Firmware Downloads To Flash Eeprom - Cabletron Systems MicroMMAC-22T User Manual

The chief benefit provided by out-of-band access capability is that it
allows you to manage your network in the event that the in-band network
communication infrastructure that supports remote communication with
the MicroMMAC-T becomes inoperable.
You can also access LM from an in-band Telnet connection from any
TCP/IP-based node linked to the MicroMMAC-T. The MicroMMAC-T
allows up to four concurrent Telnet sessions with LM. See the
MicroMMAC-T Local Management Guide for information about using
LM.
The CRBRIM-W/T and the MicroSNAC-T accessories each
NOTE
include their own embedded configuration/management
applications.
Remote SNMP Management
The MicroMMAC-T's management agent can collect data on and process
SNMP requests for up to 255 stations on the ring. Cabletron Systems
offers the following remote management packages you can use to fully
exploit the MicroMMAC-T's management capabilities:
SPECTRUM
•
Remote LANVIEW/Windows-Spectrum Element Manager
•
Remote SPECTRUM Portable Management Application (SPMA) for
•
the MicroMMAC-T

1.2.3 Firmware Downloads To Flash EEPROM

The MicroMMAC-T is equipped with Flash EEPROM (Electrical
Erasable Programmable Read Only Memory). It stores the operating code
(or firmware image) that is loaded into RAM when the MicroMMAC-T is
powered up or reset. When you want to replace the current image in Flash
EEPROM, you can initiate a download of a new (or preferred) image
from a TFTP/BootP server using the Local Management Flash Download
screen (see the MicroMMAC-T Local Management Guide for
instructions) or any SNMP-compliant remote management application
providing TFTP/BootP-protocol services.
INTRODUCTION
1-3
