742
Event Log Message
Host Console Message
Alert Condition
Alert ID Number
Alert Type
Alert Descr iption
Probable Causes
User Causes
Install Causes
Failure Causes
Actions
Additional SVs
36
puname/linename – LLC/2 FRMR Rcvd, IFLD too long
SOFTWARE PROGRAM ERROR:LAN LLC COMMUNICATIONS
A LAN logical link has been lost. The local link station sent a frame with an i-field that
was too long. The remote link station returned a Frame Reject response.
X'87180BF5'
X'01' Permanent
X'2100' Softwar e program error
X'2007' LAN LLC communications
X'1000' Softwar e program
(none)
(none)
X'1000' Softwar e program
X'F013' Frame reject received – m aximum I-field length exceeded
X'3301' If problem persists then do the following:
X'2010' Review link detail data
X'3103' Contact LAN administrator responsible for this LAN
X'32C0' Repor t the following:
X'82'SF (Adapter Number )
X'82'SF (Reference Code)
X'51'SV LAN LCS Data
X'02'SF Ring/Segment Identifier
X'03'SF Local Individual MAC Address
X'23'SF Local Individual MAC Name (optional)
X'04'SF Remote Individual MAC Address
X'24'SF Remote Individual MAC Name (optional)
X'05'SF LAN Routing Information
X'52'SV LCS Configuration
X'02'SF Rem ote Device Address
X'04'SF Local Device Address
X'8C'SV Link Station Data
X'01'SF Current Ns/Nr Counts
X'02'SF Outstanding Fr ame Count
X'03'SF Last Control Field Received
X'04'SF Last Control Field Sent
X'05'SF Sequence Number Modulus
X'06'SF Link Station State
X'07'SF LLC Reply Timer Expiration Count
X'08'SF Last Received Nr Count
X'05'SV Hierarchy/Resource List
X'10'SF Hierarchy Name List
First resource below sender :
Second resource below sender:
Resource Name = (LAN NAME)
Resource Type = X'39'(LINE)
Resource Name = (Physical Unit Name)
Resource Type = X'80'(Physical Unit)
NetView Service Point
