LPDARESID
AUTOCALL
Auto Retry Tout
Auto Retry Ct
Local Sub
Remote Sub
Response Timer (T1)
Supplemental Software User Guide
(Cabletron device parameter
(milliseconds).
is the LPDA Resource ID, which defines LUs on the PU. The value must match the
LOCADDR defined on VTAM. Valid values are
causes automatic calling between SNA ports when the controller becomes active. The
valid values are
ENABLE
is equivalent to the Cabletron device parameter
between autocall retries. Valid values are 15-255 (seconds).
is equivalent to the Cabletron device parameter
maximum number of times an autocall will be sent. Valid values are
a value of
allows indefinite retries.
0
is the subscriber address of the local (to the Cabletron device) end of an SNA con-
nection.
is the address of the remote (to the Cabletron device) end of an SNA connection.
is used to detect the failure to receive a required acknowledgment or response from
the remote link station. The valid values are
station will start the timer when it transmits one of these:
an Information LPDU.
a Command LPDU with the P bit set to B'1.' (If this LPDU is sent while the timer
is already running, the link station will reset and restart it.)
The link station will reset T1 when it receives one of these:
A REJ LPDU, provided a Command LPDU with P bit set to B'1' is not out-
standing.
A Response LPDU with the F bit set to B '1.'
An Information or Supervisory LPDU with an N(R) greater than the last N(R)
received and less than or equal to the line station's V(S), provided a Command
LPDU with P bit set to B'1' is not outstanding.
If additional LPDUs are set from the remote link station after the local station has reset
T1, the timer will be restarted if acknowledgments of or responses to those LPDUs are
outstanding. If no acknowledgments/responses are outstanding, the link station will
start the inactivity timer. (See "Ti" later.)
If T1 expires and acknowledgments/responses are still outstanding, the link station
will send one of the following, then restart T1:
A Supervisory LPDU with the P bit set to B'1,' to solicit remote link station
status.
Maximum Retransmissions
and
.
DISABLE
Autocall Retry Time
0-250
). Valid values are
.
0-255
, which is the time
, which is the
Autocall Retry Count
0-255
(x 100 milliseconds).The link
40-9999
. Note that
9
