The System Level Screen

5.3 The System Level Screen
Access the System Level screen (Figure 5-4) from the Device Setup menu.
STHI LOCAL MANAGEMENT
System Date:
SNMP Agent
Enable IP Address Discovery:
Retry Interval (0001-9999 Mins):
Enable Beacon Recovery:
Number of Retries (000-100, 999=infinite):
Retry Interval (000-999 Secs):
FNB MAC Address - Physical:
FNB MAC Address - Locally Administered:
SAVE
5.3.1

System Date and System Time

Use these fields to set the correct date and time.
Type the date into the field in a MM/DD/YY format for the date, and
HH:MM:SS for the time. If the format entered is invalid, the message
"Invalid Date" or "Invalid Time" appears and the edit is rejected.
5.3.2

IP Address

Use this field to set the host Internet Protocol (IP) address for the STHI.
If the IP Address is changed, the STHI will execute a soft-reset after
is invoked to re-initialize all affected parameters.
Only a user with Super-User access can change the device's
IP address. See Section 5.4 for information about
TIP
Super-User access.
Page 5-8
SYSTEM LEVEL
06/15/10
IP Address
134.141.143.141
Figure 5-4. System Level Screen
Flash Image Version:
System Time: 13:08:00
Subnet Mask
255.255.0.0
[YES] State: [SEEKING ]
0015
[YES]
004
021
00-00-B8-00-00-00
00-00-B8-E8-A5-B1
1.00.00
RETURN
SAVE
