Name Qty. 3–47 Hex Hd. Cap Screw 8–15 Shoulder Bolt 16–28 Nylock Hex Nut 1068–66–42 Option Bar Rail 1068–266–50 Mounting Bracket Weldment...

  • Page 148: Replacement Parts

    Replacement Parts 1210 Parts PART NAME PART NUMBER 3” Low Friction Mattress ............1059–326–140 4”...
  • Page 149 Replacement Parts 1211 Parts PART NAME PART NUMBER 3” Low Friction Mattress ............1059–326–140 4”...
  • Page 150 Replacement Parts 1710 Parts PART NAME PART NUMBER 3” Low Friction Mattress ............1059–329–140 4”...
  • Page 151 Replacement Parts 1711 Parts PART NAME PART NUMBER 3” Low Friction Mattress ............1059–329–140 4”...

  • Page 152: Limited Warranty

    Warranty Limited Warranty: Stryker Medical Division, a division of Stryker Corporation, warrants to the original purchaser that its products should be free from defects in material and workmanship for a period of one (1) year after date of delivery. Stryker’s obligation under this warranty is expressly limited to supplying replacement parts and labor for, or replacing, at its option, any product which is, in the sole discretion of Stryker, found to be defective.

  • Page 153: Return Authorization

    Warranty Return Authorization: Merchandise cannot be returned without approval from the Stryker Customer Service Department. An autho- rization number will be provided which must be printed on the returned merchandise. Stryker reserves the right to charge shipping and restocking fees on returned items. SPECIAL, MODIFIED, OR DISCONTINUED ITEMS NOT SUBJECT TO RETURN.
  • Page 154 6300 Sprinkle Road, Kalamazoo, MI 49001–9799 (800) 327–0770 DH 10/97 1210–90–3 REV Q...

This manual is also suitable for:

Renaissance 1211Renaissance 1710Renaissance 17119711030047

Table of Contents
