INSTALLATION AND MAINTENANCE INSTRUCTIONS
B501BH Sounder Base
Specifications
Base Diameter:
Base Height (less sensor):
Weight:
Operating Temperature Range:
Operating Humidity Range:
Electrical Ratings
External Supply Voltage:
Standby Current:
Alarm Current:
Maximum Ripple Voltage:
Start-up Capacitance:
Communication/Initiating Loop Supply
Current Draw from Remote Output
of Sensor to turn on Horn:
Sound Output:
Before Installing
Please read the System Smoke Detector Application Guide,
which provides detailed information on sensor spacing.
placement, zoning, wiring. and special applications. Copies
of this manual are available from System Sensor. NFPA 72
and NEMA guidelines should be observed.
NOTICE: This manual should be left with the owner/user
of this equipment.
IMPORTANT: The detector used with this base must be
tested and maintained regularly following NFPA 72 require-
ments. The detector should be cleaned at least once a year.
General Description
The B501BH sounder base is used with System Sensor 200
and 500 Series sensor heads. Refer to the appropriate man-
ual for more information on sensors.
D650-03-00
6.0 inches (15.2 cm)
2.3 inches (5.9 cm)
0.4 lb. (181 gm)
32° to 120°F (0° to 49°C)
10% to 93% Relative Humidity
17 to 32 VDC
1.0 mA maximum
15 mA maximum
10% of supply voltage
200 µF
700 µA maximum
Greater than 90 dBA measured in anechoic room at 10 feet, 24 volts. 85 dBA
minimum measured in UL reverberant room.
1
3825 Ohio Avenue, St. Charles, Illinois 60174
The sounder base is intended for use with intelligent sys-
tems. Refer to the panel manual for the maximum allow-
able number of units per loop. The sounder base requires
an external 24VDC supply with reverse polarity capability.
The connections for the external supply (terminals 1 and 2)
and the communication loop (terminals 3 and 4) are iso-
lated to prevent electrical interaction between them.
When the sensor's visible LEDs are latched on for approx-
imately 10 seconds, the associated horn sounds. A loop of
horns can be made to sound by reversing the polarity of the
external supply.
NOTE: When not used as a supplementary evacuation sys-
tem, the external 24 VDC supply shall be treated as
a component of the main power supply system and
shall fall under the requirements of the main
power supply system per NFPA 72.
