MC
TECHNICAL DOCUMENTATION
Edition 05/2021
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Monaco MC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Conti Monaco MC

Summary of Contents for Conti Monaco MC

  • Page 1 TECHNICAL DOCUMENTATION Edition 05/2021 SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.

  • Page 2: Table Of Contents

    TECHNICAL DOCUMENTS ..................4 DIMENSIONS ......................4 CAUTION DURING THE USE ..................5 Ambient conditions During installation During the use Rules relating to the environment INSTALLATION ......................6 Standby (standby = 2 months): Protections Water supply Drain Supplying voltage Water softeners FIRST INSTALLATION ....................
  • Page 3 10.1 ECO MODE (general) 10.2 Programming on general display 10.3 First level menu 10.4 Language 10.5 Clock adjustement 10.6 Installation 10.7 Adjustements 10.8 Maintenance 10.9 Technical parameters 10.10 Coffee Counters 10.11 Accessibility COFFEE TEMPERATURE ADJUSTMENTS ..............43 QUALITY CRITERIA ....................44 STEAM CONTROL PRODUCTS ADJUSTMENTS ............

  • Page 4: Technical Documents

    1 TECHNICAL DOCUMENTS Total Steam boiler Coffee boiler Group Outlet power Capacity Power Capacity Power Power Power Number Number (liter) (liter) MC 2G 4200 1000 6700 MC 3G 6000 1000 9600 MC 2G K 6000 2500 11500 MC 3G K 6000 2500 14100...

  • Page 5: Caution During The Use

    3.2 During installation The installation (electrical connections, water supply and drainage) must be carried out by a  qualified technician approved by CONTI. The machine must be connected to a device conforming to the standards of the country where the ...

  • Page 6: Installation

    INSTALLATION Standby (standby = 2 months): The first thing to do is to test your machine in a lab.  If the machine stops running for a long time, you could have sediment in some places.  More precisely in small area like the spray nozzle. ...

  • Page 7: Water Softeners

    4.6 Water softeners  When the mains water has a high hardness (>10°TH ou >4 °KH), it is recommended: o To use a water treatment o To regenerate regularly the filters.  What is the total Hardness of the water? o This is the amount of calcium and magnesium ions in the water.

  • Page 8: First Installation

    5 FIRST INSTALLATION A. Open the water supply tap B. Switch on the machine using the switch under the drip tray. ON/OFF Switch C. During 1 second The general display shows the software version “Monte Carlo 2.18”. MC 2.18 D. According the situation the display shows: Please Push “where you want"...
  • Page 9 2° step: Press 3° step: Press 4° step: The display shows : Press 3 times: F. The display shows: Installation First Install First Install First Install First Install In progress Let the machine doing the 1° installation. During this time, the air inside coffee groups are automatically vacuum by an opening cycle of vacuum valves, pump and groups valves.
  • Page 10 G. The process is finished when the display shows: First Install Installation Press Press H. The display shows : Edition 05/2021 - MC – Technical documentation - page 10 SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.

  • Page 11: Starting & Warm Up

    6 STARTING & WARM UP A. Switch ON the machine by pressing on the main display.  B. The keyboards are lighting, and shows the coffee boilers temperature settings Please 95°C 95°C wait! Coffee buttons are blinking. General display blinking C.
  • Page 12 F. Main display  When the machine is ready, the general display shows: Digital manometer M1 Digital manometer M2 Boiler pressure (MPa) network or pump pressure (MPa) Level information  Press “where you want” on the display, during 3 sec to switch the machine ...

  • Page 13: How To Use The Machine

    7 HOW TO USE THE MACHINE 7.1 Operating elements STEAM FUNCTION  Two steams tap levers « V » are provided to allow:  The heating of liquids by spraying steam.  The milk foam production to create Cappuccino or Macchiato. The liquid to be heated should preferably be placed in a deep container.

  • Page 14: How To Use The Programmed Doses

    FILTERS  The machine is equipped with two types of filters: 1 cup (10 G) and 2 cups (18 G) Each filter is operating with its own holder-filter to produce respectively 1 cup or 2 cups of coffee. Filters need to be unclogged and clean, so they need to be cleaned almost once a day with hot water, by being removed from the holder filters.

