739
Event Log Message
Host Console Message
Alert Condition
Alert ID Number
Alert Type
Alert Description
Probable Causes
User Causes
Install Causes
Failure Causes
Actions
Additional SVs
Supplemental Software User Guide
puname/linename – LLC/2 FRMR Rcvd, Invalid Command
SOFTWARE PROGRAM ERROR:LAN LLC COMMUNICATIONS
A LAN logical link has been lost. The local link station sent an invalid or unsupported
command or response to the remote link station. The remote link station returned a
Frame Reject response.
X'8A5B2D2C'
X'01' Permanent
X'2100' Software program error
X'2007' LAN LLC com munications
X'1000' Software program
(none)
(none)
X'1000' Software program
X'F010' Frame reject r eceived – Invalid/unsupported com mand or response sent
X'3301' If problem persists then do the following:
X'2010' Review link detail data
X'3103' Contact LAN administrator responsible for this LAN
X'32C0' Report the following:
X'82'SF (Adapter Num ber)
X'82'SF (Reference Code)
X'51'SV LAN LCS Data
X'02'SF Ring/Segment Identifier
X'03'SF Local Individual MAC Address
X'23'SF Local Individual MAC Name (optional)
X'04'SF Remote Individual MAC Address
X'24'SF Remote Individual MAC Name (optional)
X'05'SF LAN Routing Information
X'52'SV LCS Configuration
X'02'SF Remote Device Address
X'04'SF Local Device Address
X'8C'SV Link Station Data
X'01'SF Curr ent Ns/Nr Counts
X'02'SF Outstanding Frame Count
X'03'SF Last Control Field Received
X'04'SF Last Control Field Sent
X'05'SF Sequence Number Modulus
X'06'SF Link Station State
X'07'SF LLC Reply Timer Expiration Count
X'08'SF Last Received Nr Count
X'05'SV Hierarchy/Resource List
X'10'SF Hierarchy Name List
First resource below sender:
Second resource below sender :
Resource Name = (LAN NAME)
Resource Type = X'39'(LINE)
Resource Name = (Physical Unit Name)
Resource Type = X'80'(Physical Unit)
33
