- Page 1 REV.2009.09.13 72 SERIES Advanced Remote Starters & Vehicle Security Systems THIS MANUAL COVERS THE OPERATIONS OF THE 1172, 1272 AND 3272 SERIES REMOTE STARTERS WARNING: NEVER USE AN AUTOMATIC TRANSMISSION STARTER IN A MANUAL TRANSMISSION VEHICLE...
-
Page 2: Table Of Contents
72 SERIES OWNER'S MANUAL Important Notes...Page 3 Quick View Operations...Pages 4-5 Remote Start Operations...Pages 6-12 Remote Start Idle Mode Remote Start Optional Operations...Pages 6-11 Lock Doors Auxiliary Outputs Car Finder Mode Emergency Override Mode...Page 12 Activate Override Mode Timer Mode/ Cold Start...Page 13 Transmitter Programming...Page 14 LED 2way Operations...Page 15-16 Lock 2way... -
Page 3: Important Notes
72 SERIES PAGE 3 OWNER'S MANUAL IMPORTANT NOTES ATTENTION Please take a moment to review the safety precautions before operating your system. 1) For safety reasons, the owner/user of this system MUST INSTALL a CARBON MONOXIDE DETECTOR in the living area near to where the vehicle is being stored or parked. -
Page 4: Quick View Operations
72 SERIES OWNER'S MANUAL BUTTON BUTTON PRESS 1 SECOND 3 SECONDS PRESS THEN RELEASE THEN LOCK PRESS & HOLD 1 SECOND 1 SECOND WHILE ALARM IS TRIGGERED 5 SECONDS UNLOCK/ TRUNK PRESS & RELEASE PRESS & HOLD START PRESS AND HOLD HOLD FOR 3 SEC PRESS TOGETHER THEN RELEASE... -
Page 5: Remote Start
PAGE 5 QUICK VIEW CHART BUTTON BUTTON PRESS PRESS THEN RELEASE THEN 2ND CAR PRESS & HOLD OPERATION WHILE PANIC IS TRIGGERED 2ND CAR OPERATION 2ND CAR OPERATION IS NOT AVAILABLE ON 2WAY MODELS SERVICE MODE / EMERGENCY OVERRIDE MODE TO AVOID SERIOUS INJURY, this remote start system must be set into Service Mode before any under hood servicing is started. -
Page 6: Remote Start Operations
72 SERIES OWNER'S MANUAL PRESS & RELEASE 1. Press and release the START button on the remote transmitter one time.* *Press twice if the system is programmed for Safety Start. 2. The park lights will flash and the horn (optional) will Honk once as confirmation. 3. - Page 7 PAGE 7 SYSTEM OPERATIONS PRESS & HOLD 1. While the vehicle is running with the remote starter press and hold the START button for three seconds. 2. The park lights will flash and the horn (optional) will honk 2 times to confirm shutdown. - Pressing the brake pedal or opening the hood will also shut down the remote starter.
-
Page 8: Lock Doors
72 SERIES OWNER'S MANUAL PRESS & RELEASE 1. Press and release the Lock Button on the remote transmitter. 2. The park lights will flash and the horn (optional) will Honk one time. 3. The doors will lock. 4. The LED will start flashing within five seconds. NOTES: - If the panic mode is activated pressing the lock button on the remote will stop the horn from sounding. -
Page 9: Lock Doors
PAGE 9 SYSTEM OPERATIONS PRESS & RELEASE 1. Press then release the Unlock Button on the remote transmitter. 2. The park lights will flash and the horn (optional) will honk two times. 3. The doors will unlock and the dome lights will activate. (optional) 4. -
Page 10: Car Finder Mode
72 SERIES OWNER'S MANUAL PRESS HOLD 1. Press and HOLD the Lock Button for three seconds. The doors will lock. 3. The park lights will begin to flash and the horn will honk ON and OFF. 4. To turn off panic, press Lock or Unlock Buttons on remote. 5. - Page 11 PAGE 11 SYSTEM OPERATIONS HOLD THE # BUTTON The Aux output can be programmed for a variety of custom applications. (SEE DEALER FOR DETAILS) 1. To activate Auxiliary Channel 1 output press and hold the # Button for 3 seconds. 2.
