The Component Status Screen

5.6.4

NEXT and PREVIOUS

The Chassis Status View screen lists ports in ranges of 12 at a time. Use the
and
NEXT PREVIOUS
previous range.
5.6.5

ENABLE ALL PORTS

Invoke this screen command to enable all ports in the stack. It is available
only in
ADMINISTRATIVE
5.6.6

REFRESH

The user may toggle this screen command to select screen refresh intervals
from 3 to 10 seconds.
5.7 The Component Status Screen
Access the Component Status screen (Figure 5-11) from the Device Status
menu.
STHI LOCAL MANAGEMENT
COMPONENT NAME
STHI Chassis MGR
STHI LIM
STHI Protocol stack
STHI SNMP agent
Network 1
The Component Status View screen is a read-only screen which lists the
enabled/disabled status of the STHI hub's operating system and
associated components. (Software applications, resources, and functions
registered in the STHI are known as components.) All compatible
Page 5-20
screen commands to view ports from the next or
mode.
COMPONENT STATUS VIEW
Figure 5-11. Component Status Screen
Flash Image Version:
REFRESH 3sec
1.00.00
RETURN
