Accessing LM
5.1.1

Dumb Terminal Configuration

Configure the LM console according to the parameter settings defined in
Table 5-1. On VT100/200/300 series terminals, press F3 to access the Setup
Directory. For setup parameters not listed in the following table, any
selection should be acceptable. Refer to terminal's manual for more
instructions if necessary.
Table 5-1. Setup Requirements for LM Console
Menu
Display Setup:
General Setup:
Communications
Setup:
Keyboard Setup:
Page 5-2
Parameter
Columns
Controls
Auto wrap
Text Cursor
Mode
Cursor keys

Transmit

Receive

Bits, parity
Stop Bit
Local Echo
Port
Auto Answerback
Keys
Margin bell
Warning bell
Auto Answerback
Setting
80 Columns
Interpret controls
No Auto wrap
No Cursor
VT100, 7 bit control
Normal cursor keys
(all values from 2400 to
19,200 accepted)
Receive = transmit
8 Bits, no parity
1 Stop Bit
No Local Echo
Data Leads Only
No Auto Answerback
Typewriter keys
Margin bell
Warning bell
No Auto Answerback
