Moving and storage instructions
Do not store the product in hot place exposed to direct sunlight.
• Never lift or carry the product by the flexible power cord or the EV cable. Carry by the
main unit and support the cable with the other hand.
5
• Handle the product with care to prevent damage to any of its components. Do not
subject the product to strong force or impact. Do not pull, twist, tangle, drag or step on
the product or any of its components.
• Store the product in the provided storage case
from children and pets.

SPECIFICATIONS

Model:
Rated input/output
voltage:
Rated frequency:
Rated current:
Charging connector:
Power plug type:
Compatible outlet:
Cable length:
Operating temperature:
Storage temperature:
Protection class:
IP degree of protection:
Net weight:
Circuit breaker rating:
* The weight and dimensions may vary due to measurement errors. Please refer to the
actual measurements.
CAUTION
SEV-32-01, SEV-40-01
120 /240 V AC single-phase
50/60 Hz
32 A (model SEV-32-01)
40 A (model SEV-40-01)
J plug (SAE J1772)
NEMA Type 14-50
NEMA 14-50 or NEMA 5-15
approx. 30 ft (9 m)
–22 to 122°F (–30 to 50°C)
–22 to 140°F (–30 to 60°C)
Class I
5
IP66 (main unit
15.4 lb (7 kg)
40 A (model SEV-32-01)
50 A (model SEV-40-01)
13
10
in a dry indoor area. Keep away
7
and charging gun )
