2.2
·
·
DANGER
·
·
·
·
2-2

Mounting Location

Mounting location must be able to support double the gross
weight of the heater when full (i.e.70 lbs. x 2 = 140 lbs./63.5
KG) and must be of a non-combustible material.
®
The Hurricane Zephyr™ HW model is 10.5"H x 14" W x 19" D
(26.6 cm x 35.5 cm x 48.2 cm). See Figure 2-1: Dimensions
The Hurricane® Zephyr™ HW heater must not be installed in
any compartment with flammable gases.
The Hurricane® Zephyr™ HW heater must be isolated
completely from all living spaces. Combustion air must be
drawn directly from an outside source and cannot contain any
combustible gases.
(part#8019) and
Securely clamp and seal all air inlet hose connections. Ensure
the supply of combustion air to the appliance is not obstructed
or cut off.
The heater must be mounted in an area that provides
unrestricted access to the front panel, top access panel and
access to fuel, water, power and exhaust connections. There
should be at least 12" of clearance on the top of the heater for
accessing and
temperature adjusting valve. Available space for connection to
the rear of the heater is necessary if engine heat management
is connected to the Zephyr. There should be at least 1"
clearance to all other Hurricane® Zephyr™ HW heater
surfaces.
The heater must not be installed in any compartment with
flammable gases.
The heater must be mounted horizontal and level using the
two included mounting brackets that bolt to the side of the
heater.
Installation Manual for
Section 2, Mounting the Heater Unit
Use the supplied
the air intake
servicing the components
Hurricane
air intake
silencer (part#10455).
and water
® Zephyr™ HW Heating
hose
