2.2.3

Supported MIB Groups

The STHI provides access to the following Management Information Base
groups and their respective functionality:
Standard MIBs
• MIB-2 (RFC 1231)
Cabletron Enterprise MIBs
• Download
• MIB-II Extensions
• Token Ring FNB (Flexible Network Bus)
• DOT 5 Physical & Logical
• Token Ring Station Assignment
• Device
• PIC MIB (Product Information Chip MIB)
• Chassis MIB
2.2.4

Ring Speed

The operating ring speed for the STHI may be set via the Ring Speed
Switch on the front face of the STHI or by MIB commands via the SNMP
Tool screen in Local Management.
The STHI hub's Ring Speed switch setting is read only at power-up. In
order to change the ring speed via the Ring Speed switch, the user must
first change the switch setting and then reset the STHI (see Section 4.3, The
Reset Button).
MIB commands override the Ring Speed switch setting. Once the switch
setting has been overridden, the MIB command ring speed setting will
remain in effect at all subsequent power-ups as long as the switch setting
is not changed. MIB commands are accessible through the MIB Navigator
screen on the intelligent hub's Local Management application and
through other SNMP network management software packages including
Cabletron Systems' Remote LANVIEW
The user may cancel the MIB override and regain switch control over the
STHI hub's ring speed by changing the current switch position and
resetting the STH by the reset button.
Operating Specifications
®
/Windows.
