Using LM Screens

bottom line of the screen, then the Main Menu screen shown in Figure 5-2
appears.
STHI LOCAL MANAGEMENT
Screen Title Line
Screen Commands Line
Figure 5-2. Main Menu with Screen Anatomy Labels
As a precaution against unauthorized access, if LM detects
NOTE
no keyboard activity for 15 minutes, it closes the current
session and returns to the Password screen.
5.2 Using LM Screens
5.2.1

Working with LM Screens

This section describes how to work with all LM screens. Refer to Figure 5-2
for screen anatomy.
Invoking Menu Options or Screen Commands
1. Use the Tab key or arrow keys to highlight the item.
2. Press the Return key.
Invoking a menu option opens the named screen.
Invoking a screen command executes the named action. The
screen command returns the user from the current screen to its parent
screen. The
SAVE
the screen and put them into effect.
Page 5-4
MAIN MENU
DEVICE SETUP
DEVICE STATUS
DEVICE STATISTICS
SNMP TOOL
EXIT LM
or screen commands record all entries set on
EXECUTE
Flash Image Version:
Field Sensitive Help Line
Event Message Line
1.00.00
Menu Items or Fields
RETURN
