Table 1: Termination Details
Type of Field Device
Current Input - Internal Source
(3 wire)
Current Input - External
Source (in Loop)
Feedback from EPP-1000
Dry Contact (Binary Input)
0–10 VDC Output to Actuator
(External Source)
0–10 VDC Output to Actuator
(Internal Source)
IOU4710 Input/Output Module Installation Instructions
Type of
Termination Diagrams
Input/Output
UI
UI
UI
UI or BI
CO or AO
CO or AO
8
