DISASSEMBLE CLUTCH

1. If your bike is carbureted, turn the fuel
petcock to "OFF."
2. Shift the transmission into 5
3. Lay the bike on its left side. Catch any draining fuel using a
suitable container.
4. Using an 8 mm socket, remove the OE clutch cover. Pay
close attention to the length and location of the OE screws so
they can each be returned to the same location.
5. Using a socket, remove the pressure plate screws and
springs, then remove the pressure plate.
Note: Your OE parts may look different than pictured depending
on the bike.
th
gear.
Doc ID: 191-7008001
Doc Rev: 080720
Pg. 5
