- Page 1 ASSEMBLY GUIDE Enzo Large Bookcase...
-
Page 2: What You Need
Components Before you get started, check you have all of the pieces below. If anything’s missing, please visit www.brosa.com.au/pages/product-return-and-parts-request and we’ll sort it out right away. Back Panel x 3 Top Panel x 1 Shelf with Rails x 2 Shelf x 3... - Page 3 Align a shelf with rails with a side panel (2), Step 1 making sure the bolt holes overlap. Fit a washer to a short bolt and insert the bolt into the hole. Fix the bolt with the Allen key (F). Repeat this for the other hole and then repeat the process for the other shelf with rails (8).
- Page 4 Insert wooden dowels into the outer holes of the Step 2 base frame (10). A x 4...
- Page 5 Align the base frame (10) with the side panel using Step 3 the wooden dowels. Fit a washer to a long bolt and insert the bolt into the hole. Fix the bolt with the Allen key (F). Repeat this for the other hole. C x 2 D x 2 F x 1...
- Page 6 Align the other side panel with the structure Step 4 formed in Step 3. Repeat the previous steps for shelves with rails and base frame to attach the side panel to the formed structure. B x 4 C x 2 D x 6 F x 1...
- Page 7 Insert the wooden dowels into the outer holes of Step 5 the top panel (1). A x 4...
- Page 8 Align the top panel with the formed structure Step 6 using the wooden dowels. Fit a washer to a long bolt and insert the bolt into the hole. Fix the bolt with the Allen key (F). C x 4 D x 4 F x 1...
- Page 9 Slide the tongue into the groove so that the back Step 7 panels are joined together.
- Page 10 With the help of another person, lift the bookcase Step 8 and place it upright on the level surface. Align the formed back panel with the formed space on the back of the body and secure it in place using the screws and a Phillips screwdriver.
- Page 11 Incline the shelves to t them into the inner Step 9 space of the body and then place them upon the rails of the side panels.
- Page 12 Fit the drawer into the lowest space by tting the Step 10 rails of the side panels into the grooves of the drawer. Enjoy your new bookcase!
