OPERATING INSTRUCTIONS

Connecting to the outlet
• The product's maximum working current is 32 A (model SEV-32-01) or 40 A
(model SEV-40-01). Ensure the circuit breaker of the outlet or the GFCI outlet supports
current of 50 A or more.
• Ensure the outlet used is of NEMA 14-50 or NEMA 5-15 type.
• Fully plug the power plug
For use with the standard 120 V AC outlet (NEMA 5-15), connect the power plug
NEMA 5-15P to 14-50R adapter
Charging parameter estimation
Required circuit /
Breaker rating
20 A
30 A
40 A
50 A
CAUTION
1
into the outlet.
NOTICE
6
first.
Charger
amperage
16 A
24 A
32 A
40 A
9
Estimated driving range added
per hour of charging
12 miles (19 km)
18 miles (29 km)
25 miles (40 km)
30 miles (48 km)
1
to the
