exit (logout)
Allows you to log out of your current LCM session.
Example: exit
Enter
help
Displays the available LCM commands. You can also type a
question mark ( ? ) to display the available LCM commands.
Example: help
Enter
ident
Displays the ELS10-26's serial number, the FE up-link module
number (if installed), power-up test codes, and diagnostic information.
Example: ident
Enter
ipaddr
Displays the IP addresses, address masks, and MAC addresses for all
monitored ports. This command also allows you to assign an IP address
to a port on the ELS10-26.
Example: ipaddr 6 192.138.217.40
mirror
Allows you to display a monitored port or turn monitoring on or off for a port.
Options:
Rx
Tx
both (half duplex mode only)
off
Example: mirror 6 Tx
Enter
Enter
– 10 –
ping
Allows you to send ICMP ECHO_REQUEST packets
Options:
-rvsx
HOST
DATASIZE
count
Example: ping -r
Enter
reboot
Allows you to enter the number of seconds the ELS10-26 waits before
rebooting.
Options:
SECONDS
off
Example: reboot 60
Enter
route display
Displays routing table information.
Options:
IPADDR
Example: route display IPADDR
speed
Allows you to display or set the speed for the Fast Ethernet ports.
Options:
auto
10 (mbps)
100 (mbps)
Example: speed 26 100
status
Displays the status of the ELS10-26, including the currently running software
version, the number of learned addresses, system up time, unit temperature,
CPU utilization, and the status of each port or range of ports.
Options:
port number
port number range
Enter
Example: status
Enter
