Troubleshooting the Controllers
Observe the Status LEDs on the front of the controller and see
Table 6: Status LEDs and Descriptions of LED States
LED Label LED Color
POWER Green
FAULT Red
SA/FC BUS Green
EOL Amber
Accessories
See Table 7 for controller accessories ordering information.
Table 7: Accessories Ordering Information
Product Code Number
PAN-PWRSP-U
NS Series Network Sensors

Technical Specifications

Table 8: IOU4710-0U Technical Specifications
Product Code Number
Supply Voltage
Power Consumption
Ambient Conditions
Addressing
IOU4710 Input/Output Module Installation Instructions
Normal LED Description of LED States
State
On Steady Off Steady = No Supply Power or the controller's polyswitch/resettable fuse
is open. Check Output wiring for short circuits and cycle power to controller.
On Steady = Power Connected
Off Steady Off Steady = No Faults
On Steady = Device Fault; no application loaded; Main Code download
required, if controller is in Boot mode, or a firmware mismatch exists between
the controller and the ZFR1811 Wireless Field Bus Router.
Blink - 2 Hz = Download or Startup in progress, not ready for normal operation
Blink - 2 Hz Blink - 2 Hz = Data Transmission (normal communication)
Off Steady = No Data Transmission (N/A - auto baud not supported)
On Steady = Communication lost, waiting to join communication ring
Off (Except on On Steady = EOL switch in ON position
terminating
Off Steady = EOL switch in Off position
devices)
Description
Transformer, 120/24 VAC, 96 VA, with circuit breaker and 120 VAC outlet, approved for Smoke
Control
Refer to the NS Series Network Sensors Product Bulletin (LIT-12011574) for specific sensor
model descriptions.
MS-IOU4710-0U Input/Output Module, model listed for Smoke Control, consisting
of:
24 VAC (nominal, 20 VAC minimum/30 VAC maximum), 50/60 Hz, power supply
Class 2 (North America)
14 VA maximum
Note: VA rating does not include any power supplied to the peripheral devices
connected to Binary Outputs (BOs) or Configurable Outputs (COs), which can
consume up to 12 VA for each BO or CO; for a possible total consumption of an
additional 84 VA (maximum).
Operating: 0° to 50°C (32° to 122°F); 10% to 90% RH noncondensing
Storage: -40° to 80°C (-40° to 176°F); 5% to 95% RH noncondensing
DIP switch set; valid controller device addresses 4–127 (Device addresses 0–3 and
128–255 are reserved and not valid addresses.)
Table 6 to troubleshoot the controller.