  • Page 15: Coffee Groups

    8 COFFEE GROUPS 8.1 Mode menu Press the "Menu/Enter" button to enter in the programming mode. The "Esc" button is used to escape from the programming mode. MENU ENTER 95°C ORMAL MODE " " MENU MENU Coffee boiler T° Group temperature MENU MENU Dose setting...
  • Page 16 A) COFFEE BOILER TEMPERATURE Coffee boiler T° ENTER Coffee boiler T° Coffee boiler T° 94°C 95°C Press "menu" to validate and "ESC" to escape B) GROUP TEMPERATURE Group temperature ENTER Group temperature Group temperature 89°C 88°C Press "menu" to validate and "ESC" to escape C) DOSE SETTING All the leds are Dose setting...

  • Page 17: Group Eco Mode

    D) SOFT-INFUSION Programming a closing time of the coffee circuit during the extraction beginning. During that time a low pression is applied on the coffee grounds. Soft EXTRACTION Time Soft-infusion MENU Soft-Infusion To adjust the closing time of the soft-infusion valve Espresso 3.0 sec MENU...

  • Page 18: Programming Doses Methodology

    9 PROGRAMMING DOSES METHODOLOGY 9.1 Coffee doses programming: MENU ENTER 95°C 2 ways of programming are possible to set the coffee dose.  Choose 1st group (on the left when the user is in front of the machine) o To program all groups at the same time with the same value. o The programmed key will have its equivalent key programmed identically on the other groups ...

  • Page 19: Hot Water Dose Programming

    9.2 Hot water dose programming: «Hot water» key «Hot water» key Methodology: One programming dose is available for each outlet:  Press key the “MENU” from the coffee group nearest the outlet to be programmed.  The display show “Coffee boiler T” ...

  • Page 20: General Display

    10 GENERAL DISPLAY 10.1 ECO MODE (general) Press the eco button for eco mode The entire machine goes in eco mode. The steam boiler is maintained at 60°C. Products can’t be extracted. To come back on the main menu, press "where you want" on the display for 3 seconds. 10.2 Programming on general display Press the menu button for 5 seconds...

  • Page 21: First Level Menu

    10.3 First level menu Language To choose language Clock adjust To adjust the clock and the auto on/off Installation About the machine technical installation Adjustements To adjust the extraction settings Maintenance Help for the maintenance Technical Par. Access to technical parameters Counters Beverages counters menu Accessibility...

  • Page 22: Language

    10.4 Language Language Language English To change the language To validate Next step Available languages: French / English / Italian / Spanish / German / Portuguese 10.5 Clock adjustement 10.5.1 Date/time Set clock 14/02/14 16:49 Set clock To adjust the value 05/01/15 16:49 To validate and proceed...
  • Page 23 10.5.2 Auto on/off Auto ON/OFF Auto ON/OFF To select Yes or No To validate If No If Yes To adjust the value 08:00 18h00 To validate and proceed Time from which the machine switches ON automatically OFF: Time from which the machine switches OFF automatically Next step Closed ON To select the day of closure...

  • Page 24: Installation

    10.6 Installation 10.6.1 First install First install See chapter: First installation Next step 10.6.2 Power boiler Boiler Power Boiler Power To select the value Range: 1 to 6 To validate Next step This step is to define the maximum power supply available for the machine. Example: 2 ...
  • Page 25 10.6.4 Pressure calibration V. Th. 9.0 bar Pressure calibr. V. Cor. 9.0 bar To adjust the value To validate This menu allows to adjust the value shown by digital manometer according the value shown by the mechanical manometer Adjusting method: Press .
  • Page 26 10.6.7 Service Service cycles Service To adjust the value Range: 0 to 99900 Next step This menu allows the machine to display a message for a service after a programmed number of cycle (example 20000 cycles) If value = 0  not used 10.6.8 Water Filter Water Filter Water Filter...

  • Page 27: Adjustements

    10.7 Adjustements 10.7.1 Coffee boiler temperature Coffee Boiler T. Coffee Boiler T. To adjust the value 95°C Range: 80 to 95 °C (the temperature shown is the setting T° of the left group) (the chosen setting temperature is validated for all the groups) Next step To validate Temperature Gr...
  • Page 28 10.7.2 Steam boiler temperature Temp. Boiler Temp. Boiler To adjust the value 123°C Range: 80 to 125 °C To validate Next step To adjust the value 0.04 10,0 To validate and proceed For next step PID setting To adjust the value 5°C Range: 2 to 5°C To validate...
  • Page 29 10.7.4 Quality Criteria Quality Criteria ESP Criteria (ml/s) min 1,5 max 2,2 To adjust the value for espresso Adjustable value from 0,5 to 6 To validate KF Criteria (ml/s) min 2,5 max 4,5 Next step To adjust the value for coffee Adjustable value from 0,5 to 6 To validate 10.7.5 Steam Control...
  • Page 30 10.7.6 Viewing This menu allows to define: The type of coffee or group temperatures to be displayed The information to be displayed during extraction + ou – to change the value Temperature Temp display « Setting / Actual / Average Coffee boiler Setting √...
  • Page 31  Choice of the viewing type during the extraction: If the user chooses “Time / Volume” (default value): The viewing during the extraction is this one (@ represents cups logos)  2Cafés @ @ YYYml If the user chooses “Time / Volume / Flow” The viewing during the extraction is this one: ...

