Cabletron Systems ELS10-26 Reference Manual

Mib reference guide
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ELS10-26 MIB REFERENCE
GUIDE
9032244-01

Advertisement

Table of Contents
loading

Related Manuals for Cabletron Systems ELS10-26

Summary of Contents for Cabletron Systems ELS10-26

  • Page 1 ELS10-26 MIB REFERENCE GUIDE 9032244-01...

  • Page 3: Fcc Notice

    Notice NOTICE Cabletron Systems reserves the right to make changes in specifications and other information contained in this document without prior notice. The reader should in all cases consult Cabletron Systems to determine whether any such changes have been made.
  • Page 4 IMPORTANT: Before utilizing this product, carefully read this License Agreement. This document is an agreement between you, the end user, and Cabletron Systems, Inc. (“Cabletron”) that sets forth your rights and obligations with respect to the Cabletron software program (the “Program”) contained in this package.
  • Page 5 Government is subject to restrictions as set forth in subparagraph (c) (1) (ii) of the Rights in Technical Data and Computer Software clause at 252.227-7013. Cabletron Systems, Inc., 35 Industrial Way, Rochester, New Hampshire 03867-0505. Notice...

  • Page 6: Declaration Of Conformity

    Principal Compliance Engineer ___________________________________ Title Rochester, NH, USA ___________________________________ Location 89/336/EEC 73/23/EEC Cabletron Systems, Inc. 35 Industrial Way PO Box 5005 Rochester, NH 03867 Mr. J. Solari Cabletron Systems Limited Nexus House, Newbury Business Park London Road, Newbury Berkshire RG13 2PZ, England...

  • Page 7: Table Of Contents

    TABLE OF CONTENTS Chapter 1 Introduction 1.1 Related Documentation...1-2 1.2 Getting Help...1-3 1.3 Document Conventions...1-4 1.4 SNMP Primitives ...1-5 1.5 MIB Primitive Types ...1-6 1.6 User Functions ...1-7 1.7 Navigating Through the MIBTree Structure...1-9 1.8 TFTP ...1-13 1.8.1 Retrieving All Parameters...1-15 1.8.2 Setting All Parameters ...1-15 1.9 Additional Interfaces...1-16 Chapter 2...
  • Page 8 4.3 Transparent Group ...4-9 Chapter 5 PPP MIB 5.1 PPP Link Control Table ...5-1 5.2 PPP IP Table ...5-10 Chapter 6 ELS10-26 MIB 6.1 System Group...6-1 6.1.1 Hardware Configuration Group ...6-2 6.1.2 LXSW Configuration Group...6-4 6.1.3 Administration Group ...6-6 6.1.4 Software Distribution Group...6-11 6.1.5 Addresses Configuration Group ...6-13...
  • Page 9 6.1.11 Cabletron Workgroup Management Group ...6-29 6.1.12 Cabletron Trap Management Group ...6-31 6.1.13 Ping Management MIB...6-35 6.1.14 Traceroute ...6-41 6.1.15 Traceroute Management MIB...6-42 6.1.16 Port Mirroring ...6-47 Chapter 7 Traps 7.1 Generic Traps...7-1 7.2 Enterprise Specific Traps For The ELS10-26...7-2 Contents...
  • Page 10 Contents viii...

  • Page 11: Chapter 1 Introduction

    This manual is for system administrators responsible for configuring, monitoring, and maintaining the ELS10-26. Much of the configuration of the ELS10-26 needs to be done using an SNMP-based network management station. This manual contains the SNMP MIB variables you may need to configure, monitor, and manage your ELS10-26.

  • Page 12: Related Documentation

    (2nd edition), Marshall T. Rose, Prentice Hall © 1994. This manual describes the software interface between the NMS and the ELS10-26. This is relevant for an ELS10-26 running Version 1.0 software. The NMS communicates with the ELS10-26 software. The Network Management, or UART, port is the interface to the Local Console Manager (LCM).

  • Page 13: Getting Help

    1.2 GETTING HELP If you need additional support related to the ELS10-26, or if you have any questions, comments, or suggestions concerning this manual, contact Cabletron Systems Global Call Center: Phone: Internet mail: FTP: Login: Password: BBS: Modem setting: Before calling Cabletron Systems Global Call Center, have the following information ready: •...

  • Page 14: Document Conventions

    < >. For example, you must enter a port number and an IP address to execute the command: ELS10-26 >ipaddr 6 192.138.217.40 Field value options appear in bold typeface. The following conventions are also used in this document: Note: Calls the reader’s attention to any item of information that may be...

  • Page 15: Snmp Primitives

    The NMS must rely on IP, rather than MAC addressing for all datagrams sent to an ELS10-26. Therefore: • All datagrams from the ELS10-26 are addressed to either an NMS or the broadcast IP address. • Within the context of this document, the terms “datagram,”...

  • Page 16: Mib Primitive Types

    Introduction 1.5 MIB PRIMITIVE TYPES The MIB definitions in this document may reference the primitive types that are described in the Structure and Identification of Management Information for TCP/IP-based Internets, RFC 1155. RFC 1155 is based on the Specification of Abstract Syntax Notation One, ASN.1.

  • Page 17: User Functions

    SetRequest PDU, and the ELS10-26 responds with a GetResponse PDU. The ELS10-26 will change both its current value and its local default to be used when the ELS10-26 reboots, unless noted otherwise. • Obtain the current value of certain parameters and...
  • Page 18 SetRequest contains two parameters with an incorrect value specified for the second parameter, the ELS10-26 returns a badValue error to the NMS; however, the ELS10-26 may have updated its value for the first parameter. • The values within the variable bindings of the returned GetResponse may reflect meaningful information, rather than...

  • Page 19: Navigating Through The Mibtree Structure

    MIB, a group or table within that MIB, and then to the individual variable. Figure 1-1 shows the path down the MIB tree structure. Under the “mib-2” and the Cabletron enterprise branch, are all the relevant MIBs that the ELS10-26 supports.
  • Page 20 1.3.6.1.2.1. For example, to reach an object in the system group, you would start with 1.3.6.1.2.1.1. To find the amount of time the ELS10-26 had been running, you would want to get the sysUpTime variable, which is the third object in the system group. So the get command would look like: get 1.3.6.1.2.1.1.3.0...
  • Page 21 CMIP over TCP (CMOT) Transmission SNMP GenericIF AppleTalk Open Shortest Path First (OSPF) Border Gateway Protocol (BGP) Remote Network Monitoring (RMON) Bridge There are additional groups under MIB-II, but all groups are not supported by the ELS10-26. Introduction Number (1.3.6.1.2.1.) 1-11...
  • Page 22 Cabletron MIB variable. You would then add the specific object ID to complete the MIB variable. For example, to find the sysID currently defined in the ELS10-26, you would want to get the sysID variable in the Cabletron MIB group and add it to the prefix 1.3.6.1.4.97.

  • Page 23: Tftp

    TFTP (Trivial File Transfer Protocol, RFC 1350) is used for: • Distribution of new software. • Bulk retrieval of all of the parameters of a ELS10-26. • Bulk setting of all of the parameters of a ELS10-26. TFTP has no inherent security provision; however, all files have special data encryption, and the ELS10-26 will reject files that have...
  • Page 24 If the bulk retrieval of all of the parameters of the ELS10-26 had been performed while the ELS10-26 was executing that older software, that retrieved file should be used to do a bulk set of all parameters (as described below).

  • Page 25: Retrieving All Parameters

    1.8.1 Retrieving All Parameters TFTP is used for retrieval of the parameters of an ELS10-26, as follows 1. Start TFTP (as described earlier). TFTP must be told the IP address of the remote host (i.e., the ELS10-26), and the file transfer mode (which must be “binary”).

