- Page 1 ASSEMBLY GUIDE Ethan 5 Drawer Tall Chest...
- Page 2 Components Upon unpacking your chest from it’s delivery box, you should have the pieces shown below. Follow the steps on the next pages to assemble your new unit. Drawer Box Unit 15MIN Cross dowel Spanner M8 x 12 x 30mm Threaded bolt Mounting plate M8 x 60mm...
- Page 3 Step 1 Insert cross dowels into the legs by placing each dowels into the holes on top of each leg (2). Ensure the horizontal marking on each dowel is facing down. Screw threaded bolts into dowels that are already concealed in legs as shown.
- Page 4 Step 2 Lay drawer box unit on a at surface. Attach each leg into place by inserting threaded bolt through the pre-drilled hole of each metal corner bracket as shown. Insert in order the at washer (C), lock washer (D), and hex onto threaded bolt on leg as shown.
- Page 5 Step 3 With help of assistant, stand the drawer upright. Enjoy your new drawers!
- Page 6 Tip Kit Instructions Notice: To prevent injury and property damage from unexpected tipping of furniture, we highly recommend installation of the anti-tip kit included with this project. Attaching furniture to wall with anti-tip kits. Determine where the piece is to be placed and mark location on the wall for the mounting bracket screw holes.