  • Page 32: Maintenance

    10.8 Maintenance 10.8.1 Exhibition mode Mode exposition Mode exposition To select Range: Yes / No If Yes If No EXPO Next step The machine remains in exposition mode: No filling up tanker No heating up boiler No doses available To come back on normal menu: Go into the menu and select “No” in the exposition mode step 10.8.2 Cold Mode Cold mode Cold mode...
  • Page 33 10.8.3 Diagnostics The menu allows supplying and testing separately all the outlets: Output Diagnostic On / Off Press to activate the outlet Press to disable the outlet For the next Outlets : Next step Steam 1: XXX °C (Real temperature read in the steam boiler) Steam 2: XXX °C (Real temperature read in the steam boiler) Steam 3: XXX °C...
  • Page 34 10.8.4 Filters Alarm Reset Filters Alarm Reset Filters Alarm Reset To select To validate To escape To change Filtres Reset Alarme To select To validate To escape To validate 10.8.5 Service Alarm Reset Service Alarm Reset Service Alarm Reset To select To validate To escape To change...
  • Page 35 10.8.6 Reset Reset Reset To select Range: Yes / No If Yes If No Data Reset To select Yes or No Completed Next step To validate To validate Switch OFF and switch ON the machine. The machine is reset. The menu allows to set the factory setting inside the machine Machine version = 2G and coffee model Power 2 10.8.7 Alarm history...

  • Page 36: Technical Parameters

    10.9 Technical parameters 10.9.1 Unit of measurements Temperature Unit of measure °C To select Value : °C / °F To validate Next step 10.9.2 Filling up time out Filling up time out Filling up time out 360s To adjust the value Range: till 360s To validate Next step...
  • Page 37 10.9.5 Probe sensitivity Probe Sensitivity Probe Sensitivity To select Range: MIN / MID / MAX To validate 10.9.6 Machine Version N. group Machine version To select the group 2 or 3 group To validate Machine version Coffee To select Next step Coffee / steam control To validate This is to configure the machine in 2 or 3 groups and in coffee or steam control model.
  • Page 38 10.9.1 Pulse filter Pulse filter Pulse filter Activated To select To validate Pulse filter activated: the machine uses the specific Monte Carlo dose counting Pulse filter disactivated: the machine counts the water goes through the flowmeter for the dose 10.9.2 Display Mode Display Display To select...
  • Page 39 10.9.1 Lighting This step allows choosing if during the functioning of the machine the “side white leds” are “switch off” or “switch on”. Lighting Lighting To select Range: Yes / No Next step When the machine ON: YES: The lights are ON The lights are OFF The lights are always “OFF”...

  • Page 40: Coffee Counters

    10.10 Coffee Counters Espresso Coffee counters 1589 Press to know the amount of each product To see the other counters: Next step For example: Espresso: 2 espressos: 391 Coffee: 31 2 Coffee: Continuous: Tea: Milk: Steam: Total coffee: 874 (not resettable) Edition 05/2021 - MC –...

  • Page 41: Accessibility

    10.11 Accessibility 10.11.1 Programmation groups Prog. groupes Prog. groups Activated To select To validate To escape To change Prog. groupes Disactivated To select To validate To escape To validate If disabled: there is no possibility for the user to access to the coffee group menu. 10.11.2 Dose setting Dose setting Dose setting...
  • Page 42 10.11.1 Lock out code Lock out code Lock out code Disactivated To select Value : Activated / Disactivated To validate Next step It is possible to lock out completely the menu thanks a lock out code. By default, the lock out code is disactivated.

  • Page 43: Coffee Temperature Adjustments

     Concerning the abacus above, these values are given in an indicative way, following the regulation and the especial protocol of the CONTI company. These can change according to the type of coffee used, as well as the environment of the machine.

  • Page 44: Quality Criteria

    12 QUALITY CRITERIA  Quality criteria programming: First, the user may choose his own quality criteria. These are the acceptable minimum and maximum flow rates for the estimated product. + or – to change the value Quality Criteria ESP Value (ml/s) «...