-
Page 12: Emergency Override Mode
72 SERIES OWNER'S MANUAL EMERGENCY OVERRIDE MODE This feature is to be used if the remote transmitter is lost or is not communicating with the system. This will disable the optional starter disable if installed. Follow the steps below to deactivate your system. ACTIVATING EMERGENCY OVERRIDE MODE Turn the Ignition Key ON (Leave in the ON position) -
Page 13: Timer Mode/ Cold Start
PAGE 13 COLD START MODE SETTING COLD START MODE Code Start Mode will start the vehicle at a user selectable start interval. The vehicle can be set to start once every 2, 3 or 4 hours, for a maximum of 12 starts. The vehicle will start at the selected start interval and run for the programmed runtime*. -
Page 14: Transmitter Programming
72 SERIES OWNER'S MANUAL The system can lean up to 4 different remote’s. Each remote to be used MUST be programmed together during the same sequence. For security, when a new remote is programmed all previous remote’s are deleted. Please see remote operation chart for information on using Second Car / Pad Lock Operations. -
Page 15: Led 2Way Operations
PAGE 15 LED 2 WAY OPERATIONS LOCK BUTTON When the lock button is pressed the light behind the button will flash once and the remote will beep once as confirmation that the function has been completed. If the system is not in range the remote will beep 3 times. LOCK UNLOCK BUTTON When the unlock button is pressed the light behind the button will flash twice... -
Page 16: Panic Mode
72 SERIES OWNER'S MANUAL HOLD PANIC MODE When the lock button is held for 5 seconds the system will enter Panic Mode. The LEDs under the buttons will flash in a pattern and the remote will beep to indicate Panic Mode is active. If the system is not in range the remote will beep 3 times. -
Page 17: Trouble Shooting
PAGE 17 TROUBLE SHOOTING SYMPTOM - Count the park light flashes then see the diagnostics page. - Check battery voltage in the remote. Vehicle is not remote - Make sure you are with-in operating range. starting? - Check if the vehicle anti-theft is activating. - Reprogram the remote’s using Transmitter Program Mode. -
Page 18: Diagnostics
72 SERIES OWNER'S MANUAL Diagnostic Mode is a tool that can help trouble shoot a start fault. If the remote starter fails to start i.e.: the hood is open the park likes will flash a diagnostic code. i.e.: 5 flashes = start attempt with hood open. If the vehicle does not remote start, count the park light flashes then compare it to the chart below. -
Page 19: Warranty
72 SERIES PAGE 19 PRODUCT WARRANTY OWNER'S MANUAL WARRANTY Applicated Security Technologies, Inc. ("AST") promises to the original purchaser to repair or replace with a comparable reconditioned model any AST control module ("module") excluding without limitation the any other accessories, including but not limited to the antenna, remote, siren and wiring harness, proves to be defective in workmanship or material under reasonable use during the lifetime of the vehicle it was originally installed, provided the following conditions have been met: the module was professionally installed and serviced by an authorized AST dealer;... -
Page 20: Other
72 SERIES OWNER'S MANUAL Technical Support: support@ultrastarters.com Additional Product Information: www.ultrastarters.com IMPORTANT NOTES LOCK, UNLOCK, DRIVER'S DOOR PRIORITY UNLOCK, TRUNK RELEASE AND THE AUXILIARY OUTPUTS ARE OPTIONAL OUTPUTS. ENABLING THESE FEATURES REQUIRES CUSTOM INSTALLATION & PROGRAMMING. THESE FEATURES MAY NOT BE COMPATIBLE WITH SOME VEHICLES.
