710
Event Log Message
Host Console Message
Alert Condition
Alert ID Number
Alert Type
Alert Description
Probable Causes
User Causes
Install Causes
Failure Causes
Actions
Additional SVs
Supplemental Software User Guide
puname/linename – SDLC Rem Stn sent Invalid Nr
SOFTWARE PROGRAM ERROR:SDLC COMMUNICATIONS
An SDLC logical link has been lost. The secondary link station sent a frame with an
invalid N(r).
X'1C40F78B'
X'01' Permanent
X'2100' Software Program Error
X'2004' SDLC communications
X'1023' Communications program - remote
(none)
(none)
X'1023' Communications program in r emote node
X'F022' Invalid N(r) received
(Sender-specific actions)
X'52'SV LCS Configuration
X'02'SF Remote Device Address
X'04'SF Local Device Address
X'06'SF Link Station Attributes
X'07'SF Link Attr ibutes
X'8C'SV Link Station Data
X'01'SF Curr ent Ns/Nr Counts
X'02'SF Outstanding Frame Count
X'03'SF Last Control Field Received
X'04'SF Last Control Field Sent
X'05'SF Sequence Number Modulus
X'06'SF Link Station State
X'07'SF LLC Reply Timer Expiration Count
X'08'SF Last Received Nr Count
X'05'SV Hierarchy/Resource List
X'10'SF Hierarchy Name List
First resource below sender:
Second resource below sender :
Resource Name = (LINE NAME)
Resource Type = X'3D'(LINE)
Resource Name = (Physical Unit Name)
Resource Type = X'80'(Physical Unit)
21
