Anzzi SD-FRLS05901 Series Install & Operation Manual

Glass shower door
Hide thumbs
Table of Contents

Advertisement

Quick Links

Item: SD-FRLS05901**
SD-FRLS05902**
ANZZI GLASS SHOWER DOOR
INSTALL & OPERATION MANUAL
V1.0
DON'T WAIT!
REGISTER NOW!
Register your product within 90 days to ensure your product is
recognized as an official purchase and is eligible for warranty
coverage.
Mail in the completed registry card (Pg. 2) or register online
at
www.swcorp.com/register
.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SD-FRLS05901 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Anzzi SD-FRLS05901 Series

Summary of Contents for Anzzi SD-FRLS05901 Series

  • Page 1 Item: SD-FRLS05901** SD-FRLS05902** ANZZI GLASS SHOWER DOOR INSTALL & OPERATION MANUAL V1.0 DON’T WAIT! REGISTER NOW! Register your product within 90 days to ensure your product is recognized as an official purchase and is eligible for warranty coverage. Mail in the completed registry card (Pg. 2) or register online...
  • Page 2 I have read the Owner’s Manual carefully and understand and agree that any installation, operation or maintenance of the product must be done strictly in accordance with instructions and guidelines contained in the owner’s manual and installation guide. Signature____________________________________________________________Date ______________________________________________ Need help? For technical support call 305-614-4070 or visit us at www.ANZZI.com...
  • Page 3 INSTALLATION GUIDE BEFORE YOU BEGIN Please check the product for transit damage, missing parts immediately. Damage reported later cannot be accepted. Please handle the product with care. Avoiding any impact on all sides and edges of the glass. Consult your local plumbing codes prior to installation. To reduce the risk of breakage, keep corner protectors on glass while installing.
  • Page 4 INSTALLATION GUIDE BEFORE YOU BEGIN ATTENTION Threshold must be level for proper installation. The installation of this unit requires that you drill down into the threshold. Contact the manufacturer of the base, or threshold material with any questions regarding the drilling of holes into their product.
  • Page 5 PARTS [08A] x1 [08B] x1 [09] x2 [01] x2 [02] x2 [03] x1 [04] x2 [05] x4 [06] x1 [07] x1 [10A] x2 [10B] x2 [11A] x2 [11B] x2 [12] x2 [13A] x1 [13B] x1 [14] x12 [15] x4(ST4x [16] x2 [17] x1 [18] x1 [19] x2(ST3.5x...
  • Page 6 ASSEMBLY [15] [02] [13B] [13A] [14] [10B] [11B] [08A] [08B] [10A] [11A] [12] [05] [04] [01] [20] [21] [09] [18] [19] [07] [06] [17] [22] [14] [16] [03] Part Discription Qty. Part Discription Qty. [01] Wall Jamb [12] Wrench [02] Support Bar [13] Wall Bracket (L&R)
  • Page 7 SD-FRLS05901** 48"*76" 1.8"[45 [1209-1219 47.6"-48" 25.1"[638mm] 3"[75mm] 25.1"[638mm]...
  • Page 8 SD-FRLS05902** 60"*76" 1.8"[45 [1514-1524 59.6"-60" [790 31.1" 3"[75mm] [790 31.1"...
  • Page 9 ATTENTION To avoid personal injury or property damage, identify components and read all instructions before installing. This model requires a minimum 2-3/4”(70mm) of flat level threshold space for installation.4-1/8"(105mm) of flat level threshold space is better. (Dimension "D" of Fig 2.) INSTALLATION INSTRUCTIONS Step 1 This shower door must be installed into a stud.
  • Page 10 Step 2 1.Measure the finished opening width at the bottom("W2") and at the model height("W1"). IMPORTANT: No need for cutting if the Support Bar[02] and the Bottom Rail [03] match the width. If they don’t, please see Step 2.2 for cutting instructions. 2.Using a pencil or another marking tool (such as masking tape), mark distance "W1, subtract 1-1/8"(28.5mm) "...
  • Page 11 Step 3 1.Hold the Wall Bracket Assembly[13A] in the designated position(left side) and mark the holes for drilling(Fig 5.1). Drill a 1/4" hole at each location and insert the Wall Plugs[14](Fig 5.2,Fig 5.3). Attach the Wall Bracket Assembly[13A] using the FH Screw ST4x35[15](Fig 5.4).
  • Page 12 Step 4 1.Set the Bottom Rail [03] onto the threshold parallel with the outside edge. 2. Measure in 9/16"(14mm) min from the outside of the Wall to the Bottom Rail [03] and mark the position on the threshold(Fig 5). Or measure in 9/16"+ (A") if you want to install the shower door behind the outside of the wall.
