TPIM-F3
The TPIM-F3 is designed to operate with 8.3/125 m fiber optic cable.
Table B-3 lists TPIM-F3 specifications
Parameter
Transmitter Peak Wave
Length
Spectral Width
Rise Time
Fall Time
Transmitter Average
Power
Receiver Spectral
Response
Receiver Sensitivity
Bit Error Rate: Better than 10
Transmitter power and receive sensitivity levels, shown in
Table B-2, and Table B-3
A Peak Power Meter must be used to correctly compare the values given
to those measured on any particular port. If power levels are being
measured with an Average Power Meter, then 3 dBm must be added to the
measurement to correctly compare those measured values to the values
listed (i.e. -30.5 dBm peak=-33.5 dBm average).
Transmitter Power decreases as temperatures rise and
NOTE
increases as temperatures fall. Use the Output Power
Coefficient to calculate increased or decreased power output
for an operating environment.
For example, the typical power output at 25 C is -16.4 dBm.
For a 4 C temperature increase, multiply the typical coefficient
(-0.15 dBm) by four and add the result to typical output power
(4 x -0.15 dBm + -16.4 = -17.0).
Table B-3 TPIM-F3 Specifications
Typical
1300 nm
–
2.5 nsec
3.5 nsec
-16.9 dBm
1300 nm
-32.5 dBm
-10
are Peak Power Levels after optical overshoot.
TPIM SPECIFICATIONS
Minimum Maximum
1270 nm 1330 nm
– 100 nm
– 5.0 nsec
– 5.0 nsec
-18.6 dBm –
1150 nm 1600 nm
-34.0 dBm –
Table B-1,
B-3
