Extension rail 10-359
Extension rail 10-359 including versions
Warning! This symbol indicates important information related to safety. Follow these
instructions carefully.
Read User Manual before use! It is important to fully understand the content of the user
manual before attempting to use the equipment.
2021-11-29
Document number: M10-359EN rev.01
1
Version
Description
10-359
215 mm angled rail EU 25x10 mm
10-359-US
215 mm angled rail US 1⅛ '' x ⅜ ''
10-359-UK
215 mm angled rail UK 1¼ " x ¼ "
Advertisement
Table of Contents
Related Manuals for Reison 10-359
Summary of Contents for Reison 10-359
- Page 1 Extension rail 10-359 Extension rail 10-359 including versions Version Description 10-359 215 mm angled rail EU 25x10 mm 10-359-US 215 mm angled rail US 1⅛ ’’ x ⅜ ’’ 10-359-UK 215 mm angled rail UK 1¼ ” x ¼ ”...
- Page 2 Intended use Angled extension rail intended to be attached to the accessory rails on the OR-table to enable extended space for accessories on the table. The product is to be used by medical professionals within a medical facility. Safety regulation Maximum load: 25 kg per rail Before use, ensure correct function! Service and preventive maintenance shall be performed by authorized personnel.
- Page 3 User instruction Installation Position adjustment...
- Page 4 Maintenance Service, preventive maintenance, adjustment and repair shall be performed by authorized personnel only. Altering the construction without a written consent from the manufacturer, is strictly forbidden. Cleaning Clean with antiseptic detergent with pH 6 – 8 and warm water. Ethanol can be used. Wipe dry with soft cloth.
- Page 5 Spare parts Version: 10-359 10-359-US 10-359-UK Description Pcs. Article no. Article no. Article no. Post 10481 10481 10481 Spring 1602 1602 1602 Gear ring 10120 10120 10120 Rail 10477 11254 11255 Washer 10480 10480 10480 Easher BRB 10,5x20x2 Nylon Knob VCT 53B M10x40 Soft...
- Page 6 Technical specification Maximum load 25 kg Material extension rail Stainless steel Aluminum Weight 2,2 kg Dimension (H x W x L) 330 x 65 x 300 mm Vertical adjustment 165 mm UDI-DI 10-359 07350111831769 10-359-US 07350111831783 10-359-UK 07350111831776...
- Page 7 Reison Medical AB Eriksbergsvägen 32A 734 92 Hallstahammar SWEDEN +46 (0)220 433 99 order@reison.se info@reison.se...