  • Page 45: Steam Control Products Adjustments

    13 STEAM CONTROL PRODUCTS ADJUSTMENTS How to adjust “hot milk” or “milk foam” product: By “auto learning” Using the nearest coffee keypad menu from the steam control: Use keypad n° 2 on a 2 groups machine Use keypad n° 3 on a 3 groups machine MENU ENTER 95°C...

  • Page 46: Maintenance Of Machines

    The automatic cleaning process of the group is started in 3 steps: o The process is shown on the display. o The machine asks for blind hold filter and the CONTI cleaning pill code n°466662 o Follow the instructions on the display.
  • Page 47  ANNUAL MAINTENANCE:  A kit n° 450201, for the following operation is available for sale.  Change the pump inlet filter (No. 411861)  On the steam boiler: o Change vaccum valve (No. 408898) o Change the safety valve (No. 411827) ...
  • Page 48  BIENNAL MAINTENANCE:  A kit n° 450201, for the following operation is available for sale.  Change the pump inlet filter (No. 411861)  On the steam boiler: o Change vacuum valve (No. 408898) o Change the safety valve (No. 411827) o Dismantle and clean the injectors ...

  • Page 49: Electric Drawing

    CODE COULEURS FILS CABLE COLOUR CODE 15 ELECTRIC DRAWING marron brown bleu blue rouge violet violet 15.1 CPU board standard orange orange gris grey jaune yellow blanc white vert green noir black Edition 05/2021 - MC – Technical documentation - page 49 SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.

  • Page 50: Cpu Board Steam Control

    CODE COULEURS FILS 15.2 CPU board Steam Control CABLE COLOUR CODE marron brown bleu blue rouge violet violet orange orange gris grey jaune yellow blanc white vert green noir black Edition 05/2021 - MC – Technical documentation - page 50 SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.

  • Page 51: Electrical Power Diagram For "400V 3L N Pe

    15.3 Electrical power diagram for “400V 3L N PE” Edition 05/2021 - MC – Technical documentation - page 51 SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.

  • Page 52: Electrical Power Diagram For "230 V 1L N Pe

    15.4 Electrical power diagram for “230 V 1L N PE” Edition 05/2021 - MC – Technical documentation - page 52 SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.

  • Page 53: Connecting Diagram: 12 Fuses Box

    15.5 Connecting diagram: 12 fuses box CODE COULEURS FILS CABLE COLOUR CODE marron brown rouge orange orange jaune yellow vert green bleu blue violet violet gris grey blanc white noir black Edition 05/2021 - MC – Technical documentation - page 53 SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
  • Page 54 CODE COULEURS FILS CABLE COLOUR CODE marron brown rouge orange orange jaune yellow vert green bleu blue violet violet gris grey blanc white noir black Edition 05/2021 - MC – Technical documentation - page 54 SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
  • Page 55 CODE COULEURS FILS CABLE COLOUR CODE marron brown rouge orange orange jaune yellow vert green bleu blue violet violet gris grey blanc white noir black Edition 05/2021 - MC – Technical documentation - page 55 SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
  • Page 56 CODE COULEURS FILS CABLE COLOUR CODE marron brown rouge orange orange jaune yellow vert green bleu blue violet violet gris grey blanc white noir black Edition 05/2021 - MC – Technical documentation - page 56 SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.

  • Page 57: Solid State Relay Interface For "400 V 3Nac

    15.6 Solid state relay interface for “400 V 3NAC” Edition 05/2021 - MC – Technical documentation - page 57 SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.

  • Page 58: Low Voltage Wiring

    15.7 Low voltage wiring Edition 05/2021 - MC – Technical documentation - page 58 SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.

  • Page 59: Hydraulic Scheme

    16 HYDRAULIC SCHEME Edition 05/2021 - MC – Technical documentation - page 59 SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
  • Page 60 Edition 05/2021 - MC – Technical documentation - page 60 SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.

  • Page 61: Alarm

    ALARM CODE Description Faults Recommendations - Check the probe - Coffee boiler 1 t° probe in Coffee boiler 1 probe alarm short-circuit or - Check the probe connection disconnected. - Check the electronic board - Check the probe - Coffee boiler 2 t° probe in Coffee boiler 2 probe alarm short-circuit or - Check the probe connection...
  • Page 62 - Check the t° probe - Check the probe connection - Check the electronic board - Time allocated to the coffee Coffee boiler 1 time out alarm boiler 1 heating exceeded. - Check the heater and the relay - Check the programmed heating time - Check the relay control box - Check the t°...