  • Page 26: Additional Interfaces

    Introduction 1.9 ADDITIONAL INTERFACES In addition to SNMP and TFTP, the ELS10-26 employs the following protocols, as part of its software interface with an NMS: • UDP - User Datagram Protocol, RFC 768. • IP - Internet Protocol, RFC 791.

  • Page 27: Tcp/Ip Mib-Ii

    The ELS10-26 supports the TCP/IP MIB-II, as defined by Management Information Base for Network Management of TCP/ IP-based Internets MIB-II, RFC 1213 (K. McCloghrie, editor), dated March 1991. The MIB is divided into groups of parameters. The individual groups are described in the subsections below. You may...

  • Page 28: Interfaces Group

    TimeTicks Read-Only The time, in centiseconds, since the ELS10-26 was last booted. sysContact DisplayString Read-Write The name and address of the contact person for the ELS10-26. sysName DisplayString Read-Write The Internet name of the contact person for the ELS10-26. The LCM prompt consists of sysName followed by “>”.
  • Page 29 ifNumber Integer Read-Only The number of ports (whether alive or dead), including the UART. ifTable Not Accessible A list of interface entries; one per port (ifNumber in total). ifEntry Not Accessible A set of objects for an interface entry. The individual components are described below.
  • Page 30 TCP/IP MIB-II ifDescr DisplayString Read-Only A textual description of the port. One of the following text strings: • Ethernet/802.3 TP • Network Management Port (this is the UART port) • Fast Ethernet/802.3u TP (twisted pair connection) • Fast Ethernet/802.3u FX (fiber connection) •...
  • Page 31 ifPhysAddress Physical Address Read-Write The MAC address of the port. For the UART port, this field should be an octet string of zero length. ifAdminStatus Integer Read-Write The desired state of the port, i.e., one of the following: • up (1) - setting the port’s state to up causes the port’s statistics to be reset •...
  • Page 32 FCS, but not counting the bytes in packets that were rejected due to hardware errors. All counters are 32-bit wide wrap-around counters which can only be reset by restarting the port or by rebooting the ELS10-26. ifInUcastPkts Counter Read-Only The number of non-multicast packets received by the port, regardless of the packet’s outcome (i.e., whether the packet was...
  • Page 33 The number of packets to be transmitted out the port, but were not transmitted due to non-error reasons. The definition of non-error reasons is implementation dependent. The ELS10-26 defines non-error reasons as packet congestion. Packet congestion occurs when too many packets are to be queued for transmission, or when packets have been awaiting transmission for too long a time period.

  • Page 34: Address Translation Group

    2.3 ADDRESS TRANSLATION GROUP The TCP/IP Address Translation Group parameters are minimally supported (i.e., for any parameter in this group, the ELS10-26 returns a GetResponse with a noSuchName ErrorStatus). It is anticipated that the Address Translation Group will be deleted...

  • Page 35: Ip Group

    The TCP/IP IP Group parameters are described below. ipForwarding Integer Read-Write Whether the ELS10-26 is an IP router. This value is always host (2). Attempts to write a different value to this field will not change its value, and “badValue” GetResponse PDUs are returned for all such SetRequest PDUs.
  • Page 36 IP destination. ipInUnknownProtos Counter Read-Only The number of packets received that were addressed to this ELS10-26’s IP, but were discarded because of an unknown or unsupported protocol. ipInDiscards Counter Read-Only The number of packets that were received without error, but were not processed (due to insufficient resources, for example).
  • Page 37 The total number of input packets successfully delivered to the IP user-protocol layers. ipOutRequests Counter Read-Only The total number of IP output packets generated by this ELS10-26. This count does not include any packets represented in ipForwDatagrams. ipOutDiscards Counter Read-Only The total number of output packets which were discarded (due to lack of resources, for example).

  • Page 38: Ip Address Table

    Counter Read-Only The number of IP datagrams that have been successfully fragmented within this ELS10-26. ipFragFails Counter Read-Only The number of IP datagrams that have been discarded because they needed to be fragmented but could not be (e.g., because their “Don’t Fragment”...
  • Page 39 The network/subnet mask associated with the IP address. For SetRequests, a mask of zero may be specified, in which case, the ELS10-26 will create the correct network mask for a non-subnetted network. For GetRequests, the ELS10-26 will always convert a value of zero into the correct network mask.

  • Page 40: Ip Routing Table

    2.4.2 IP Routing Table The TCP/IP IP routing table contains the routing information for each route currently known by the ELS10-26. When adding a row, the entire row must be specified, except for the following defaults: • ipRouteDest is obtained from the row’s instance identifier.
  • Page 41 for the same IP address, then only the entry being used by the IP forwarding process is available for SNMP access. ipRouteEntry Not Accessible A set of objects for an ipRouteTable entry. The individual components are described below. ipRouteDest IP Address Read-Write The destination IP address of this route.
  • Page 42 TCP/IP MIB-II ipRouteNextHop IP Address Read-Write The IP address of the route’s next hop. ipRouteType Integer Read-Write The type of the route, one of the following: • other (1) - none of the below. • invalid (2) - the entry should be considered to be non-existent. •...

  • Page 43: Ip Address Translation Table

    A reference to additional MIB definitions, specific to the routing protocol which is responsible for this route. This information is not present in the ELS10-26, so ipRouteInfo should be set to the object identifier {0 0}. 2.4.3 IP Address Translation Table...

  • Page 44: Ip Additional Objects

    TCP/IP MIB-II ipNetToMediaEntry Not Accessible A set of objects for an ipNetToMediaTable entry. The individual components are described below. ipNetToMediaIfIndex Integer Read-Write The port number for which this entry is effective. ipNetToMediaPhysAddress Physical Address Read-Write The MAC address (for the PPP port, this should be a zero length octet string;...

  • Page 45: Icmp Group

    The TCP/IP ICMP Group parameters are described below. icmpInMsgs Counter Read-Only The total number of ICMP messages which were received by this ELS10-26. This includes all messages represented by icmpInErrors. icmpInErrors Counter Read-Only The number of ICMP messages which were received with errors (bad checksums, bad length, etc.).
  • Page 46 TCP/IP MIB-II icmpInSrcQuenchs Counter Read-Only The number of ICMP “Source Quench” messages received. icmpInRedirects Counter Read-Only The number of ICMP “Redirect” messages received. icmpInEchos Counter Read-Only The number of ICMP “Echo (request)” messages received. icmpInEchoReps Counter Read-Only The number of ICMP “Echo Reply” messages received. icmpInTimestamps Counter Read-Only The number of ICMP “Timestamp (request)”...
  • Page 47 The total number of ICMP messages which were sent by this ELS10-26. This includes all messages counted by icmpOutErrors. icmpOutErrors Counter Read-Only The number of ICMP messages which this ELS10-26 did not send due to problems discovered entirely within the ICMP subsystem (such as lack of buffers). icmpOutDestUnreachs Counter Read-Only The number of ICMP “Destination Unreachable”...

  • Page 48: Tcp Group

    Counter Read-Only The number of ICMP “Address Mask Reply” messages sent. 2.6 TCP GROUP The TCP Group is not supported since the ELS10-26 does not support TCP. 2.7 UDP GROUP The TCP/IP UDP Group parameters are described below. 2-22...

  • Page 49: Udp Listener Table

    Counter Read-Only The total number of UDP datagrams sent from this ELS10-26. 2.7.1 UDP Listener Table The TCP/IP UDP Listener Table parameters are described below. udpTable Not Accessible A table containing UDP listener information.

