Sunricher SR-2834BDMX Quick Start Manual

Dual Color DMX512 Controller
Important: Read All Instructions Prior to Installation
Function introduction
Dual color slider, touch to adjust color temperature
between Warm White and Cool White
Click to turn on/off
50% WW+50% CW
Press and hold down to save
colors;Click to recall the saved
19.4 mm
DC Power input
100% WW+0% CW
100% brightness
Brightness slider, touch to adjust
brightness
1% brightness
0% WW+100% CW
Front side
60.3 mm
52.0 mm
DMX512 Wall
Panel Controller
DMX OUTPUT
V- V+ D- D+ GND
DMX512 signal output
Back side
Product Data Product Data
09.34BDE.04713
Output Signal
Power Supply
Power consumption
Operating temperature
Relative humidity
Dimensions
Safety & Warnings
• DO NOT install with power applied to device.
• DO NOT expose the device to moisture.
Wiring diagram
DMX512 Wall
Panel Controller
DMX OUTPUT
V- V+ D- D+ GND
12-24VDC
PSU
AC 100-240V
Set DMX Address
This DMX master controller can control many DMX decoders, please set all decoders' address as 001.
• Touch sensitive
DMX512 signal
• Glass interface(white & black)
12-24VDC
• Standard DMX512 Signal output
• Control CCT color
200 mA
• Control 1 zone/area
• Waterproof grade: IP20
0-40°C
8% to 80%
86x86x29.1mm
L
V+
12V/24V/36V
N
CV PSU
V-
G
DMX512 Decoder
0-5 0-9 0-9
DMX512 Decoder
0-5 0-9 0-9
DMX512 Decoder
0-5 0-9 0-9
AC 100-240V
V+ V+
WW WW
Connect with Dual Color LED Strip
CW CW
WW WW
CW CW
V+ V+
WW WW
Connect with Dual Color LED Strip
CW CW
WW WW
CW CW
V+ V+
WW WW
Connect with Dual Color LED Strip
CW CW
WW WW
CW CW
