Arm surgery table 10-390
Arm surgery table 10-390 including versions
Version
10-390
10-390-S
10-390-US
10-390-UK
Warning! This symbol indicates important information related to safety. Follow these
instructions carefully.
Read User Manual before use! It is important to fully understand the content of the user
manual before attempting to use the equipment.
2021-04-21
Document number: M10-390EN rev.01
1
Description
Clamp (EU 25x10 mm rail)
Clamp (EU 25x10 mm rail), excl. mattress
Clamp (US 1⅛ '' x ⅜ '' rail)
Clamp (UK 1¼ " x ¼ " rail)
Advertisement
Table of Contents
Related Manuals for Reison 10-390 Series
Summary of Contents for Reison 10-390 Series
- Page 1 Arm surgery table 10-390 Arm surgery table 10-390 including versions Version Description 10-390 Clamp (EU 25x10 mm rail) 10-390-S Clamp (EU 25x10 mm rail), excl. mattress 10-390-US Clamp (US 1⅛ ’’ x ⅜ ’’ rail) 10-390-UK Clamp (UK 1¼ ” x ¼ ” rail) Warning! This symbol indicates important information related to safety.
- Page 2 Intended use Arm surgery table for placement of patient arm during surgical treatment of arm and hand. The product is to be used by medical professionals within a medical facility. Safety regulation Maximum load: 15 kg in even distribution, corresponding to a patient weight of 200 kg, according to EN 60601-1 and EN 60601-2.
- Page 3 User instruction Installation...
- Page 4 Maintenance Service, preventive maintenance, adjustment and repair shall be performed by authorized personnel only. Altering the construction without a written consent from the manufacturer, is strictly forbidden. Cleaning Clean with antiseptic detergent with pH 6 – 8 and warm water. Ethanol can be used. Wipe dry with soft cloth.
- Page 5 Spare parts Version: 10-390 10-390-S Description Pcs. Article no. Article no. Frame 10056 10056 Plate 10045 10045 Blind rivet AS 4,8x12-F Knob VC 192/40 B M8 Washer 10004 10004 Screw MF6S M6x12 A2 EU: 10031 Clamp body US: 10547 EU: 10031 UK: 10543 Supporting leg 11041...
- Page 6 Technical specification Maximum work load 15 kg in even distribution, corresponding to a patient weight of 200 kg, according to EN 60601-1 and EN 60601-2 Weight 13 kg Dimension (H x W x L) 700-1150 x 525 x 820 mm Material arm surgery table Stainless steel High pressure laminate...
- Page 7 Reison Medical AB Eriksbergsvägen 32A 734 92 Hallstahammar SWEDEN +46 (0)220 433 99 order@reison.se info@reison.se...