  • Page 50: Egp Group

    The UDP port number, i.e., one of 69, 161, and 520. Note that reception of SNMP Traps (UDP port number 162) is not supported by the ELS10-26. 2.8 EGP GROUP The EGP Group is not supported since the ELS10-26 does not support EGP. 2.9 OIM SUBTREE cmot The OSI Subtree, as defined in OSI internet management,...

  • Page 51: Snmp Management Group

    Counter Read-Only The number of SNMP PDUs created by the ELS10-26. snmpInBadVersions Counter Read-Only The number of SNMP PDUs received by the ELS10-26 which had an unsupported SNMP version. snmpInBadCommunityNames Counter Read-Only The number of SNMP PDUs received by the ELS10-26 which had an unrecognized SNMP community name.
  • Page 52 Always zero, since the ELS10-26 ignores all SNMP response PDUs. snmpInTotalReqVars Counter Read-Only The total number of MIB objects which have been successfully retrieved by the ELS10-26 as a result of SNMP GetRequest or GetNext PDUs. 2-26 {snmp 7} {snmp 8}...
  • Page 53 Counter Read-Only Always zero, since the ELS10-26 ignores all SNMP Trap PDUs. snmpOutTooBigs Counter Read-Only The total number of SNMP PDUs created by the ELS10-26, with a value of “tooBig” in the PDU’s “ErrorStatus”. TCP/IP MIB-II {snmp 14} {snmp 15}...
  • Page 54 TCP/IP MIB-II snmpOutNoSuchNames Counter Read-Only The total number of SNMP PDUs created by the ELS10-26, with a value of “noSuchName” in the PDU’s “ErrorStatus”. snmpOutBadValues Counter Read-Only The total number of SNMP PDUs created by the ELS10-26, with a value of “badValue” in the PDU’s “ErrorStatus”.

  • Page 55: Cabletron Interface Group

    The total number of SNMP GetResponse PDUs created by the ELS10-26. snmpOutTraps Counter Read-Only The total number of SNMP Trap PDUs created by the ELS10-26. snmpEnableAuthenTraps Integer Read-Write Whether authentication failures should cause the ELS10-26 to generate authentication-failure Trap PDUs. Values include: •...
  • Page 56 TCP/IP MIB-II ctIfNumber This defines the interface that is being described. This is the same as IfIndex. SYNTAX INTEGER ACCESS read-only STATUS mandatory ctIfPortCnt This defines the number of ports on the interface that are being described. SYNTAX INTEGER ACCESS read-only STATUS mandatory ctIfConnectionType This defines the specific type of interface connection (BRIM, etc.).
  • Page 57 interface has been closed and then opened again. A read of ctIfLAA will always return the same values as IfPhysAddress, except in the case where; o ctIfLAA has been set, but interface has not yet been closed and reopened, in this case the last set value is returned.

  • Page 58: Cabletron Interface Port Group

    TCP/IP MIB-II SYNTAX INTEGER {other (1), standard (2), fullDuplex ACCESS read-only STATUS mandatory OBJECT IDENTIFIER: 1.3.6.1.4.1.52.4.3.3.2.1.1.6 The OID will actually be 1.3.6.1.4.1.52.4.3.3.2.1.1.6.X where X is the interface number (port number) requested. It will report fullDuplex (3) on our ethernet ports, and fastEthernet (4) on our fast ethernet ports.
  • Page 59 ctIfPortPortNumber ctIfPortPortNumber This defines the port that is being described. SYNTAX INTEGER ACCESS read-only STATUS mandatory OBJECT IDENTIFIER: 1.3.6.1.4.1.52.4.3.3.3.1.1.1 The OID will actually be 1.3.6.1.4.1.52.4.3.3.3.1.1.1.X.Y where X is the interface number and Y is the port requested. X will increment from 1 to 28 (25 Ethernet, 2 Fast Ethernet, and the LCM port).
  • Page 60 TCP/IP MIB-II ctIfPortType DESCRIPTION This defines the specific type of port (EPIM, TPIM). This is defined within ctron-oids. SYNTAX OBJECT IDENTIFIER ACCESS read-only STATUS mandatory OBJECT IDENTIFIER: 1.3.6.1.4.1.52.4.3.3.3.1.1.3 The OID will actually be 1.3.6.1.4.1.52.4.3.3.3.1.1.1.X.Y where X is the interface number and Y is the port requested. X will increment from 1 to 28 (25 Ethernet, 2 Fast Ethernet, and the LCM port).

  • Page 61: Cabletron Com Port Configuration Group

    2.14 CABLETRON COM PORT CONFIGURATION GROUP ctCpTable This table defines a Com Port Table. SYNTAX SEQUENCE OF ctCPEntry ACCESS not accessible STATUS mandatory OBJECT IDENTIFIER: 1.3.6.1.4.1.52.4.3.3.4.1 ctCpEntry This defines each conceptual row within the ctCpTable. SYNTAX ctCpEntry ACCESS not accessible STATUS mandatory OBJECT IDENTIFIER: 1.3.6.1.4.1.52.4.3.3.4.1.1 INDEX...
  • Page 62 TCP/IP MIB-II ctCpFunction DESCRIPTION This defines the Com Port Function supported by that Com Port. SYNTAX INTEGER {lm(1), ups(2), slip(3), ppp(4)} ACCESS read-write STATUS mandatory OBJECT IDENTIFIER: 1.3.6.1.4.1.52.4.3.3.4.1.1.2 The OID will actually be 1.3.6.1.4.1.52.4.3.3.4.1.1.2.1 because there is only one UART port. We support LM and PPP simultaneously. If we detect a PPP packet we do negotiations and enter into PPP mode.

  • Page 63: Snmp Version Group

    ctCpAdminStatus DESCRIPTION The administrative state of the Com Port. SYNTAX INTEGER {disabled(1), enabled(2)} ACCESS read-only STATUS mandatory OBJECT IDENTIFIER: 1.3.6.1.4.1.52.4.3.3.4.1.1.4 The OID will actually be 1.3.6.1.4.1.52.4.3.3.4.1.1.4.1 because we only have the one UART port. We don’t allow this port to be turned on or off. Because of this, it will be READ-ONLY.

  • Page 64: Trap Description

    TCP/IP MIB-II STATUS mandatory 2.16 TRAP DESCRIPTION InterfacePortInsertion Not Supported. Specific Trap Type Code - 0x1A0 This trap will be generated when it is detected that an interface port has been inserted. The information will include: ctIfNumber ctIfPortNumber ctPortType Specific Trap Type Code - 0x1A1 This trap will be generated when it is detected that an interface port has been removed.

