lines from the boat's fuel supply are push fit onto the male end of the quick connect
fittings. The fuel return line should return directly to the fuel supply tank.
The following is recommended for the fuel system installation:
NOTICE
·
The fuel supply line should be installed with minimal rise from the fuel tank.
The total rise from the bottom of the pickup tube to the fuel inlet on the
Hurricane® Zephyr™ HW should not exceed 60". There are no minimum
clearance requirements between the fuel tank and the Hurricane® Zephyr™
HW.
! CAUTION
·
All fuel line fittings and hoses must use suitable sealant and clamps and must
be checked for leaks upon initial installation and periodically as part of normal
maintenance.
·
A primary, UL and/or CSA approved, 10-micron fuel oil filter (not provided)
must be installed in the fuel supply line, between the tank and the Hurricane®
Zephyr™ HW, in a manner that ensures easy access for maintenance.
secondary fuel filter is mounted inside the fuel block, behind the fuel nozzle.
Both filters must be replaced as part of routine scheduled maintenance.
·
Fuel line must be appropriate for the specific installation requirements. It is
strongly recommended that all fuel lines have permanently installed end
fittings.
4.3
What NOT to Do
·
Don't allow fuel or the fuel lines to become contaminated with foreign material
that may accumulate during installation.
·
Don't allow the fuel lines to become damaged or constricted.
! CAUTION
4-2
The fuel supply from the fuel storage tank to the fuel inlet must be
from a dedicated fuel pickup on the top of the tank.
The fuel line must be located and secured to prevent damage,
chafing and kinking during normal operation.
Ensure fuel lines are protected from contamination by foreign
material. When installing or servicing fuel lines, seal off the ends to
prevent contamination. After installing, you may also wish to flush
the fuel line with clean fuel to rid it of air and foreign material.
Installation Manual for Hurricane® Zephyr™ HW Heating System
Section 4, Installing the Fuel System
