- Page 1 AC - 105 INSTALLATION GUIDE Please read this installation guide carefully to ensure correct installation of the AC-105 Vertical Platform Lift. AC-105 RESIDENTIAL & COMMERCIAL Rev. 12D142018 p/n: 999355-0084...
- Page 2 This guide describes how to install the Atlas AC-105 Inclined Platform Lift. The Atlas AC-105 Model offers a smoother and more stable ride due to it’s unique c-shaped rail system design. The platform fits most staircases and can be folded when not in use.
- Page 3 “Manufacturer”) shall not be held responsible or liable for any personal injury or property damage caused by or resulting from inappropriate operation of original product or of a product that has been modified or altered from the original AC-105 design. No person or company is authorized to change the AC-105 design without authorization and the express written consent of Les Escalateurs Atlas 1991, Inc.
- Page 4 INSTALLATION DISCLAIMER The Atlas AC-105 Inclined Platform Lift shall be installed and serviced only by an authorized Les Escalateurs Atlas, INC. dealer only. The authorized dealer should refer to this guide for installation and servicing. For Care & Troubleshooting, please refer to the AC-105 Inclined Platform Lift Owner’s Manual.
-
Page 5: Table Of Contents
TABLE OF CONTENTS CODES AND STANDARDS SITE REQUIREMENTS ELECTRICAL REQUIREMENTS BEFORE YOU GET STARTED INTENTIONAL BLANK PAGE AC-105 INSTALLATION 1. RAIL INSTALLATION 2. LOWER RAIL INSTALLATION 2. INSTALL THE LOWER RAIL CONT. 3. UPPER RAIL INSTALLATION 3. UPPER RAIL INSTALL CONT. -
Page 6: Codes And Standards
GFCI protected circuit. Depending on local covdes and regulations, this connection may need to be routed in electrical conduit and hard-wired. WARNING DO NOT OPERATE OR RIDE ON THE AC-105 UNTIL IT HAS BEEN ANCHORED TO AN APPROVED PAD OR FLOOR. BEFORE YOU GET STARTED CHECKLIST 1. - Page 7 THIS PAGE IS INTENTIONALLY LEFT BLANK AR-130 INSTALLATION GUIDE ATLAS 888-773-6708 www.atlasacces.com...
-
Page 8: Ac-105 Installation
Edge Line FIG 1.1 OSTERIOR VIEW The distance between the 3 rails are constant the length of the run. Take note of these measurements as they will be used in the next steps. FIG 1.2 AC-105 INSTALLATION GUIDE ATLAS 888-773-6708 www.atlasacces.com... -
Page 9: Lower Rail Installation
2. Align and mount the Lower Rail to the wall studs using Lag Screws through the Lower Rail’s Mounting Slots. ENSURE THE RAIL IS SQUARED 90° TO THE TOP LANDING FLOOR. Mounting Slot [What screw/size?] FIG 2.1 Wall Stud/Post FIG 2.2 Detailed View of Lower Rail FIG 2.3 AC-105 INSTALLATION GUIDE ATLAS 888-773-6708 www.atlasacces.com... -
Page 10: Install The Lower Rail Cont
DO NOT allow the Lower Rail to touch the Lower Landing floor/ground. Rail Joint & Bolts Assembled FIG 2.4 WARNING DO NOT allow the Lower Rail to touch the Lower Landing floor/ground. FIG 2.5 AC-105 INSTALLATION GUIDE ATLAS 888-773-6708 www.atlasacces.com... -
Page 11: Upper Rail Installation
FIG 3.1 Wall Stud UPPER RAIL LOWER RAIL UPPER RAIL LOWER RAIL FIG 3.2 OSTERIOR VIEW FIG 3.3 The 18” distance between the UPPER AND LOWER RAIL must remain constant the length of the run. AC-105 INSTALLATION GUIDE ATLAS 888-773-6708 www.atlasacces.com... -
Page 12: Upper Rail Install Cont
(3. UPPER RAIL INSTALL CONT.) 3. If requried, join subsequent Upper Rails together using provided Rail Joints and Hex Bolts. Rail Joint & Bolts Assembled FIG 3.4 FIG 3.5 AC-105 INSTALLATION GUIDE ATLAS 888-773-6708 www.atlasacces.com... -
Page 13: Middle Rail Installation
Rail’s Mounting Slots. Refer to Fig 4.1 Mounting Slot 5-1/4” FIG 4.1 MIDDLE RAIL LOWER RAIL FIG 4.2 OSTERIOR VIEW The 5-1/4” distance between the Middle and Lower Rail must remain constant the FIG 4.3 length of the run. AC-105 INSTALLATION GUIDE ATLAS 888-773-6708 www.atlasacces.com... -
