Table 8: IOU4710-0U Technical Specifications
Communications Bus
Processor
Memory
Input and Output Capabilities
Analog Input/Analog Output Resolution
and Accuracy
Terminations
Mounting
Housing
Dimensions(Height x Width x Depth)
Weight
Compliance
The performance specifications are nominal and conform to acceptable industry standard. For application at conditions
beyond these specifications, consult the local Johnson Controls® office. Johnson Controls shall not be liable for
damages resulting from misapplication or misuse of its products.
IOU4710 Input/Output Module Installation Instructions
BACnet® MS/TP, RS-485:
3-wire FC Bus between the supervisory controller and other controllers
4-wire SA bus between controller, network sensors and other sensor/actuator devices,
includes a lead to source 15 VDC supply power (from controller) to bus devices.
H8SX/166xR Renesas® 32-bit microcontroller
512 KB Flash Memory and 128 KB Random Access Memory (RAM)
6 - Universal Inputs: Defined as 0–10 VDC, 4–20 mA, 0–600k ohm, or Binary Dry
Contact
2 - Binary Inputs: Defined as Dry Contact Maintained or Pulse Counter/Accumulator
Mode
3 - Binary Outputs: Defined as 24 VAC Triac (selectable internal or external source
power)
4 - Configurable Outputs: Defined as 0–10 VDC or 24 VAC/DC Field-Effect
Transistor (FET) BO
2 - Analog Outputs: Defined as 0–10 VDC or 4–20 mA
Input: 16-bit resolution
Output: 16-bit resolution, +/- 200 mV accuracy in 0-10 VDC applications
Input/Output: Fixed Screw Terminal Blocks
SA/FC Bus and Supply Power: 4-Wire and 3-Wire Pluggable Screw Terminal Blocks
SA/FC Bus Port: RJ-12 6-Pin Modular Jacks
Horizontal on single 35 mm DIN rail mount (preferred), or screw mount on flat surface
with three integral mounting clips on controller
Enclosure material: ABS and polycarbonate UL94 5VB; Self-extinguishing, Plenum
Rated
150 x 190 x 53 mm (5-7/8 x 7-1/2 x 2-1/8 in.) including terminals and mounting clips
Note: Mounting space requires an additional 50 mm (2 in.) space on top, bottom
and front face of controller for easy cover removal, ventilation and wire terminations.
0.5 kg (1.1 lb)
United States: UL Listed, File E107041, CCN PAZX, UL 916, Energy Management
Equipment; FCC Compliant to CFR47, Part 15, Subpart B, Class A
UL Listed, File S4977, UL 864 UUKL/UUKLC 10th Edition Listed, Smoke Control
Units and Accessories for Fire Alarm Systems Equipment
Canada: UL Listed, File E107041, CCN PAZX7 CAN/CSA C22.2 No.205, Signal
Equipment; Industry Canada Compliant, ICES-003
UL Listed, File S4977, UL 864 UUKL/ORD-C100-13 10th Edition Listed, Smoke
Control Units and Accessories for Fire Alarm Systems
Europe: Johnson Controls declares that this product is in compliance with the
essential requirements and other relevant provisions of the EMC Directive.
Note: Conducted RF Immunity within EN 61000-6-2 meets performance criteria B.
Australia and New Zealand: RCM Mark, Australia/NZ Emissions Compliant
BACnet International: BACnet Testing Laboratories (BTL) Protocol Revision 4
Listed BACnet Application Specific Controller (B-ASC)