  • Page 65: Cabletron Mib 2 Extensions

    InterfacePortLinkDown Specific Trap Type Code - 0x1A3 This trap will be generated when a previously attached bridging port has been disconnected from a LAN. This is only appropriate for ports that support the concept of a link state. The information will include: ctIfNumber ctIfPortPortNumber...
  • Page 66 TCP/IP MIB-II This MIB defines Cabletron extensions to MIB-II. Groups within this MIB refer to the group in which the objects pertain within MIB-II. Groups within this MIB are: commonDevOBJECT IDENTIFIER ctIfPortOBJECT IDENTIFIER ctIfPortOBJECT IDENTIFIER ctIfCpOBJECT IDENTIFIER ctSNMP OBJECT IDENTIFIER ctSONET OBJECT IDENTIFIER The commonDevice group of this group is an extension to the system group MIB2.
  • Page 67 OBJECT-TYPE SYNTAX DisplayString(SIZE (8)) ACCESS STATUS DESCRIPTION ::= {commonDev 2} comDeviceBoardMap OBJECT-TYPE SYNTAXINTEGER ACCESS STATUS DESCRIPTION ::= {commonDev 3} ctIF group implementation of this group is optional. The ctIf group contains information about the type of interface, i.e. the type of BRIM etc. This information is not available in the interface group of MIB-II.
  • Page 68 TCP/IP MIB-II ::= {ctIf 1} ctIfEntry OBJECT-TYPE SYNTAXCtIfEntry ACCESS STATUS DESCRIPTION INDEX ::= {ctIfTable 1} CtIfEntry::= SEQUENCE {ctIfNumber INTEGER, ctIfPortCnt INTEGER, ctIfConnectionType OBJECT IDENTIFIER, ctIfLAA OCTET STRING, ctIfDuplex INTEGER, ctIfCapability INTEGER, ctIfRedundancy INTEGER } ctIfNumber OBJECT-TYPE SYNTAXINTEGER ACCESS STATUS DESCRIPTION 2-42 not accessible mandatory...
  • Page 69 ::= {ctIfEntry 1} ctIfPortCnt OBJECT-TYPE SYNTAXINTEGER ACCESS STATUS DESCRIPTION INDEX ::= {ctIfEntry 2} ctIfConnectionType OBJECT-TYPE SYNTAXOBJECTIDENTIFIER ACCESS STATUS DESCRIPTION INDEX ::= {ctIfEntry 3} ctIfLAA OBJECT-TYPE SYNTAXOCTET STRING (SIZE (6)) ACCESS read-only mandatory This defines the number of ports on the interface that is being described. {ctIfNumber} read-only mandatory...
  • Page 70 TCP/IP MIB-II STATUS DESCRIPTION For devices that do not support LAA: a read will return all zeroes any write attempt will return BADVALUE For devices that suport LAA: valid values are 4000 0000 0000 to 4000 7fff ffff, and 0000 0000 0000 (a value of all zeroes causes interface to use the burned-in address).
  • Page 71 STATUS DESCRIPTION For devices that do not support this capability: a read will return standard (2). any write attempt will return BADVALUE. fast ethernet devices will report other (1). ::= {ctIfEntry 5} ctIfCapability OBJECT-TYPE SYNTAXINTEGER {other (1), standard (2), full duplex ACCESS STATUS DESCRIPTION...
  • Page 72 TCP/IP MIB-II DESCRIPTION ::= {ctIfEntry 7} ctIfPort group implementation of this group is optional The ctIfPort group contains information about the type of port on the interface i.e., the type of EPIM,TPIM etc. This information is not available in the interface group of MIB-II. ctIfPortTable OBJECT-TYPE SYNTAXSEQUENCEOF CtIfPortEntry...
  • Page 73 ::= {ctIfPortTable 1} ctIfPortEntry::= SEQUENCE {ctIfPortPortNumber INTEGER, ctIfPortIfNumber INTEGER, ctIfPortType OBJECT IDENTIFIER, ctIfPortLinkStatus INTEGER} ctIfPortPortNumber OBJECT-TYPE SYNTAX INTEGER ACCESS STATUS DESCRIPTION ::= {ctIfPortEntry 1} ctIfPortIfNumber OBJECT-TYPE SYNTAX INTEGER ACCESS STATUS DESCRIPTION read-only mandatory This defines the port being described. read-only mandatory This defines the interface that the port being described is on.
  • Page 74 TCP/IP MIB-II ::= {ctIfPortEntry 2} ctIfPortType OBJECT-TYPE SYNTAX ACCESS STATUS DESCRIPTION ::= {ctIfPortEntry 3} ctIfPortLinkStatus OBJECT-TYPE SYNTAX INTEGER ACCESS STATUS DESCRIPTION ::= {ctIfPortEntry 4} ctIfPort group implementation of this group is optional The ctIfCp group contains information about the com port configuration on the MMAC Management Modules (i.e., EMME, TRMM) and on the MMAC-Plus Environmental Module.
  • Page 75 ACCESS STATUS DESCRIPTION ::= {ctIfCp 1} ctCpEntry OBJECT-TYPE SYNTAX ACCESS STATUS DESCRIPTION INDEX ::= {ctCpTable 1} ctCpEntry::= SEQUENCE {ctComPort INTEGER, ctCpFunction INTEGER, ctIfNum INTEGER, ctCpAdminStatus INTEGER} ctComPort OBJECT-TYPE SYNTAXINTEGER ACCESS STATUS DESCRIPTION not accessible mandatory This table defines a Com Port Table. CtCpEntry not accessible mandatory...
  • Page 76 TCP/IP MIB-II {ctCpEntry 1} ctCpFunction OBJECT-TYPE SYNTAXINTEGER {lm(1), Local Management (default), ACCESS STATUS DESCRIPTION {ctCpEntry 2} ctIfNum OBJECT-TYPE SYNTAXINTEGER ACCESS STATUS DESCRIPTION {ctCpEntry 3} ctCpAdminStatus OBJECT-TYPE SYNTAXINTEGER {disabled (1), enabled (2) (default)} ACCESS 2-50 is being described. com1 = 1, com2 = 2 ups (2) UPS, slip (3) SLIP, ppp (4) PPP}...
  • Page 77 STATUS DESCRIPTION {ctCpEntry 4} The SNMP group. Implementation of this group is mandatory when the SNMPv2 protocol is present within the device. enableSNMPv1 OBJECT-TYPE SYNTAXINTEGER {disable (1), enable (2)} ACCESS STATUS DESCRIPTION {ctSNMP 1} enableSNMPv2 OBJECT-TYPE SYNTAXINTEGER {disable (1), enable (2)} ACCESS STATUS DESCRIPTION...
  • Page 78 TCP/IP MIB-II {ctSNMP 2} {ctSNMP 3} is obsolete The ctSonet group is an optional group. It contains information pertaining to the optical connectivity speed. ctSonetEntry OBJECT-TYPE SYNTAXSEQUENCEOF CtSonetEntry ACCESS STATUS DESCRIPTION INDEX {ctSonetTable 1} CtSonetEntry::= SEQUENCE {ctSonetIfIndex INTEGER, ctSonetMediumType INTEGER} ctSonetIfIndex OBJECT-TYPE SYNTAX...
  • Page 79 {ctSonetEntry 1} ctSonetMediumType OBJECT-TYPE SYNTAX INTEGER ACCESS STATUS DESCRIPTION {ctSonetEntry 2} Trap description InterfacePortInsertion Specific Trap Type Code- 0x1A0 This trap will be generated when it is detected that an interface port has been inserted. The interesting information will include: ctIfNumber {ctIfEntry 1}, ctIfPortPortNumber Trap description InterfacePortInsertion...
  • Page 80 TCP/IP MIB-II Specific Trap Type Code - 0x1A2 This trap will be generated when it is determined that a port on a strictly bridging interface (not a “repeater”) has been connected to a LAN. This is only appropriate for ports that support the concept of a link state.

  • Page 81: Chapter 3 Ethernet Mib

    The ELS10-26 supports the Ethernet MIB as defined in Definitions of Managed Objects for the Ethernet-like Interface Types, RFC 1284 (J. Cook, editor), dated December 1991. The MIB tree prefix for reaching the GenericIF group is: 1.3.6.1.2.1.12. 3.1 GENERIC ETHERNET-LIKE GROUP...

