- Page 1 ASSEMBLY GUIDE Elizabeth Entertainment Unit...
- Page 2 Components Upon unpacking your entertainment unit from it’s delivery box, you should have the separate pieces shown below. Follow the steps on the next pages to assemble your new entertainment unit. Entertainment Leg x 2 unit x 1 Leg x 2 Shelving x 2 Shelving x 2 Hardware...
- Page 3 Step 1 Insert a cross dowel in the top hole on each leg (2 & 3) making sure that it ts facing the correct direction as shown in the diagram. Insert a threaded bolt in the side hole on each (2 &...
- Page 4 Step 2 Align each leg (2 & 3) one by one to the underside of the entertainment unit so that the threaded bolt ts in its corresponding hole. Fit a washer to the threaded bolt followed by a lock washer and a nut (E).
- Page 5 Step 3 With another person, gently lift the entertainment unit and place it upright on a level surface. On the inside of the entertainment unit insert the shelving supporters at the desired level, making sure that the pin on each of them are facing upward. G x 16 Angle the shelves when inserting (one by one) making sure the holes are facing down so that the pins...
- Page 6 Step 4 e following steps are to instruct how to adjust the hinges if needed. Lateral adjustment by screw adjustment. Front-to-Back by slackening and retightening the hinge-arm mounting screw. Vertical adjustment via slots on mounting plate by slackening and retightening the screws on the mounting plate.