  • Page 13 Step 5 1.Tear off the tape form the Bottom Rail [03] (Fig 7).Place the Bottom Rail [03] onto the marked position on the threshold(Fig 8). 2.Measure across the width of the threshold to locate and mark the center (Fig 9). Fig7 Fig8 center...
  • Page 14 Step 6 1.Place the Bottom Guide[17] onto the center of the Bottom Rail [03] and mark the hole for drilling( Fig 10.1 and Fig 10.2). Drill a 1/8" hole at each marked location if drilling into acrylic or wood material (Fig 10.3). Drill a 1/4" hole at each marked location if drilling into tile material and insert the Wall Plugs[14] (Fig 10.4).
  • Page 15 Step 7 1.Apply silicone to the Seal [16] and attach to the end of Bottom Rail [03] ( Fig 11.1 and Fig 11.2). 2.Measure the length between the left side wall surface and the Bottom Guide[17] and the right side wall surface. 3.Cut the Threshold Gasket according to the length by a Tin snips.
  • Page 16 Step 8 Place Wall Jambs [01] into position by closing to Seal[16]. Ensure Wall Jambs[01] is vertical using a level. Temporarily tape fixed Wall Jamb[01] into position. (Fig 12) Wall Jamb Seal Fig12 Profile Figure Step 9 Using a pencil, mark location of all three screw holes for Wall Jambs[01].
  • Page 17 Step 10 Remove Wall Jambs[01] and drill a 1/4" hole at each location marked for Wall Jamb[01] (Fig 14). ATTENTION Wear safety glasses and cut-resistant, non-slip gloves when drilling or cutting to avoid risk of injury. Fig14 Step 11 1.Insert Wall Plugs[14] in each hole location. 2.The Wall Plugs[14] should fit securely into the holes.
  • Page 18 Step 12 1.Install Gaskets[04] to Wall Jambs[01] (Fig 16.1). Reposition Wall Jamb[01]. Use drill to start the ST4X35 screws[20] into the Wall Plugs[14]. 2.Next, use a screwdriver to hand tighten until secure(Fig 16.2).Install the Caps[21] to finished the installation(Fig 16.3). 3.If the Gaskets[04] is longer than the Wall Jambs[01] after installation.
  • Page 19 Step 13 1.Install Support Bar [02] to Wall Bracket Assembly. The groove of the Support Bar [02] faces inward. Place a level to make sure the horizontal of the Support Bar [02]. 2.If the Support Bar [02] isn't horizontal, remove the Support Bar [02] again. Find the higher Wall Bracket Assembly and loose the fixed screws for one turn.(Fig 17.1) 3.Turn the hex screw counter-clockwise for one turn each time.
  • Page 20 Step 14 Inner Wheels[11A] Door Panel[08B] 1.Install to the . The washer should be on the metal part side(Fig 18.1). Adjust the Eccentric nut like the picture below(Fig 18.1a). wrenches[12] Wheels[11A] 2.Use two in the package to tighten the Inner (Fig 18.2).
  • Page 21 Step 15 1.Disassemble the hex screw and the anchor(Fig 19.1). Outer Wheels [10A] Door Panel[08A] 2.Install to the . The washer should be on the metal part side(Fig 19.2). Adjust the Eccentric nut like the picture below(Fig 19.2a). Outer Wheels [10A] 3.Use a wrench in the package and extra one to fix the (Fig 19.3).
  • Page 22 Step 16 1. From inside the shower, hang the inside Door Panel [08B] first. Insert left wheel into the notch in the Support Bar[02]. Slide the door to the right and insert the other roller wheel into the second notch while inserting the Glass into the Bottom Guide[17] (Fig 20). 2.
  • Page 23 Step 17 1. Install the Side Gaskets [05] to the Door Panels [08](Fig 22.1). 2. If needed, the door height at each wheel can be individually adjusted by using the wrenches[12] . a. For the Outer Wheels[10], using wrenches[12] in the package to carefully loose the nut for half turn.
  • Page 24 Step 18 1. Disassemble gaskets by removing handle levers and handle knobs(Fig 23.1). 2. Door Panel[08A] installation: Install handles and two washers on the outer side of Door Panel[08A]. Install gaskets and handle lever and handle knob on inner side of Door Panel[08A].
  • Page 25 Never use an abrasive sponge or cloth, steel wool or wired brush as these may permanently scratch the surfaces. NOTE: To maximize the life of your door, it is important to regularly inspect the glass and all hardware for misalignment, proper attachment, and/or damage. Contact ANZZI with any questions or concerns.