  • Page 82: Ethernet-Like Statistics Group

    Ethernet MIB dot3MACSubLayerStatus Integer Read-Write Treated identically to dot3InitializeMAC. Values include: • enabled (1) • disabled (2) dot3MulticastReceiveStatus Integer Read-Write Whether the port is able to receive multicasts. This is always enabled when the port is enabled, and always disabled when the port is disabled.
  • Page 83 Not Accessible A set of statistics for an Ethernet entry. The individual components are described below. dot3StatsIndex Integer Read-Only The ELS10-26’s Ethernet port number. dot3StatsAlignmentErrors Counter Read-Only Number of received packets with frame alignment errors since the port was last enabled.
  • Page 84 Counter Read-Only The number of times that a late collision was detected while the ELS10-26 was transmitting a frame. dot3StatsExcessiveCollisions Counter Read-Only The number of times a frame transmission attempt experienced excessive collisions, since the port was last enabled.

  • Page 85: Ethernet-Like Collision Statistics Group

    The number of times a frame reception failed due to an error condition not already accounted for, since the port was last enabled. 3.3 ETHERNET-LIKE COLLISION STATISTICS GROUP dot3CollTable This group is minimally supported (i.e., the ELS10-26 returns a GetResponse with a noSuchName ErrorStatus). Ethernet MIB {dot3StatsEntry 12} {dot3StatsEntry 13}...

  • Page 86: Ethernet-Like Tests Group

    Ethernet MIB 3.4 ETHERNET-LIKE TESTS GROUP dot3Tests There are no MIB variables in this group. 3.5 ETHERNET-LIKE ERRORS GROUP dot3Errors There are no MIB variables in this group. 3.6 ETHERNET-LIKE CHIPSETS GROUP dot3ChipSets There are no MIB variables in this group. {{dot3 6} {dot3 7} {dot3 8}...

  • Page 87: Chapter 4 Bridge Mib

    The ELS10-26 supports the Bridge MIB {mib-2 17} as defined in Definitions of Managed Objects for Bridges, RFC 1286 (Decker, Langille, Rijsinghani, and McCloghrie, editors). The MIB tree prefix for reaching the Bridge MIB-II is: 1.3.6.1.2.1.17 4.1 BASE GROUP dot1dBase...
  • Page 88 Not Accessible A table that contains generic information about every port that is associated with this bridge. All ELS10-26 Ethernet ports are included in this table, regardless of whether any form of bridging is currently enabled for the ports. dot1dBasePortEntry Not Accessible A list of information for each port of the bridge.

  • Page 89: Spanning Tree Group

    For example, in the case where multiple ports correspond one-to-one with multiple X.25 virtual circuits, this value might identify an (e.g., the first) object instance associated with the X.25 virtual circuit corresponding to this port. For a port which has a unique value of dot1dBasePortIfIndex, this object can have the value {0 0}.
  • Page 90 Bridge MIB dot1dStpPriority Integer Read-Write The value of the write-able portion of the Bridge ID, i.e., the first two octets of the (8 octet long) Bridge ID. The other (last) 6 octets of the Bridge ID are given by the value of dot1dBaseBridgeAddress. Any value from 0 to 65535 may be specified.
  • Page 91 Port number of this bridge’s current spanning tree root port, or 0, if this bridge is the current spanning tree root bridge. dot1dStpMaxAge Integer Read-Only The maximum age of Spanning Tree Protocol information learned from the network on any port before it is discarded, in units of hundredths of a second.
  • Page 92 Bridge MIB and all others would start using if/when this bridge were to become the root. dot1dStpBridgeMaxAge Time Ticks Read-Write The value that all bridges use for MaxAge when this bridge is acting as the root. Note that 802.1d/D9 specifies that the range for this parameter is related to the value of dot1dStpBridgeHelloTime.
  • Page 93 Not Accessible A table that contains port-specific information for the Spanning Tree Protocol. All ELS10-26 ports, except for the last port (port 25), are included in this table, regardless of whether the Spanning Tree Protocol is currently enabled for the ports.
  • Page 94 (1). dot1dStpPortEnable Integer Read-Write The enabled/disabled status of the port. The ELS10-26 does not change the parameter’s value when processing a SetRequest - refer to the lxsprotoBridge parameter in Cabletron’s enterprise-specific MIB for the SetRequest capabilities. dot1dStpPortPathCost...

  • Page 95: Transparent Group

    dot1dStpPortDesignatedCost Integer Read-Only The path cost of the Designated Port of the segment connected to this port. This value is compared to the Root Path Cost field in received bridge PDUs. dot1dStpPortDesignatedBridge Octet String Read-Only The Bridge Identifier of the bridge which this port considers to be the Designated Bridge for this port’s segment.
  • Page 96 Bridge MIB dot1dTpAgingTime Integer Read-Write The timeout period in seconds for aging out dynamically learned forwarding information. dot1dTpFdbTable Not Accessible A table that contains information about unicast entries for which the bridge has forwarding and/or filtering information. This information is used by the transparent bridging function in determining how to propagate a received frame.
  • Page 97 dot1dTpFdbStatus Integer Read-Only The status of this entry. The meanings of the values are other (1) none of the following. This would include the case where some other MIB object (not the corresponding instance of dot1dTpFdbPort, nor an entry in the dot1dStaticTable) is being used to determine if and how frames addressed to the value of the corresponding instance of dot1dTpFdbAddress are being forwarded.
  • Page 98 Bridge MIB dot1dTpPortMaxInfo Integer Read-Only The maximum size of the INFO (non-MAC) field that this port will receive or transmit. The type/length field (2 octets) in Ethernet/802.3 packets are considered to be part of the MAC header. dot1dTpPortInFrames Counter Read-Only The number of frames that have been received by this port from its segment.

  • Page 99: Chapter 5 Ppp Mib

    The ELS10-26 supports RFC 1471 for PPP link control and RFC 1473 for PPP IP support. The MIB tree for reaching the PPP group is: 1.3.6.1.2.1.10 5.1 PPP LINK CONTROL TABLE pppLCP pppLinkStatusTable Not-Accessible A table containing PPP-Link specific variables for this PPP implementation.
  • Page 100 PPP MIB ifSpecific.987 would contain the OBJECT IDENTIFIER for the serial-port’s media-specific MIB. pppLinkStatusBadAddresses Counter Read-only The number of packets received with an incorrect address field. This counter is a component of the ifInErrors variable that is associated with the interface that represents this PPP Link. pppLinkStatusBadControls Counter Read-only The number of packets received on this link with an incorrect...
  • Page 101 the local PPP entity. The value of this object is meaningful only when the link has reached the open state (ifOperStatus is up). Set to 8192 for the maximum HIOM frame size. pppLinkStatusRemoteMRU Integer Read-only The current value of the MRU for the remote PPP Entity. This value is the MRU that the local entity is using when sending packets to the remote PPP entity.
  • Page 102 PPP MIB • enabled (1) - supports protocol compression. • disabled (2) - no support for protocol compression. pppLinkStatusRemoteToLocalProtocolCompression Integer Read-only Indicates whether the remote PPP entity will use Protocol Compression when transmitting packets to the local PPP entity. The value of this object is meaningful only when the link has reached the open state (ifOperStatus is up).
  • Page 103 entity. The value of this object is meaningful only when the link has reached the open state (ifOperStatus is up). • enabled (1) - supports ACC map compression. • disabled (2) - no support for ACC map compression. pppLinkStatusTransmitFcsSize Integer Read-only The size of the Frame Check Sequence (FCS) in bits that the local node will generate when sending packets to the remote node.
  • Page 104 PPP MIB pppLinkConfigInitialMRU Integer Read-Write The initial Maximum Receive Unit (MRU) that the local PPP entity will advertise to the remote entity. If the value of this variable is 0 then the local PPP entity will not advertise any MRU to the remote entity and the default MRU will be assumed.
  • Page 105 PPP specification. Changes to this object take effect when the link is next restarted. • true (2) - ELS10-26 will attempt to perform magic number negotiation • false (1) - will not attempt to perform Magic Number negotiation pppLinkConfigFcsSize...
  • Page 106 PPP MIB pppLqrQuality Integer Read-only The current quality of the link as declared by the local PPP entity’s Link-Quality Management modules. No effort is made to define good or bad, nor the policy used to determine it. The not-determined value indicates that the entity does not actually evaluate the link’s quality.
  • Page 107 Not-Accessible Table containing the LQR configuration parameters for the local PPP entity. The ELS10-26 always has an empty table. pppLqrConfigEntry Not-Accessible LQR configuration information for a particular PPP link. pppLqrConfigPeriod Integer Read-Write The LQR reporting period that the local PPP entity will attempt to negotiate with the remote entity, in units of hundredths of a second.