Page 14: Middle Rail Cont
(4. MIDDLE RAIL CONT.) 3. Join subsequent Middle Rails adjacently and mount to wall studs, see Fig 4.5 Middle Rails DO NOT require rail joints. Adjecent Middle Rail FIG 4.4 FIG 4.5 AC-105 INSTALLATION GUIDE ATLAS 888-773-6708 www.atlasacces.com... -
Page 15: Install The Upper Tower Column
3. Screw in the Tower to the wall/post at the Upper and Lower Screw Entry Points. Fig 5.3 Tower Cover FIG 5.2 Tower Column Lower Screw Entry Points Tower Side View with Hardware FIG 5.3 FIG 5.4 AC-105 INSTALLATION GUIDE ATLAS 888-773-6708 www.atlasacces.com... -
Page 16: Prepare The Platform
3. Remove the Upper and Lower Carriage Covers by unscrewing the 4 (#10-24) Screws on each side of the Upper and Lower Covers. Upper Carriage Cover NOTE Screw Entry Point Keep the cover hardware in a safe place. Upper Carriage Cover FIG 6.4 AC-105 INSTALLATION GUIDE ATLAS 888-773-6708 www.atlasacces.com... -
Page 17: Install Upper Rollers To Upper Rail
1. Using the same orientation and position in the previous step, slide the Upper Roller 1 (with brake) onto the Upper Rail. Fig 7.2 2. Slide the Upper Roller 2 (without the brake) onto the Upper Rail. FIG 7.2 AC-105 INSTALLATION GUIDE ATLAS 888-773-6708 www.atlasacces.com... -
Page 18: Install The Carriage
Lower Rail FIG 8.1 1/4” Gap CAUTION Ensure the Lower Rollers have a 1/4” gap between the roller and the underside of the Lower Rail. See Fig 8.2 FIG 8.3 FIG 8.2 Lower Roller AC-105 INSTALLATION GUIDE ATLAS 888-773-6708 www.atlasacces.com... -
Page 19: Install The Rr .50 Chain
RR .50 Chain RR .50 Connecting Link RR .50 Chain RR .50 Chain stored behind panel Upper Roller Brake FIG 9.2 WARNING ENSURE .50 CHAIN PROPERLY EXITS FROM BEHIND THE PANEL AND TOWER COLUMN. FIG 9.3 AC-105 INSTALLATION GUIDE ATLAS 888-773-6708 www.atlasacces.com... -
Page 20: Install Drag Chain Cable Carrier
FIG 10.1 Drive Motor Power Cable FIG 10.2 Drag Chain Cable Carrier Upper Roller Upper Roller Brake Drag Chain Cable Carrier Phillips Screw FIG 10.3 Drive Motor Power Cable entry point FIG 10.4 AC-105 INSTALLATION GUIDE ATLAS 888-773-6708 www.atlasacces.com... -
Page 21: Wire Main Power/Drive Motor/Batteries
FIG 11.1 Drive Motor Terminals Electical Disconnect FIG 11.2 Electrical Control Panel FIG 11.3 WARNING FIG 11.2 is a reference image and NOT the electical diagram. Please refer to the provided Electrical Diagram when wiring. AC-105 INSTALLATION GUIDE ATLAS 888-773-6708 www.atlasacces.com... -
Page 22: Install Safety Arms & Calibrate Cams
LOWER ARM OPEN (LAO) UPPER ARM CLOSE UPPER ARM OPEN SECURITY LINE (LAC) (LAC SL) UPPER ARM CLOSED (LAO) FIG 12.3 NOTE NOTE THE ARM CONGIFURATION SHOW IN FIG 12.3 IS FOR ASME REGULATION AC-105 INSTALLATION GUIDE ATLAS 888-773-6708 www.atlasacces.com... -
Page 23: Calibrate Floor Cams
Ensure that the Floor Cams have been properly adjusted. FIG 13.1 FLOOR OPEN (FLO) FLOOR CLOSE SECUTIRY LINE (FLC SL) FRONT VIEW OF FLOOR CAMS FIG 13.2 FLOOR OPEN (FLO) FLOOR CLOSE SECUTIRY LINE (FLC SL) REAR VIEW OF FLOOR CAMS AC-105 INSTALLATION GUIDE ATLAS 888-773-6708 www.atlasacces.com... -
Page 24: Install Rail Cams And Adjust Limit Switches
2. Once deteremined, install the two Cams on the Lower Rail using four #10-24 screws and nuts. ENSURE THE CAMS FACE INWARD. WARNING FIG 14.1 ENSURE THE CAMS FACE INWARD TOWARDS THE CARRIAGE FIG 14.2 Detailed view of Cam FIG 14.3 AC-105 INSTALLATION GUIDE ATLAS 888-773-6708 www.atlasacces.com... -
Page 25: Mount Upper Tower And Carriage Covers
15. MOUNT UPPER TOWER AND CARRIAGE COVERS PROCEDURE Mount the Upper Tower Cover and the two Carriage Covers the #10-24 scews from the Steps 5 and 6 respectively. FIG 15.1 FIG 15.2 AC-105 INSTALLATION COMPLETE. AC-105 INSTALLATION GUIDE ATLAS 888-773-6708 www.atlasacces.com...
