DESCRIPTION
Demonstration Circuit 2611A features the
LTC6955-1, Ultralow Jitter 11 Output Fanout Buffers.
By default, the DC2611A is powered from a single 3.3V
supply. An option is provided to power to the DC2611A
from dual supplies, allowing for the LTC6955's output
supply pins to connect to an LTC Silent Switcher
LTC6955 input supply pin to connect to a low noise LDO.
The differential inputs and six of the differential outputs
are populated with 0.5" spaced SMA connectors. These
outputs are AC-coupled with 50Ω transmission lines
CAL_OUT,
SMA
OUT10, CML
AC-coupled
Outputs, SMA
OUTPUT SEL,
Switches
TEMP, turret
OUT8, CML
AC-coupled
Outputs, SMA
OUT6, CML
AC-coupled
Outputs, SMA
DEMO MANUAL DC2611A
Ultralow Jitter 11 Output
LTC
6955/
making them suitable to drive 50Ω impedance instru-
®
ments. The remaining four differential outputs are termi-
nated with 100Ω.
A calibration path is provided to aid in accurate LTC6955
propagation delay measurements. The calibration path
and the
can be also reconfigured as a DC path, which allows for
®
a convenient method of locking the LTC6955 outputs to
an external PLL/VCO, as shown in Figure 2.
Design files for this circuit board are
All registered trademarks and trademarks are the property of their respective owners.
Single Supply 3.3V Input,
banana jacks J27 & J28
Figure 1. DC2611A Connections
LTC6955/LTC6955-1
Fanout Buffer
available.
CAL_IN,
SMA
FILT, Header
IN Input, SMA
VIN33 Option,
DC2611 Reconfiguration
OUT0, CML
AC-coupled
Outputs, SMA
OUT1, CML
AC-coupled
Outputs, SMA
OUT4, CML
AC-coupled
Outputs, SMA
Refer to
Rev. 0
1
