Ultra Start Pro Series Installation Manual

Remote car starter
Hide thumbs Also See for Pro Series:

Advertisement

Quick Links

Installation Guide
Pro Series
1000
Remote Car Starter
SUPPORT
Toll Free: 1-866-698-5872
email: support@ultrastarters.com
web: www.ultrastarters.com
WWW.ULTRASTARTERS.COM
VERSION 012201

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pro Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Ultra Start Pro Series

  • Page 1 Installation Guide Pro Series 1000 Remote Car Starter SUPPORT Toll Free: 1-866-698-5872 email: support@ultrastarters.com web: www.ultrastarters.com WWW.ULTRASTARTERS.COM VERSION 012201...
  • Page 2: Transmitter Programming

    NOTE : All transmitters to be used must be programmed at the same time . Any transmitter not programmed in the same sequence will be erased from the systems memory. PRO SERIES 4-BUTTON TRANSMITTER # 2 Unlock # 1 Lock...
  • Page 3 BASIC INSTALLATION - QUICK START STEP 1 The following wires must be connected 6 PIN POWER CONNECTOR - Connect the following: WIRE FUNCTION CONNECT TO ON VEHICLE RED-1 Main Power Input Constant 12V (+) at Ignition Harness RED-2 Main Power Input Constant 12V (+) at Ignition Harness BLUE...
  • Page 4 1000 SERIES WIRING DIAGRAM DIP SWITCHES SETTINGS Dip Switch Settings -#2 Dip Switch Settings - #1 0N - Manual Transmission 0N - Alternator Mode OFF -Auto Transmission OFF - Tach-less/Tach Mode 30 Amp (+) Input Connect To Constant Power At Power Ignition Harness 30 Amp (+) Out...
  • Page 5 WIRING - 6 PIN HARNESS Red Wires: +12 VDC Main Power Source Input. Connect these two Red wires to a main constant +12 VDC power Black: Chassis Ground ground. Connect this Black wire securely to a clean, solid negative chassi Blue: Ignition - Switched +12 VDC Output ignition Connect this Blue wire to the ignition wire supplying + 12 VDC when the...
  • Page 6 WIRING CONTINUED White/Violet: Negative Output while Remote Start is running Used for bypassing the factory ignition kill systems (i.e. VATS, PATS, Passlock or Transponder) or to bypass sensors. See your vendor for optional Factory Bypass Kits. Green: Negative Door Switch Input (GM Type) Note: This Green wire is required for Manual Transmission Mode.
  • Page 7 TRANSMITTER PROGRAMMING Note: The system is capable of learning up to 3 different transmitter codes. Note: The system is capable of learning up to 3 different transmitter codes. Note: The system is capable of learning up to 3 different transmitter codes. All Transmitters to be programmed MUST be programmed at the same time, or All Transmitters to be programmed MUST be programmed at the same time, or All Transmitters to be programmed MUST be programmed at the same time, or...
  • Page 8 PROGRAMMING MODES - Tach Detection VOLTAGE SENSE MODE (SYSTEM DEFAULT Note: Ensure that program switch #1 is in the “Off” position. The recommended setting is Voltage Sense Mode. This method requires no additional wiring. Note: In Voltage Sense Mode, do NOT connect the Black/White Tach Sense Wire. If voltage Sense Mode does not start the car properly, proceed into: TACH SENSE / TACH LEANING MODE Note: Ensure that program switch #1 is in the “Off”...
  • Page 9 PROGRAMMING - Option Settings Feature 2 - Door Lock Timing - Default: 0.75 Seconds. 1. Enter in “Program Mode” (See Enter program Mode (1. Open the hood. 2. Turn the Ignition Key “On/Off”, “On/Off”, “On”.3. Press & Release the Valet button on the antenna.). 2.
  • Page 10: Manual Transmission

    MANUAL TRANSMISSION Manual Transmission Mode Note: Program switch #2 on control unit must be in “ON” position. In order to start a Manual Transmission equipped vehicle: Manual Transmission Reservation Mode must be enables each time. Manual Transmission Reservation Mode. 1. Leave the Ignition Key in the “On” position (Car is still running). 2.
  • Page 11: Relay Diagrams

    RELAY DIAGRAMS Use 30A SPDT Automotive Type Relays NEGATIVE - Door locks Vehicle Lock To Control Lock/Unlock Relay or Switch Actuators lock Green Blue POSITIVE (3 WIRE) - Door locks Vehicle Lock Lock/Unlock Fused +12V lock Switch Green Blue To Control Relay or Actuator REVERSE POLARITY (5 WIRE) Door locks...
  • Page 12 RELAY DIAGRAMS STARTER KILL 2500 SERIES Start ON BOARD STARTER KILL RELAY SPADE CONNECTORS STARTER KILL 1500 SERIES Start Start Yellow Orange REMOTE STARTER - Self Diagnostics Starter will not Attempt Remote Start Park Lights Fault 4 Flashes Hood Open 4 Flashes Door Input Shutdown(manual) 4 Flashes...