  • Page 108: Ppp Ip Table

    Not-Accessible Table containing additional LQR information for the local PPP entity. The ELS10-26 always has an empty table. pppLqrExtnsEntry Not-Accessible Extended LQR information for a particular PPP Link. Assuming that this group has been implemented, a PPP Link will have an entry in this table if and only if LQR Quality Monitoring has been successfully negotiated for the specified link.
  • Page 109 • none (1) - no IP compression protocol supported. • vj-tcp(2) - the Van Jacobsen TCP/IP header compression protocol is supported. The ELS10-26 does not support protocol compression. pppIpRemoteToLocalCompressionProtocol{pppIpEntry 3} Integer Read-only The IP compression protocol that the remote PPP-IP entity uses when sending packets to the local PPP-IP entity.
  • Page 110 PPP MIB • vj-tcp(2) - the Van Jacobsen TCP/IP header compression protocol is supported. pppIpRemoteMaxSlotId Integer Read-only The Max-Slot-Id parameter that the remote node has advertised and that is in use on the link. If vj-tcp header compression is not in use on the link then the value of this object shall be 0.
  • Page 111 PPP MIB network protocol’s finite state machine. The ELS10-26 only supports open (1). pppIpConfigCompression {pppIpConfigEntry 2} Integer Read-Write If none (1), then the local node will not attempt to negotiate any IP Compression option. Otherwise, the local node will attempt to negotiate compression mode indicated by the enumerated value.
  • Page 112 PPP MIB 5-14...

  • Page 113: Chapter 6 Els10-26 Mib

    Integer Read-Only An integer which serves to identify the type of hardware platform. This document describes the es-1xe-bridge, which uses the value (7) for sysID. Special third-party versions of the ELS10-26 may use different values (3, 4, or 5). sysReset Time Ticks Read-Write The time, in centiseconds, before the ELS10-26 should reboot.

  • Page 114: Hardware Configuration Group

    ELS10-26 MIB sysTrapPort Integer Read-Write zero, or the UDP port number to which a second copy of SNMP traps should be sent. Valid values are 0 through 65535. 6.1.1 Hardware Configuration Group lxhwDiagCode Octet String Read-Only This variable is for Cabletron internal use only.
  • Page 115 The unique hard-wired 48 bit MAC address for the port. lxhwUpLink Integer Read-Only An integer that specifies if the Fast Ethernet (FE) Up-Link module is installed. The following values have been defined: ELS10-26 MIB {lxhwPortEntry 2} {lxhwPortEntry 3} {lxhwPortEntry 4} {lxhwPortEntry 5}...

  • Page 116: Lxsw Configuration Group

    ELS10-26 MIB • true (1) • false (2) lxhwUpLinkManufData Octet String Read-Only A 32-byte array that contains the part number, serial number, and hardware revision level of the Up-Link I/O module. The array is valid only when the lxhwUpLink value is true. If lxhwUplink is false, it returns an error.
  • Page 117 The types of files within the file set. The size of lxswType may be determined by lxswCount, since 1 octet is required for each file. The possible file types are: • file-nam (1) - the operational software for the ELS10-26’s NAM processor. • file-powerup (10) - power-up diagnostics for the entire ELS10-26.

  • Page 118: Administration Group

    ELS10-26 MIB lxswBases Octet String Read-Only An array (4 octets per file), containing the software’s base loading address of each of the files. Each address is encoded as a series of 4 bytes, which should be converted into a 32-bit integer.
  • Page 119 Whether the ELS10-26’s storage facility for its configuration parameters has failed during the last update operation (if the ELS10-26 reboots after such a failure, it will use the factory specified defaults for all MIB parameters). Values include: • true (1) Certain SetRequest PDUs are used for read operations and using lxadminGetPass for the community name is sufficient.
  • Page 120 ELS10-26 MIB • false (2) lxadminAuthenticationFailure IP Address Read-Only All nulls, or the IP source address within the last SNMP PDU which caused an SNMP authentication failure. lxadminNAMReceiveCongests Counter Read-Only Number of packets not received due to internal buffer congestion.
  • Page 121 • no-change (1) – the ELS10-26 will not change its configuration parameters when it reboots. • tftp-config (2) – the ELS10-26 will use a file that was sent via TFTP when it reboots . • revert-to-defaults (3) – the ELS10-26 will revert to its factory specified defaults when it reboots .
  • Page 122 ELS10-26 MIB lxadminDisableButton Integer Read-Write An integer that can be set to prevent the push button on the front of the ELS10-26 from controlling the LED display. Values include: • true (1) • false (2) lxadminButtonSelection Integer Read-Write An integer that indicates which statistic has been selected. Values include: •...

  • Page 123: Software Distribution Group

    Octet String Read-Only The description (0-32 bytes) of the software set currently being downloaded, or a description of the software set last downloaded since the ELS10-26 booted. lxswdisAccess Integer Read-Write The version of software that may be downloaded. Attempts to download other versions of software will be rejected.
  • Page 124 NMS from obtaining access, while a value of 255.255.255.255 gives every NMS permission. lxswdisConfigRetryTime Integer Read-Write The number of seconds that the ELS10-26 will wait for an acknowledgment before it retransmits an unacknowledged TFTP data block. The factory specified default is 5 seconds. slxwdisConfigTotalTimeout...

  • Page 125: Addresses Configuration Group

    The number of learned addresses in the ELS10-26’s address table. lxaddrDynamicMax Gauge Read-Write The maximum number of spanning tree addresses which have been learned since the ELS10-26 was last booted (or this parameter was last reset by the NMS). lxaddrDynamicOverflows Counter Read-Write The number times an address was not learned due to insufficient...
  • Page 126 • Bits 9-0 are reserved. lxaddrMAC MAC Address Read-Write The MAC address for this address definition. lxaddrPort Integer Write-Ignore The port through which this address is connected to the ELS10-26 (only valid for entry-dynamic-local, entry-static and entry-port entries). 6-14 {lxaddr 6} {lxaddr 7}...
  • Page 127 • read-block (6) lxaddrIndex Integer Read-Write The index number to be used for read-next and read-block operations. When the ELS10-26 boots, lxaddrIndex is initialized to -1 lxaddrNext Integer Write-Ignore The next value to use for lxaddrIndex, when you use read-next or read-block operations to read the address table.

