5.5 Copy Settings from SD card

The V-Tap automatically copies the settings files to the root of the SD
card, directly after insertion (only if they do not exist already).
The file CFG.VTV from the SD card can be edited with a text editor on
the PC and then be copied back to internal memory. To do so, the SD
card must be inserted while holding the button pressed on the V-Tap.

5.6 Factory settings

To reset all settings to factory default, the following must be done:
•
Remove the SD card.
•
Power Off the unit.
•
Press the button.
•
Power On and hold the button pressed; all LED's are ON.
•
Release the button within 5 seconds; RGB LED's go OFF.
•
Press the button 5 more times; RGB LED's blink fast.
•
After 5 seconds, the system reboots automatically.
The procedure above is only possible when the system is running
normal. With corrupted firmware, a special update must be done with
an SD card (see Firmware

5.7 Format SD card

To format an SD card, insert the card somewhere during the factory
settings procedure above, after the first release of the button. Another
way is to enter "FORMAT CARD" in

5.8 Default IP address

When the application does not seem to run at all anymore, then a reset
to factory settings is not possible. Besides a special update with the SD
card (see below), there is still a way to look with FTP in the filing system
remotely. The following can be done:
•
Remove the SD card.
•
Power Off the unit.
•
Press the button.
•
Power On and hold the button pressed for 1 second.
•
The IP address is now on the default value 192.168.55.66
•
Only access with FTP is now possible (no web interface).
V-Tap VoIP Manual EN v3.23 Aug 2021
update).
