3

OPERATING INSTRUCTIONS

3.1

EPC500ST SPECIFICATIONS

Info: All dimensions are specified in [millimeters] and inches. Unless otherwise noted, all
dimensions are ± [10 mm] .375 in. Dual dimensions are minimum (left) and maximum (right)
when shown in chair position, and opposite — maximum (left) and minimum (right) when
shown in Trendelenburg position.
DO NOT USE
LEG EXTENSION
IN CHAIR MODE
470
18.5
(FULLY RETRACTED)
65°
90°
191 / 686
7.5 / 27.0
Home position, side view
1207
47.5
EPC500ST-INS-LAB-RevA21
106°
5°
38
1.5
1308
51.5
Home Position - Side View
673 / 470
26.5 / 18.5
15°
Trendelenburg position, side view
(Back Range
From Horizontal
0 to 90 )
1270 / 1765
50.0 / 69.5
495 / 991
19.5 / 39.0
1994 / 1791
78.5 / 70.5
799
31.5
629
24.75
674
26.5
699
27.5
Home position, front view
546
381
21.5
15.0
242
9.5
546 / 1042
21.5 / 41.0
