745
Event Log Message
Host Console Message
Alert Condition
Alert ID Number
Alert Type
Alert Description
Probable Causes
User Causes
Install Causes
Failure Causes
Actions
Additional SVs
Supplemental Software User Guide
puname/linename – LLC/2 FRMR Sent, Invalid Nr
SOFTWARE PROGRAM ERROR:LAN LLC COMMUNICATIONS
A LAN logical link has been lost. The remote station sent a fram e with an invalid N(r ).
The local link station returned a Fram e Reject r esponse.
X'216D1033'
X'01' Permanent
X'2100' Software program error
X'2007' LAN LLC com munications
X'1023' Communications program in r emote node
(none)
(none)
X'1023' Communications program in r emote node
X'F022' Invalid N(r) received
X'3301' If problem persists then do the following:
X'2010' Review link detail data
X'3103' Contact LAN administrator responsible for this LAN
X'32C0' Report the following:
X'82'SF (Adapter Num ber)
X'82'SF (Reference Code)
X'51'SV LAN LCS Data
X'02'SF Ring/Segment Identifier
X'03'SF Local Individual MAC Address
X'23'SF Local Individual MAC Name (optional)
X'04'SF Remote Individual MAC Address
X'24'SF Remote Individual MAC Name (optional)
X'05'SF LAN Routing Information
X'52'SV LCS Configuration
X'02'SF Remote Device Address
X'04'SF Local Device Address
X'8C'SV Link Station Data
X'01'SF Curr ent Ns/Nr Counts
X'02'SF Outstanding Frame Count
X'03'SF Last Control Field Received
X'04'SF Last Control Field Sent
X'05'SF Sequence Number Modulus
X'06'SF Link Station State
X'07'SF LLC Reply Timer Expiration Count
X'08'SF Last Received Nr Count
X'05'SV Hierarchy/Resource List
X'10'SF Hierarchy Name List
First resource below sender:
Second resource below sender :
Resource Name = (LAN NAME)
Resource Type = X'39'(LINE)
Resource Name = (Physical Unit Name)
Resource Type = X'80'(Physical Unit)
