Single-Proxy mode
Just a single IP address must be entered in the Proxy Server and Proxy
Source fields. The Proxy Destination is always only one IP address or host
name. Also, at least one Proxy license is needed. For example:
Proxy Server V-Tap IP Address = 192.168.0.244
Proxy Source IP Address
Proxy Destination Address
For a drawn scheme, see
It is also possible to leave the Proxy Source field empty, in which case all
SIP clients are accepted as a source, until the maximum Proxy licenses.
In combination with a FRITZ!Box, the Single-Proxy mode can be used to
record all your phone calls, even those from the cordless DECT handsets.
This special case is described in chapter
Multi-Proxy mode
To setup Multi-Proxy mode, an IP range must be entered in the Proxy
Server and Proxy Source fields. The V-Tap then acts as multiple proxy
servers. For example:
Proxy Server V-Tap IP Address =
Proxy Source IP Address
Proxy Destination Address
The above means that 5 devices can use the V-Tap as proxy and can
therefore be recorded at the same time. For this to work, at least 5
Proxy licenses must be available inside the V-Tap.
The source devices must have an IP address that lies between the
entered range and each source device must use a different proxy IP.
The 5 devices (IP phones) can then be filled in as follows:
1. IP phone
2. IP phone
3. IP phone
4. IP phone
5. IP phone
For a drawn scheme, see
It is recommended that the SIP phones are set to static IP addresses.
V-Tap VoIP Manual EN v3.23 Aug 2021
= 192.168.0.12
= sip.voip-provider.com
Single-Proxy
=
= sip.voip-provider.com
192.168.0.12 uses V-Tap proxy
192.168.0.27 uses V-Tap proxy
192.168.0.41 uses V-Tap proxy
192.168.0.48 uses V-Tap proxy
192.168.0.56 uses V-Tap proxy
Multi-Proxy
mode.
FRITZ!Box recording...
192.168.0.231 - 192.168.0.235
192.168.0.10 - 192.168.0.60
192.168.0.231
192.168.0.232
192.168.0.233
192.168.0.234
192.168.0.235
mode.
