7. PROGRAMMING OF COFFEE DOSAGE

7.1. PROGRAMMING PROCEDURES
Programming is done on the group 1 (left group), the 5 keys are defined as follows:
2 ways of programming are possible to set the coffee dose.
➢ Choose 1st group (on the left when the user is in front of the machine)
o To program the right group at the same time with the same value.
o The programmed key will have its equivalent key programmed identically on the right
group
➢ Choose the right group separately, if the groups need to have different value.
Methodology:
 Put the ground coffee (1 dose or 2 doses according to the programmed key), in the suitable filter holder.
 Press the key n°5 "P5 Gr1" from the selected group during 10 seconds, until it's blinking.
 Release the key n°5 "P5 Gr1"
 The operation can start in a delay of 10 seconds. Otherwise it go back from the programming mode.
 Press the key to be programmed to start the flow, and press again when water quantity is correct. The
value is directly registered.
 Then, continue programming the next key within 10 seconds, and so on for the other keys.
 Wait 10 seconds to escape from the programming mode, and then you can use machine normally.
Note : On the factory, each machine undergoes a test protocol on which a program has already been
completed, according to the following settings:
1 espresso = 2,5 cl / 2 espressos = 5 cl / 1 coffee = 4,5 cl / 2 coffee = 9 cl
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
P1 Gr1 P2 Gr1
1shot 2shots
espresso espresso
Edition 05/2021 - COMPACT - technical documentation - page 9
P3 Gr1 P4 Gr1
1regular 2regular continuous
coffee coffee
P5 Gr1
flow
