9 Technical Specifications

1000 Mbps (Gigabit) ports are only available on the V-Tap VoIP 3 model
LAN port
PHONE1 port
PHONE2 port
PHONE3 port
Port Status LED's
Switching
PoE Bridge
SD Card type
SD Card size
SD Card storage
USB Version
USB Profile
USB Current
USB Connector
Button
LED's (4x)
Size ( L x B x H )
Housing material
Weight
Temperature Range : 0 – 40 °C
Humidity Range
EMC
Safety
RoHS
V-Tap VoIP Manual EN v3.23 Aug 2021
: RJ45, Ethernet 10/100(/1000)
: RJ45, Ethernet 10/100(/1000)
: RJ45, Ethernet 10/100(/1000) BASE-T, Full Duplex, PoE to PHONE3
: RJ45, Ethernet 10/100(/1000)
: 10/100Mb with Rx/Tx activity blinking on all 4 Ethernet ports.
: L2 switching on all Ethernet ports.
: PoE is passively bridged from PHONE2 to PHONE3,
So, if the cable carries PoE, it is bridged to the other port.
Note that the V-Tap VoIP does not generate PoE by itself.
: Best to use SDHC/XC Ultra with a minimum speed of 40 MB/s.
: 8, 16 or 32 GB. Bigger is possible but must be FAT32 formatted.
: Depends on the used VoIP codec and other network traffic.
For normal G.711 VoIP calls, it is about 12 hours per 1 GB.
For normal G.729 VoIP calls, it is about 24 hours per 1 GB.
: V2.0 High Speed (480Mbps)
: Generic HID (VID_0DE1 & PID_5101 or PID_5102)
: 5V @300mA (Max. 2W)
: Full size 'B'- type
: Function as described here:
: Function as described here:
: 90 x 125 x 28 mm
: Blue bottom with Silver top, 4 pcs soft rubber footpads.
: 150 Gram
: 10 – 90 %, non-condensing
: EN 55022:2010 / AC:2011 Class B , EN 55024:2010
: EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011
: EN 50581:2012 (RoHS2) , RoHS Directive 2011/65/EU
BASE-T, Full Duplex
BASE-T, Full Duplex
BASE-T, Full Duplex, PoE to PHONE2
Button functions
LED's
© 2017-2021 Vidicode
IEEE 802.3af.
