Arthroscopy support 10-353
Arthroscopy support 10-353 including versions
Version
10-353
10-353-18
10-353-18-B
10-353-US
10-353-XL
Warning! This symbol indicates important information related to safety. Follow these
instructions carefully.
Read User Manual before use! It is important to fully understand the content of the user
manual before attempting to use the equipment.
2020-10-30
Document number: M10-353EN rev.01
1
Description
Post Ø20 mm, V-shaped side
Post Ø18 mm
Post Ø18 mm, plane side
Post Ø18 mm, excl. pads
Post Ø20 mm, V-shaped side. Adaptation for larger legs
Advertisement
Table of Contents
Related Manuals for Reison 10-353
Summary of Contents for Reison 10-353
- Page 1 Arthroscopy support 10-353 Arthroscopy support 10-353 including versions Version Description 10-353 Post Ø20 mm, V-shaped side 10-353-18 Post Ø18 mm 10-353-18-B Post Ø18 mm, plane side 10-353-US Post Ø18 mm, excl. pads 10-353-XL Post Ø20 mm, V-shaped side. Adaptation for larger legs Warning! This symbol indicates important information related to safety.
-
Page 2: Intended Use
Intended use Arthroscopy support for fixation and positioning of patients leg during surgery in the knee area. The product is to be used by medical professionals within a medical facility. Safety regulation Maximum load: 40 kg, corresponding to a patient weight of 215 kg, according to EN 60601-1 and EN 60601-2. -
Page 3: User Instruction
User instruction Installation Position adjustment... - Page 4 Maintenance Service, preventive maintenance, adjustment and repair shall be performed by authorized personnel only. Altering the construction without a written consent from the manufacturer, is strictly forbidden. Cleaning Clean with antiseptic detergent with pH 6 – 8 and warm water. Ethanol can be used on metal surfaces. Wipe dry with soft cloth.
-
Page 5: Spare Parts
Spare parts Version: 10-353 10-353-18 10-353-18-B 10-353-US 10-353-XL Description Article no. Article no. Article no. Article no. Article no. Support tube 10376 10376 10376 10376 10376 Adjusting screw 10382 10382 10382 10382 10382 10383 10383 10383 10383 10383 Driving plate pin... -
Page 6: Technical Specification
40 kg, corresponding to a patient weight of 215 kg, according to EN 60601- 1 and EN 60601-2 Material arthroscopy support Stainless steel Version UDI-DI Weight Dimension (H x W x L) 10-353 07350111831431 4,3 kg 265 x 130 x 465 mm 10-353-18 07350111831448 4,3 kg 265 x 130 x 465 mm... - Page 7 Reison Medical AB Eriksbergsvägen 32A 734 92 Hallstahammar SWEDEN +46 (0)220 433 99 order@reison.se info@reison.se...