  • Page 128: Cabletron Interfaces Group

    ELS10-26 MIB port number. If the port number is zero, then the address is that of a specially configured address; otherwise, the address is a dynamically learned address. This parameter is only used for dumping blocks of MAC addresses. 6.1.6 Cabletron Interfaces Group...
  • Page 129 A value of zero will disable the lxifTxStormCnt Integer Read-Write The maximum number of multicasts to transmit with a certain period of time (not applicable for the UART port). ELS10-26 MIB {lxifEntry 4} {lxifEntry 5} alarm. sifThreshold {lxifEntry 6}...
  • Page 130 ELS10-26 MIB lxifTxStormTime Time Ticks Read-Write The period of time, in centiseconds, which qualifies sifTxStormCnt (not applicable for the UART port). llxifFunction Integer Read-Only The current functional state (protocols which have been activated and are operational) of the port. The following values or...
  • Page 131 The IP address assigned to the port. If this is zero, then the port must learn its IP address via Reverse ARP or PPP’s IPCP. lxifIpGroupAddr IP Address Read-Write Zero, or an IP group address assigned to the port. ELS10-26 MIB {lxifEntry 19} {lxifEntry 27} {lxifEntry 28} {lxifEntry 29}...

  • Page 132: Cabletron Dot3 Group

    ELS10-26 MIB lxifForwardedChars Counter Read-Only Number of characters in the forwarded received packets. lxifDesc lxifGoodRxFrames Counter Read-Only lxifGoodTxFrames Counter Read-Only 6.1.7 Cabletron Dot3 Group This group provides additional objects that are not part of the standard dot3 MIB. lxdot3Table Not Accessible A list of dot3 interfaces entries, one per dot3 port.
  • Page 133 (and discarded). lxdot3TxJabbers Counter Read-Only Counter indicating the number of packets transmitted with jabber errors. These statistics are only updated if the ELS10-26 has been configured to gather extended statistics (lxadminStatsExtended). ELS10-26 MIB {lxdot3Entry 3} {lxdot3Entry 4} {lxdot3Entry 5}...
  • Page 134 • duplex-auto (1) These statistics are only updated if the ELS10-26 has been configured to gather extended statistics (lxadminStatsExtended). 6-22 {lxdot3Entry 8}...

  • Page 135: Cabletron Uart Interface Group

    A set of objects for an interface entry. The individual components are described below. lxuartIndex Integer Read-Only The ELS10-26’s port number of the port. This is always 25. lxuartBaud Integer Read-Write This is the desired baud rate. Only 1200 baud through 19,200 baud are supported by the ELS10-26, but the complete set of possibilities •...

  • Page 136: Cabletron Protocol Group

    This table contains configuration information specifying the types of protocols used for each port. lxprotoEntry Not Accessible Each entry in this table specifies which protocols are used by a particular port in the ELS10-26. 6-24 {lxuartEntry 3} {lxuartEntry 4} {lxsproto 1}...
  • Page 137 Integer Read-Write Specifies whether the port should listen for internet RIP packets so the ELS10-26 can build a routing table for the unit. Values include: • enabled (1) • disabled (2) ELS10-26 MIB {lxsprotoEntry 1}...

  • Page 138: Cabletron Trunking Group

    ELS10-26 MIB lxprotoTrunking Integer Read-Write Specifies whether Cabletron’s trunking protocol (an extension to the standard Spanning Tree) is to be used over this port. Values include: • enabled (1) • disabled (2) lxprotoTransmitPacing Integer Read-Write When enabled, introduces delays into normal transmission of frames to reduce the probability of collisions during heavy traffic.
  • Page 139 • closed (2) – this link has not yet received any PDUs. • oneway (3) – incoming trunking PDUs do not indicate that the ELS10-26’s PDUs are being successfully received by the far end. • joined (4) – this link is actively participating in the trunk group.
  • Page 140 • too-many-groups(6) – the maximum number of groups a ELS10-26 can handle has been reached and a new group cannot be added. This port will not be used until the condition clears.

  • Page 141: Cabletron Workgroup Management Group

    Each entry in this table contains a definition of a workgroup. The lxWorkGroupNumber serves as the table index. The sequence of elements in the table is as follows: • lxWorkGroupNumber Integer Read-Write ELS10-26 MIB {lxtrunkEntry 7} {lxtrunkEntry 8} {lxworkgroup 1}...
  • Page 142 ELS10-26 MIB • lxWorkGroupName Display String Read-Write • lxWorkGroupPorts Octet String Read-Write • lxWorkGroupType Integer Read-Write • lxWorkGroupIpAddress IP Address Read-Write • lxWorkGroupIpMask IP Address Read-Write • lxWorkGroupIpxNetwork Octet String Read-write lxWorkGroupNumber Integer Read-Write An integer that identifies the workgroup and is used as an index to this table.

  • Page 143: Cabletron Trap Management Group

    6.1.12 Cabletron Trap Management Group This group presents the Cabletron MIB variables that are included as varbinds with the traps generated by the ELS10-26. Chapter 7 of this manual describes the traps generated by the ELS10-26. lxtrapControlTable Not Accessible This table contains information about the severity of each trap and whether the trap is currently enabled.
  • Page 144 ELS10-26 MIB • informational (1) • warning (2) • minor (3) • major (4) • critical (5) lxtrapText Display String Read-Only Provides a description of the trap. lxtrapSeverityControlTable Not Accessible This table contains information about whether traps of a particular severity are enabled or disabled.
  • Page 145 2 seconds, 4 seconds, 8 seconds, 16 seconds and then 32 seconds for all succeeding intervals. The default value is 1 retry. lxtrapEntryNumber Integer Read-Only The number of traps that are in the lxtrapTable. ELS10-26 MIB {lxtrapSeverityControl 2} {lxtrapMgt 3} {lxtrapMgt 4} {lxtrapMgt 5}...
  • Page 146 ELS10-26 MIB lxtrapTable Not Accessible This table contains the latest traps that have been generated. lxtrapEntryIndex Integer Read-Only The sequence of elements in the lxtrapControlTable 1 are shown below. A number representing the order (in time) in which the trap occurred.

  • Page 147: Ping Management Mib

    ECHO_RESPONSE or ECHO_REQUEST message), to when the lxpingEntry infor- mation for that ping request will be deleted. SEQUENCE OF lxpingEntry not-accessible mandatory The set of information describing the active ping requests and their results. lxpingEntry not-accessible mandatory ELS10-26 MIB 6-35...
  • Page 148 ELS10-26 MIB DESCRIPTION INDEX ::= {lxpingTable 1} lxpingEntry {lxpingNMSAddr lxpingDestAddr lxpingState lxpingCount lxpingDataSize lxpingWait lxpingTimeOut lxpingOperation lxpingMin lxpingMax lxpingAvg lxpingNumTransmitted INTEGER, lxpingNumReceived lxpingNMSAddr OBJECT-TYPE SYNTAX ACCESS STATUS DESCRIPTION 6-36 The parameters, state, and results of a ping request. {lxpingNMSAddr,lxpingDes- tAddr}...
  • Page 149 The IP address which is to be the destination of the ping ECHO_REQUEST. This variable cannot be set while lxpingOpera- tion is on. INTEGER {not-started (1) active (2) timed-out (3) completed (3)} read-only mandatory The current state of the ping request. INTEGER read-write mandatory ELS10-26 MIB 6-37...
  • Page 150 ELS10-26 MIB DESCRIPTION ::= {lxpingEntry 4} lxpingDataSize OBJECT-TYPE SYNTAX ACCESS STATUS DESCRIPTION ::= {lxpingEntry 5} lxpingWait OBJECT-TYPE SYNTAX ACCESS STATUS DESCRIPTION ::= {lxpingEntry 6} lxping TimeOut OBJECT-TYPE SYNTAX ACCESS 6-38 The number of ping requests which are to be sent. This vari- able cannot be set while lxping- Operation is on.
  • Page 151 Setting lxpingOperation to on will begin the ping request. Set- ting lxpingOperation to off will terminate the ping request. TimeTicks read-only mandatory The minimum round trip time for the ping requests and responses, in centiseconds. ELS10-26 MIB 6-39...
  • Page 152 ELS10-26 MIB ::= {lxpingEntry 9} lxpingMax OBJECT-TYPE SYNTAX ACCESS STATUS DESCRIPTION ::= {lxpingEntry 10} lxpingAvg OBJECT-TYPE SYNTAX ACCESS STATUS DESCRIPTION ::= {lxpingEntry 11} lxpingNumTransmitted OBJECT-TYPE SYTAX ACCESS STATUS DESCRIPTION 6-40 TimeTicks read-only mandatory The maximum round trip time for the ping requests and responses, in centiseconds.

