Welcome to the SmartSTACK 10
ELS10-26
This Getting Started Guide will tell you what you need to get your
SmartSTACK10 ELS10-26 up and running, out of the box. By
using the factory-set default configuration, you can quickly
integrate the ELS10-26 into your network. This guide will provide
you with what you need to know to:
• set up and power up the SmartSTACK 10 ELS10-26
• connect devices to the SmartSTACK 10 ELS10-26
• connect the SmartSTACK 10 ELS10-26 to the network
• connect the Local Console Manager to a terminal
• install a Fast Ethernet Port Interface Module (FEPIM)
• troubleshoot the SmartSTACK 10 ELS10-26
The SmartSTACK 10 ELS10-26 is an intelligent Ethernet-to-
Ethernet desktop switch that lets you to link multiple Local Area
Networks (LANs) together. The SmartSTACK 10 ELS10-26 has
twenty-five 10 Mbps Ethernet ports, one fixed 100 Mbps Fast
Ethernet port and one slot for an optional FEPIM (Fast Ethernet
Port Interface Module).

Getting Help

If you need additional support related to the SmartSTACK 10
ELS10-26, contact Cabletron Systems Global Call Center:
By phone (603) 332-9400
By Internet mail support@ctron.com
By FTP ctron.com (134.141.197.25)
Login anonymous
Password your email address
BBS: (603) 335-3358
Modem setting: 8N1: 8 data bits, No parity, 1 stop bit
WWW: www.ctron.com
Com Port
