inSTaLLaTiOn and mainTenanCe inSTrUCTiOnS
B501BhT-2
Temporal Tone Sounder Base

Specifications

Base Diameter:
Base Height (less sensor):
Weight:
Operating Temperature Range:
Operating Humidity Range:

Electrical Ratings

External Supply Voltage:
Standby Current:
Alarm Current:
Maximum Ripple Voltage:
Start-up Capacitance:
Communication/Initiating Loop Supply
Current Draw from Remote Output
of Sensor to turn on Horn:
Sound Output:
Sounder Delay Time:
Before installing
Please read the System Smoke Detector Application Guide,
which provides detailed information on sensor spacing. place-
ment, zoning, wiring, and special applications. Copies of this
manual are available from System Sensor. NFPA 72 and NEMA
guidelines should be observed.
NOTICE: This manual should be left with the owner/user of
this equipment.
IMPORTANT: The detector used with this base must be tested
and maintained regularly following NFPA 72 requirements.
The detector should be cleaned at least once a year.

General description

The B501BHT-2 sounder base is used with System Sensor 200
Series sensor heads. Refer to the appropriate manual for more
information on sensors.
The B501BHT-2 incorporates the distinctive three-pulse tempo-
ral pattern fire alarm evacuation signal now required by NFPA
72 for commercial and residential applications.
The sounder base is intended for use with intelligent systems.
Refer to the panel manual for the maximum allowable num-
ber of units per loop. The sounder base requires an external
24VDC supply with reverse polarity capability or a relay mod-
ule configured to reverse the power as in Figure 5. The con-
nections for the external supply (terminals 1 and 2) and the
communication loop (terminals 3 and 4) are isolated to pre-
vent electrical interaction between them.
A loop of horns can be made to sound by reversing the polar-
ity of the external supply when configured as in Figure 4 and
5. When configured as in Figure 5, a loop of horns can also be
made to sound by turning on the Intelligent Relay Module.
D250-02-00
6.0 inches (15.2 cm)
2.3 inches (5.9 cm)
.32 lb. (145 gm)
32° to 120°F (0° to 49°C)
10% to 93% Relative Humidity
17 to 32 VDC
1.0 mA maximum
15 mA maximum
10% of supply voltage
200 µF
600 µA maximum
Greater than 90 dBA measured in anechoic room at 10 feet, 24 volts. 85 dBA
minimum measured in UL reverberant room.
0.75 to 5.7 sec
NOTE: When not used as a supplementary evacuation system,
the external 24 VDC supply shall be treated as a component of
the main power supply system and shall fall under the require-
ments of the main power supply system per NFPA 72.

B501BhT-2 Terminals

No.
1 External Supply Positive (+)
2 External Supply Negative (–)
3 Negative (–) Comm. Line In and Out
4 Positive (+) Comm. Line In and Out
5 Sounder Base Interconnect
Terminals 3 and 4 are used for the communication circuit.

mounting

Mount the B501BHT-2 directly to an electrical box, using the
mounting kit, supplied (see Figure 2).
The sounder base is 1.1-inches deep. Electrical boxes must be
4-inches square by at least 1
ommended.
NOTE: A maximum space of
the electrical box to the inside edge of the drywall or ceiling
tile is allowable.

Wiring Guidelines

All wiring must be installed in compliance with the National
Electrical Code and the local codes having jurisdiction and
must not be of such length or wire size which would cause
the base to operate outside of its published specifications. The
conductors used to connect smoke sensors to control panels
and accessory devices should be color coded to reduce the
likelihood of wiring errors. Improper connections can prevent
a system from responding properly in the event of a fire.
1
3825 Ohio Avenue, St. Charles, Illinois 60174
Function
1 ⁄ inches deep - 2
2
1
⁄
8
1-800-SENSOR2, FAX: 630-377-6495
www.systemsensor.com
1 ⁄ inches is rec-
8
inch from the outside edge of
I56-2814-003R