  • Page 153: Traceroute

    6.1.14 Traceroute An implementation of traceroute was added in order to add the ability to orginate a traceroute request from the ELS10-26. The request can be started from LCM, or from SNMP. If the request is originated from the LCM, the results are printed out on the LCM console.

  • Page 154: Traceroute Management Mib

    ELS10-26 MIB 6.1.15 Traceroute Management MIB lxtraceDataTimout OBJECT-TYPE SYNTAX ACCESS STATUS DESCRIPTION ::= {lxtraceMgt 1} lxtraceTable OBJECT-TYPE SYNTAX ACCESS STATUS DESCRIPTION ::= {lxtraceMgt 2} lxtraceEntry OBJECT-TYPE SYNTAX ACCESS STATUS DESCRIPTION INDEX 6-42 TimeTicks read-write mandatory The time, in centiseconds, from...
  • Page 155 SYNTAX ACCESS STATUS IpAddress IpAddress INTEGER INTEGER INTEGER TimeTicks INTEGER INTEGER IpAddress INTEGER INTEGER TimeTicks} IpAddress read-only mandatory The IP address of the NMS, used to determine on which traceroute request to return information. IpAddress read-write mandatory ELS10-26 MIB 6-43...
  • Page 156 ELS10-26 MIB DESCRIPTION ::= {lxtraceEntry 2} lxtraceMaxTTL OBJECT-TYPE SYNTAX ACCESS STATUS DESCRIPTION ::= {lxtraceEntry 3} lxtraceDataSize OBJECT-TYPE SYNTAX ACCESS STATUS DESCRIPTION ::= {lxtraceEntry 4} lxtraceNumProbes OBJECT-TYPE SYNTAX ACCESS 6-44 The IP address which is to be the destination of the traceroute request.
  • Page 157 This variable cannot be set while lxOperation is on. INTEGER {on (1), off (2) } read-write mandatory Setting lxtraceOperation to on will begin the traceroute request. Setting lxtraceOperation to off will terminate the traceroute request. INTEGER read-only ELS10-26 MIB 6-45...
  • Page 158 ELS10-26 MIB STATUS DESCRIPTION ::= {lxtraceEntry 8} lxtraceHopAddress OBJECT-TYPE SYNTAX ACCESS STATUS DESCRIPTION ::= {lxtraceEntry 9} lxtraceProbe OBJECT-TYPE SYNTAX ACCESS STATUS DESCRIPTION ::= {lxtraceEntry 10} lxtraceState OBJECT-TYPE SYNTAX 6-46 mandatory The hop count for a set of probes with a particular TTL.

  • Page 159: Port Mirroring

    INTEGER {off (0), tx (1), rx (2) rx and tx (4) read-write mandatory To turn off port mirroring, or turn on by specifying rx, tx or rxandtx, which is the type of data to be mirrored. ELS10-26 MIB 6-47...
  • Page 160 ELS10-26 MIB ::= {lxmirrorgroup 1} lxmirrorTargetPort OBJECT-TYPE SYNTAX ACCESS STATUS DESCRIPTION ::= {lxmirrorgroup 2} 6-48 INTEGER read-write mandatory The number of the port whose data will be mirrored by the spe- cial mirror port.

  • Page 161: Chapter 7 Traps

    “variable-bindings” portion of the trap contains the ifIndex of the port. linkUp (3) - A port has come back to life, and the ELS10-26’s local management agent has re-enabled usage of the port. The “variable-bindings” portion of the trap contains the ifIndex of the port.

  • Page 162: Enterprise Specific Traps For The Els10-26

    The GetRequest exception is for one of the debugging attributes; those PDUs must always provide the lxadminAnyPass. egpNeighborLoss (5) - Not used by the ELS10-26. 7.2 ENTERPRISE SPECIFIC TRAPS FOR THE ELS10-26 This section lists the enterprise-specific traps that can be generated by the ELS10-26.
  • Page 163 Traps lxRxQuesTrap (4) - Sent whenever the number of times that the port’s receiver has missed receiving packets due to buffer space shortages has exceeded the port’s limit. Cabletron MIB variables include: • lxTrapSeverity • lxifRxQueues lxTxStormFlagTrap (5) - Sent whenever multicast storm protection has been invoked for the port.
  • Page 164 Traps • lxTrapSeverity • lxlpbkOperation • lxlpbkErrorNoReceives • lxlpbkErrorBadReceives lxTrunkStateTrap (10) - A trunking state change transition has occurred. The possible transitions are: • CLOSED-ONWAY • ONEWAY-PERTURBED • PERTURBED-JOINED • JOINED-HELDDOWN • CLOSED-HELDDOWN • ONEWAY-HELDDOWN • PERTURBED-HELDDOWN Cabletron MIB variables include: •...
  • Page 165 Traps lxTrunkIPAddrTrap (12) - The associated trunking IP address of the remote bridge has changed. Cabletron MIB variables include: • lxTrapSeverity • lxtrunkRemoteIP lxTrunkErrorTrap (13) - An error has occurred in trunking. Cabletron MIB variables include: • lxTrapSeverity • lxtrunkLastError lxTrunkLinkOrdinalTrap (14) - The port’s index in the trunking group has changed.
  • Page 166 Traps lxStorageFailureTrap (17) - Sent if the unit’s Configuration EEPROM has failed. Cabletron MIB variables include: • lxTrapSeverity lxPortCongestionTrap (18) - Sent whenever outbound congestion control has been invoked for the port. Cabletron MIB variables include: • lxTrapSeverity • ifOutDiscards lxTopChangeBegunTrap (19) - The spanning tree topology has begun to change.
  • Page 167 Traps lxStRootIDTrap (22) - The spanning tree root bridge ID has changed. Cabletron MIB variables include: • lxTrapSeverity • dot1dStpDesignatedRoot lxStRootCostTrap (23) - The unit’s spanning tree cost to the root bridge has changed. Cabletron MIB variables include: • lxTrapSeverity •...
  • Page 168 Traps • dot1dStpHelloTime lxStForwardDelayTrap (27) - The spanning tree forward delay time has changed. Cabletron MIB variables include: • lxTrapSeverity • dot1StpForwardDelay lxStDesigRootTrap (28) - The root bridge ID in received spanning tree configuration BPDUs from the port has changed. Cabletron MIB variables include: •...
  • Page 169 Traps lxStPortDesigPortTrap (31) - The port ID of the spanning tree des- ignated port of the LAN/WAN to which the port is attached has changed. Cabletron MIB variables include: • lxTrapSeverity • dot1dStpPortDesignatedPort lxStPortStateTrap (32) - The spanning tree state of the port has changed.
  • Page 170 Traps 7-10...

This manual is also suitable for:

Smartstack 10 els10-26

Table of Contents
